ALDI WORKZONE TITANIUM+ PLASMA 35 Manual de usuario
IMPORTANT:
Read carefully before use
Keep for future reference
YEAR WARRANTY
AUS
AFTER SALES SUPPORT
1300 777 137
3
Instruction
Manual
35 AMPS
PLASMA CUTTER
MODEL: PLASMA 35 PRODUCT CODE: 60485 04/2018 Version number：001
Contents
1 INTENDED USE .............................................................................................
2 PARTS DESCRIPTION ..................................................................................
3 PACKAGE CONTENT LIST ...........................................................................
4 SYMBOLS ......................................................................................................
5 GENERAL SAFETY WARNINGS ..................................................................
6 RATING PLATE..............................................................................................
7 OPERATION ..................................................................................................
8 CLEANING, MAINTENANCE AND STORAGE .............................................
9 DISPOSAL .....................................................................................................
10 TROUBLESHOOTING ...................................................................................
11 TECHNICAL DATA .........................................................................................
12 RESIDUAL RISKS..........................................................................................
3
3
4
6
7
13
14
18
20
21
23
23
PLASMA CUTTER
31300 777 137 [email protected]
AUS
AFTER SALES SUPPORT PLASMA 35 60485 04/2018
1. INTENDED USE
This unit is a contact type plasma cutter with high frequency start. This
means that the tip of the torch MUST be in contact with the job before
the plasma arc will strike. It does NOT have pilot arc system. It is designed
to be used in conjunction with a suitable air compressor/ air supply
to cut low carbon steel, stainless steel, high strength steel, alloy steel
and other non-ferrous metals. This product is intended for domestic
DIY use only, and is not intended for commercial, industrial or trade
use. Recommended for use with the ALDI 50L Air Compressor (available
exclusively at ALDI Stores).
2. PARTS IDENTIFICATION
11
10
912
13
Fig.1
INTENDED USE/PARTS DESCRIPTION
1
8
7
6
5
4
2
3
PLASMA CUTTER
4
AUS
AFTER SALES SUPPORT PLASMA 35 60485 04/2018
1. Carry handle
2. Air pressure gauge
3. Over temperature lamp
4. Current adjustment control
5. Air pressure regulator
6. Earth connector
7. Plasma torch switch connector
8. Plasma torch connector
9. Power ON/OFF switch
10. Compressed air input
11. Water drain
12. Plasma torch assembly
13. Earth clamp and cable assembly
3. PACKAGE CONTENTS LIST
A
BC
PACKAGE CONTENT LIST
PLASMA CUTTER
51300 777 137 [email protected]
AUS
AFTER SALES SUPPORT PLASMA 35 60485 04/2018
A. 1 x Plasma cutter
B. 1 x PT-31 Plasma torch assembly
C. 1 x Earth clamp assembly
D. 1 x Instruction manual
E. 1 x Warranty card
WARNING! Danger of suffocating! Packing materials are not toys!
Children must not play with plastic bags!
IF ANY PARTS ARE MISSING OR DAMAGED,
PLEASE CONTACT ACTION SPARES 1300 777 137
Recycle/dispose of packaging materials in accordance to the
regulations and requirements of your local council.
PACKAGE CONTENT LIST
PLASMA CUTTER
6
AUS
AFTER SALES SUPPORT PLASMA 35 60485 04/2018
4. SYMBOLS
Symbols are used in this manual and/or on the product to attract your attention
to possible risks. These symbols and the explanations that accompany them
must be understood.
Warning/Caution. Risk of fire.
Read instruction
manual.
Australian regulatory
compliance mark
Risk of toxic fumes Risk of electric shock
Risk of Ultra Violet
radiation.
Keep bystanders away
15m
Wear welding gloves. Keep dry
SYMBOLS
PLASMA CUTTER
71300 777 137 [email protected]
AUS
AFTER SALES SUPPORT PLASMA 35 60485 04/2018
5. SAFETY WARNINGS
WARNING! READ AND UNDERSTAND ALL
INSTRUCTIONS. Failure to follow all instructions
listed below, may result in electric shock, fire and/
or serious personal injury.
5.1 GENERAL
The user of this plasma cutter is responsible for his own
safety and the safety of others. It is most important to read,
learn and respect the rules in this user guide.
When using this plasma cutter, basic safety precautions,
including the following, should be followed to reduce the risk
of fire, electric shock and personal injury. Make sure that you
have read all of these instructions before using this plasma
cutter. Keep this booklet in a safe place for future reference.
Persons who are not familiar with this booklet should not
use the plasma cutter.
5.2 TRAINING
The operator should be properly trained to use the plasma
cutter safely and should be informed about the risks relating
to cutting procedures. This manual does not attempt to cover
cutting technique. Training should be sought from qualified/
experienced personnel.
5.3 SERIOUS FIRE RISK
The cutting process produces sparks, droplets of fused metal,
metal projectiles and fumes. This constitutes a serious fire
GENERAL SAFETY WARNINGS
PLASMA CUTTER
8
AUS
AFTER SALES SUPPORT PLASMA 35 60485 04/2018
risk. Make sure that the area around the work piece is clear
of all inflammable materials. It is advisable to have a fire
extinguisher to hand.
5.4 WORK AREA
Ensure a clear work area with unrestricted movement for the
operator. Always maintain easy access to the On/Off switch
and the mains supply.
5.5 THE WORK PIECE
The work piece will remain at a high temperature for a
relatively long period. Do not touch the weld or the work
piece unless you are wearing welding gloves. Always use
pliers or tongs. Never touch the welded material with bare
hands until it has been allowed to cool.
5.6 WORK SURFACES
Do not cut containers or pipes that hold, or have held,
flammable liquids or combustible gases.
Do not coated, painted or varnished surfaces as the coatings
may ignite and or can give off dangerous fumes.
5.7 VENTILATE THE WORK AREA
Plasma cutting emits fumes which can be dangerous. Make
sure that the work area is well ventilated.
5.8 AVOID ELECTRICAL CONTACT
Use adequate electrical insulation with regard to the
electrode, the work piece and any accessible earthed metal
GENERAL SAFETY WARNINGS
PLASMA CUTTER
91300 777 137 [email protected]
AUS
AFTER SALES SUPPORT PLASMA 35 60485 04/2018
parts in the vicinity. Avoid direct contact with the welding
circuit. The no load voltage between the earth clamp and the
torch can be dangerous under certain circumstances.
5.9 FOR ADDITIONAL PROTECTION FROM ELECTRIC SHOCK
It is recommended that this tool be used in conjunction with
a residual current device (RCD) with a rated residual current
of 30mA or less.
5.10 CONSIDER WORK AREA ENVIRONMENT
Do not expose the plasma cutter to rain. Do not use it in
damp, or wet locations. Keep the work area well lit.
5.11 DRESS PROPERLY
Use protective gloves and fire resistant protective clothing
and footwear when using the cutter. Avoid exposing skin to
the ultraviolet rays produced by the arc.
5.12 ALWAYS USE THE WELDING MASK
Under no circumstances should the cutter be operated unless
the welding mask is protecting the eyes and face. There is a
serious risk of eye damage if the mask is not used. The sparks
and metal projectiles can cause serious damage to the eyes
and face.
The light radiation produced by the arc can cause damage to
eyesight and burns on the skin. Never remove the welding
mask whilst cutting. Move the torch away from the work
piece and release the trigger switch before removing the
welding mask.
GENERAL SAFETY WARNINGS
PLASMA CUTTER
10
AUS
AFTER SALES SUPPORT PLASMA 35 60485 04/2018
5.13 SAFETY GLASSES
After cutting use safety glasses when brushing, chipping
grinding the slag from the cut.
5.14 OTHER PERSONS
Ensure that other persons are screened from the welding arc
and are at least 15 metres away from the work piece. Always
ensure that the welding arc is screened from onlookers,
or people just passing by. Use screens if necessary, or non
reflecting curtains.
5.15 KEEP CHILDREN AND ANIMALS AWAY
Do not let children or animals have access to the cutting
equipment or to the work area.
5.16 SWITCHING OFF
When you have finished cutting switch off the plasma cutter.
Do not put the torch down with the plasma cutter switch On.
When leaving the plasma cutter unattended, move the On/
Off switch to the Off position and disconnect it from the mains
supply. Do not leave hot material unattended after cutting
5.17 CABLES
Keep the cables, earth clamp and torch in good condition.
Failure to can result in a poor cut and damage to the cutting
torch.
5.18 CHECK DAMAGED PARTS
Before further use of the plasma, any part that is damaged
should be carefully checked to determine that it will operate
GENERAL SAFETY WARNINGS
