TABLE OF CONTENTS

Support..................................................................... 1

Service Activation.................................................... 2

Phone Overview ...................................................... 3

SIM Card................................................................... 4

Memory Card........................................................... 7

Battery....................................................................... 8

Power ........................................................................ 8

Home Screen........................................................... 9

Calls......................................................................... 12

T-Mobile Name ID .................................................15

Wi-Fi Calling ...........................................................15

Tethering & Mobile Hotspot ................................17

Accessing Files......................................................18

Voicemail ...............................................................19

Visual Voicemail ....................................................19

Volume & Ringtone ...............................................20

Contacts .................................................................21

Email .......................................................................22

Text Entry................................................................23

Text Messaging .....................................................25

Web Browsing .......................................................28

Bluetooth®.............................................................29

Battery & Memory Management.........................30

Protect Your Phone...............................................32

Accessories............................................................36

Caring For Your Phone.........................................37

Approved Firmware Versions..............................38

Safety Tips..............................................................38

Emergency Dialing................................................41

Additional Information..........................................42

TCL Communications Ltd. Warranty..................45

Safety and Use.......................................................48

SERVICE ACTIVATION

If you are a new T-Mobile®customer

and your service has not yet been

activated, simply call Customer Care at

1-800-937-8997 and a T-Mobile Activations

representative will assist you.

You will need the following information

when activating service:

nYour Service Agreement and the

agent code on your Agreement

nYour name, home address, home

phone number, and billing address

Note: For business and government accounts,

please provide the organization’s name,

address, and tax ID.

nYour Social Security number, current

driver’s license number, and date of

birth for credit check purposes

nYour choice of T-Mobile rate plan and

services (see www.t-mobile.com

for latest plan information)

nYour SIM serial number and IMEI number

(located on the box barcode label)

By activating service, you acknowledge that you have read,

understand, and agree to be bound by each of T-Mobile’s Terms and

Conditions, and by your Service Agreement.

SUPPORT

This guide provides you with the information you

need to get started.

For more information and additional support, please

visit www.t-mobile.com/support where you can:

nRegister at my.t-mobile.com to check

your minutes, pay your bill, upgrade your

phone, and change your rate plan.

nReview your phone’s User Manual

and troubleshooting FAQs.

nView the latest troubleshooting solutions in the

Support Forums or ask a question of your own.

Power key

Volume up

Volume

down

Camera

SIM CARD

The SIM (Subscriber Identity Module) card identifies

your phone to the wireless network. You cannot make

or receive phone calls or browse the Internet without

a properly installed SIM card.

PHONE OVERVIEW

Touch

screen

Back key

Home key

Front

camera

Menu key

Headset connector

Micro-USB Connector

3. Insert SIM card into SIM slot located on right

side of phone. Ensure SIM gold contacts

are facing phone when inserting card.

4. Reattach back cover to phone

and power phone on.

Installing SIM card

1. Detach the SIM card from its packaging.

2. Power off your phone and remove

back cover by pulling cover up.

BATTERY

To optimize battery performance, be sure to fully

charge your phone before using it for the first time.

Charging battery

1. Insert the small end of the charging cable

into the phone micro-USB connector

located on bottom of phone, as shown.

2. Plug the other end of the charging

cable into provided charger, connect

charger to power outlet.

POWER

To turn the power on or off, press and hold the power

key located on right side of phone.

MEMORY CARD

Memory cards add extra storage space for your

music, pictures, videos, and more. This phone uses

a microSD memory card size. Memory card sold

separately.

Installing memory card

Power off your phone, remove back cover by pulling

cover up and remove battery.

2. Locate the microSD card slot located above top

right corner of battery compartment.

3. Insert the microSD card into the microSD slot with

the gold contacts facing downward and gently push

in microSD card until it locks into slot.

4. Reinsert battery into battery compartment until

locked in position, then reattach the battery cover.

109

Status bar

The Status bar appears at the top of your Home

screen. Icons indicating your phone’s status and new

notification alerts appear in the Status bar.

Notifications panel

To open the Notifications panel, touch and drag the

Status bar down.

Applications menu

To access all Applications from the Home screen, tap

the Applications icon .

Swipe left or right through the menu screens to view

all applications. As you download new applications,

they will appear in the Applications menu in

alphabetical order.

HOME SCREEN

You can bring all the items (applications, shortcuts,

folders and widgets) you love or use most frequently

to your Home screen for quick access. Touch the

Home key to get instant access to the Home screen.

Status bar

• Status/Notification indicators

•

Touch and drag down to open

the notifications panel.

Applications icon

•

Touch to open applications menu.

Search bar

• Touch to enter text

search screen.

• Touch to enter voice

search screen.



Favorite applications tray

•

Touch to enter the applications.

•

Touch and hold to move or

change applications.

Swipe main home screen left and right

to view additional home screens.

Home screen is provided in an extended format to

allow more space for adding applications, shortcuts

etc. Slide all Home screens horizontally left and right

to get a complete view of the Home screens. The

white squares at the lower part of the screen indicate

which screen you are viewing.

Add additional home screens by touching Menu key

and selecting Manage Home Screens.

1211

CALLS

Placing a call

You can easily launch a call using Phone. Touch

from Favorite applications tray or from Applications

menu.

Touch and

hold to access

voicemail

Touch to hide or

show Keypad

Touch to add

a new contact

to Contacts

Enter the desired number directly into Keypad, then

touch to place call. If you make a mistake, you can

delete the incorrect digit(s) by touching .

To select phone number from contacts list, touch

Contacts tab and select preferred contact, then

touch next to preferred contact number to place

call.

Unlock the screen

Press the Power key once to light up the screen, slide

the screen to the right, draw the unlock pattern you

have created or enter PIN or password to unlock the

screen.

Add items to the Home screen

1. Swipe left or right to the desired Home screen.

2. Tap the Applications icon to access the

Applications menu.

3. Touch and hold the desired item, and then drag it

to a blank area on the Home screen.

Move and delete items

Touch and hold the item you want to move or delete

and then drag it to another location or to the Trash

can icon at the top of the screen.

Change Home screen wallpaper

1. Touch Menu key on the Home screen , then select

Wallpaper.

2. Tap Gallery, Homescreen wallpapers, Live

wallpapers,Lock screen wallpapers or Photos.

3. Tap the desired image.

4. Touch Set Wallpaper. If a picture is selected from

Gallery, you will be prompted to crop picture, once

cropping is complete select OK to set as wallpaper.

1413

Answering or rejecting a call

When you receive a call, touch and hold .

• Slide to green icon rightward to answer;

• Slide to red icon leftward to reject;

• Slide to icon upward to reject a call and send a

preset text message.

To mute incoming calls, press the Volume up/down

key or make the phone facing down.

To hang up a call, touch end call icon.

To save a phone number that has been recently

dialed, touch the default image by phone number

record. You will be prompted to “Add to contacts?”

select OK and then touch CREATE NEW CONTACT

at bottom of screen.

International call

To dial an international call, touch and hold to enter

“+”, then enter the international country prefix followed

by the full phone number and finally touch .

Emergency call

If your phone has network coverage, dial emergency

number and touch to make an emergency call.

This works even without a SIM card and without

typing the PIN code.

1615

To enable Wi-Fi Calling

1. From the Home screen, touch

Applications icon .

2. Select Settings , then More….

3. Toggle Wi-Fi Calling button to right On

position, bar will light up in yellow.

To disable Wi-Fi Calling

1. From the Home screen, touch

Applications icon .

2. Select Settings , then More….

3. Toggle Wi-Fi Calling button to left Off

position, bar will display in gray.

To change the connection preference for

Wi-Fi Calling

1 From the Home screen, touch

Applications icon .

2. Select Settings , then More….

3 Select Wi-Fi Calling, then select

Connection Preferences.

T-MOBILE NAME ID

T-Mobile Name ID identifies callers, displaying Name,

City and State even if the caller is not in your contacts

list. It is an optional add-on feature that can be

purchased directly from your phone for an additional

monthly charge. A one time 10 day trial is included

with the phone.

1. From the Applications menu, tap .

2. Choose an on-screen option.

WI-FI CALLING

Wi-Fi Calling can improve your coverage and allows

you to make phone calls and send messages over

a Wi-Fi network (when a Wi-Fi network is available).

Please check your rate plan to determine if Wi-Fi

Calling minutes count towards your cellular calling

minutes or not. To use Wi-Fi Calling please use the

SIM card shipped with your device. A different SIM

card may not work with the Wi-Fi Calling feature. You

must have a 911 emergency address registered with

your account. Log into your account at www.t-mobile.

com. Go to your profile and click Customer Info to

Please note: Corporate accounts may require

administrator assistance for 911 Address.

Tabla de contenidos

Otros manuales de Teléfono móvil de Alcatel

Alcatel

Alcatel OT-255P Manual de usuario

Alcatel

Alcatel U3 Manual de usuario

Alcatel

Alcatel onetouch 4033X Manual de usuario

Alcatel

Alcatel TracFone OneTouch POP ICON LTE 2 Manual de usuario

Alcatel

Alcatel ONETOUCH 5020W Manual de usuario

Alcatel

Alcatel ONE TOUCH 8020X Manual de usuario

Alcatel

Alcatel Glam Elle 3 Manual de usuario

Alcatel

Alcatel A3 Manual de usuario

Alcatel

Alcatel One Touch 992D Instrucciones de funcionamiento

Alcatel

Alcatel OT-356C Manual de usuario

Alcatel

Alcatel OT-E805C Manual de usuario

Alcatel

Alcatel 5036D Manual de usuario

Alcatel

Alcatel One Touch 282 Manual de usuario

Alcatel

Alcatel GO FLIP V Manual de usuario

Alcatel

Alcatel OneTouch 5035A Manual de usuario

Alcatel

Alcatel Pop S7 704SY Manual de usuario

Alcatel

Alcatel One Touch 985D Smart Manual de usuario

Alcatel

Alcatel One Touch Pop 4007A Manual de usuario

Alcatel

Alcatel 1S: S 6025D Manual de usuario

Alcatel

Alcatel onetouch 117 Manual de usuario

Alcatel

Alcatel 5017W Manual de usuario

Alcatel

Alcatel Premium Reflexes OmniPCX 4400 Manual de usuario

Alcatel

Alcatel 585A Manual de usuario

Alcatel

Alcatel OneTouch 30.22G Manual de usuario

Manuales populares de Teléfono móvil de otras marcas

Zte

Zte BLADE A520 Manual de usuario

Nokia

Nokia Lumia 620 Manual de usuario

Blackbe;rry

Blackbe;rry KEYone Manual de usuario

Bea-fon

Bea-fon X5 Premium Manual de usuario

Blackbe;rry

Blackbe;rry 8707 Series Manual de usuario

Blackbe;rry

Blackbe;rry Storm Instrucciones de funcionamiento

LG LM-X420QN Manual de usuario

LifeWatch

LifeWatch V Manual de usuario

Bea-fon

Bea-fon SILVER LINE SL860 Manual de usuario

IKI Mobile

IKI Mobile KF4.5i Manual de usuario

Hitech

Hitech HT-850 Manual de usuario

Yezz

Yezz Fashion F10 Manual de usuario

Point Mobile

Point Mobile PM60 Manual de usuario

Blackbe;rry

Blackbe;rry Q10 Manual de usuario

Blackbe;rry

Blackbe;rry Bold 9900 Manual de usuario

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manual de usuario

LG LM-K420EMW Manual de usuario

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manual de usuario

Alcatel onetouch Pop Astro Guía

Manuales populares de Teléfono móvil de otras marcas
