Alienware X51 R2 Manual de usuario

Alienware X51 R2

Owner’s Manual

Regulatory model: D05S

Regulatory type: D05S002

book.book Page 1 Monday, November 18, 2013 3:50 PM

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss

of data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.

is strictly forbidden.

Trademarks used in this text: Dell™ and the DELL logo are trademarks of Dell Inc.; Alienware®is a

trademark or registered trademark of Alienware Corporation; Microsoft®, Windows®, and the Windows

start button logo are either trademarks or registered trademarks of Microsoft Corporation in the

United States and/or other countries; Bluetooth®is a registered trademark owned by Bluetooth SIG,

Inc. and is used by Dell under license.

Other trademarks and trade names may be used in this document to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

2013 - 10 Rev. A01

book.book Page 2 Monday, November 18, 2013 3:50 PM

Contents | 3

Contents

About Your Computer. . . . . . . . . . . . . . . . . . . . . . . . 5

Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Back View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Turn Off Your Computer and Connected Devices . . . . . . 7

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . 8

Working Inside Your Computer . . . . . . . . . . . . . . . . 9

System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Entering System Setup. . . . . . . . . . . . . . . . . . . . . . 10

Boot Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Flashing the BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Contacting Alienware . . . . . . . . . . . . . . . . . . . . . . . 18

Websites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

book.book Page 3 Monday, November 18, 2013 3:50 PM

4| Contents

book.book Page 4 Monday, November 18, 2013 3:50 PM

About Your Computer | 5

About Your Computer

Front View

NOTE: Your Alienware X51 R2 computer supports dual orientation. You can place

your computer vertically or horizontally. The rotatable AlienHead allows you to

change the direction of the AlienHead depending on the orientation of your

computer.

1 power button 2 optical-drive eject button

3 optical drive 4 rotatable AlienHead

5 microphone port 6 headphone port

7 USB 3.0 ports (2)

book.book Page 5 Monday, November 18, 2013 3:50 PM

6| About Your Computer

Back View

Specifications

For detailed information regarding the configuration of your computer, see Specifications

at dell.com/support.

1 optical S/PDIF port 2 USB 3.0 ports (2)

3 USB 2.0 ports (2) 4 rear L/R surround port

5 side L/R surround port 6 microphone port

7 hard-drive activity light 8 label tab

9 power adapter port 10 HDMI port

11 discrete graphics card 12 line-out port

13 line-in port 14 center/subwoofer LFE port

15 security-cable slot 16 USB 3.0 ports (2)

17 network port and network lights 18 coaxial S/PDIF port

514

book.book Page 6 Monday, November 18, 2013 3:50 PM

Before You Begin | 7

Before You Begin

Turn Off Your Computer and Connected

Devices

CAUTION: To avoid losing data, save and close all open files and exit

all open programs before you turn off your computer.

1Save and close all open files and exit all open programs.

2Access the Settings charm in the Charms sidebar. Tap or click Power and then

choose Shut Down.

Microsoft Windows shuts down and then the computer turns off.

NOTE: If you are using a different operating system, see the documentation

of your operating system for shut-down instructions.

3Disconnect your computer and all attached devices from their electrical outlets.

4Disconnect all telephone cables, network cables, and attached devices from your

computer.

5Press and hold the power button while the computer is unplugged to ground the

system board.

book.book Page 7 Monday, November 18, 2013 3:50 PM

8| Before You Begin

Safety Instructions

Use the following safety guidelines to help protect your computer from potential damage

and to help ensure your personal safety.

WARNING: Before you begin, read the safety information that

shipped with your computer. For more safety best practices

information, see the Regulatory Compliance Homepage at

dell.com/regulatory_compliance.

WARNING: Only a certified service technician is authorized to

remove the computer cover and access any of the components

inside.

CAUTION: To avoid damaging the computer, ensure that the work

surface is flat and clean.

CAUTION: When you disconnect a cable, pull on its connector or on

its pull-tab, not on the cable itself. Some cables have connectors with

locking tabs or thumb-screws that you must disengage before

disconnecting the cable. When disconnecting cables, keep them

evenly aligned to avoid bending any connector pins. When

connecting cables, ensure that the connectors and ports are

correctly oriented and aligned.

CAUTION: To disconnect a network cable, first unplug the cable from

your computer and then unplug the cable from the network device.

NOTE: Ensure that you remove the security cable from the security-cable slot,

if applicable.

book.book Page 8 Monday, November 18, 2013 3:50 PM

Working Inside Your Computer | 9

Working Inside Your Computer

WARNING: Only a certified service technician is authorized to

remove the computer cover and access any of the components inside

the computer.

For information on removing and replacing the internal component of your computer,

contact Alienware. See "Contacting Alienware" on page 18.

book.book Page 9 Monday, November 18, 2013 3:50 PM

10 | System Setup

System Setup

Overview

Use the system setup to:

•get information about the hardware installed in your computer, such as the amount

of RAM, the size of the hard drive, and so on

•change the system configuration information

•set or change a user-selectable option, such as user password, type of hard drive

installed, enabling or disabling base devices, and so on

CAUTION: Unless you are an expert computer user, do not change

the settings for this program. Certain changes can make your

computer work incorrectly.

NOTE: Before you change system setup, it is recommended that you note the

system-setup screen information for future reference.

Entering System Setup

1Turn on (or restart) your computer.

2During POST, when the Alienware logo is displayed, watch for the F2 prompt to

appear and then press <F2> immediately.

NOTE: The F2 prompt indicates that the keyboard has initialized. This prompt

can appear very quickly, so you must watch for it, and then press <F2>. If you

press <F2> before the F2 prompt, this keystroke is lost. If you wait too long and

the operating system logo appears, continue to wait until you see the Microsoft

Windows desktop. Then, turn off your computer and try again. See "Turn Off Your

Computer and Connected Devices" on page 7.

System Setup Screens

The system setup screen displays current or changeable configuration information for

your computer. Information on the screen is divided into three areas: the Setup Item,

active Help Screen, and Key Functions.

book.book Page 10 Monday, November 18, 2013 3:50 PM
