Alcatel-Lucent

1677 SONET Link

NEXT-GENERATION MULTISERVICE PLATFORM

Never before have businesses been under such pressure

to provide and support multiple high-bandwidth services

while continuing to support traditional revenue-generating

services. The Alcatel-Lucent 1677 SONET Link provides the

means to maximize bandwidth availability and to ﬁll that

bandwidth effectively.

Businesses have invested billions of dollars

in their SONET network infrastructures,

their operations systems, and the personnel

to run and maintain them. Customers,

both consumers and businesses, are now

demanding more services, more versatility

and more bandwidth, and these demands

are expected to continue to rise over the

next few years. Consequently, SONET

equipment is still called on to provide

transport for new and existing services.

Pressure for revenue growth means

that services must be deployed in the

here and now, without dramatic changes

to the network topology or to operational

methods. To fully use and expand the

capabilities of SONET, next-generation

transport solutions must be able to

aggregate disparate native channels at

differing bit rates, groom these signals

seamlessly, and then efﬁciently ﬁll the

transport “pipes”.

The Alcatel-Lucent 1677 SONET

Link (SL) fulﬁlls these requirements

by combining the functions of legacy

SONET add/drop multiplexers (ADMs),

the bandwidth-grooming capability of

narrowband, wideband and broadband

digital cross-connects, and the optical

ﬁber-sharing of dense wavelength division

multiplexing (DWDM). The Alcatel-Lucent

1677 SL offers best-in-class port densities

combined with the scalability that is

necessary for gradually adding more

services. What’s more, this class-leading

feature set comes at a realistic price.

YOUR NEEDS

Most operators have sufﬁcient ﬁber in the

ground to support current and near-future

needs, provided that the ﬁber is used

effectively. In situations in which more

bandwidth is needed, they know that Alcatel-

Lucent has a full range of state-of-the-art

active and passive coarse wavelength

division multiplexing (CWDM) and DWDM

devices. What operators want is a network

element (NE) that leverages the existing

network, offers data and other services

via this network, and grooms signals at

the network edge. The NE must produce

substantial cost savings over incumbent

equipment by providing signiﬁcantly

increased switching capacity and port

density, while at the same time controlling

heat output and power usage.

ALCATEL-LUCENT >1

Meeting Expanding Demands

Working with SONET

Alcatel-Lucent 1677 SONET Link

YOUR BENEFIT

The Alcatel-Lucent 1677 SL offers SONET add/drop multiplexing, narrowband,

wideband and broadband cross-connect functionality, plus DWDM. It supports a broad

range of service interfaces and service features, such as virtual concatenation (VCAT),

Gigabit Ethernet broadcasting, section, line and path performance monitoring right

down to the DS1/DS3 level, and DS0 grooming. The Alcatel-Lucent 1677 SL offers a

class-leading 1536 x 1536 synchronous transport signal level 1 (STS-1) fabric as well

as second-to-none port density and switch density. The universal I/O is not constrained

by line or tributary restrictions, and fully redundant common control and switching

modules ensure quality of service (QoS) at the ﬁve nines standard or better.

Benefit Feature Function

Pay-as-you-grow Class-leading scalability Support for interfaces from DS1 to OC-192, Fast Ethernet and Gigabit Ethernet,

allowing a wide range of applications from a single platform.

Reduced real estate Superior density 24 half-height universal interface cards; 2 chassis per 7-foot rack.

Example: 840 DS1 per rack. Multi-ring architecture.

Reduced OPEX Less space required, less power, less heat Multifunctionality of slots; modern component design.

Quality of service 99.999% reliability Fully redundant common control and switching elements, NEBS Level 3-certified.

Interoperability Industry-standard interface management Open architecture for integration in any OSS.

Efficient transportGrooming Modular design, allowing for optimal grooming based on the application:

STS, VT1.5, transmultiplexer and Gigabit Ethernet.

Efficient management Available Alcatel-Lucent 1353 NM element manager Ring management, configuration discovery, alarm and topological views provided

for multiservice transport networks by a user-friendly GUI.

2<ALCATEL-LUCENT

Legacy equipment makes it difﬁcult for

businesses to scale their networks to meet

ever-changing demands for increased

capacity and new high-bandwidth services.

Upgrading the capacity of a traditional

SONET ring can be a time-consuming

and expensive process, often requiring

the replacement of thousands of dollars’

worth of equipment. Deploying new rings

could be even more complex and difﬁcult

to manage, with even further investment

in additional central ofﬁce equipment to

terminate the ring and to switch trafﬁc

throughout the network.

As a next-generation SONET solution,

the Alcatel-Lucent 1677 SL eliminates

scaling-limitation issues and additional

ring-upgrade complexity. The Alcatel-

Lucent 1677 SL provides for future expan-

sion as bandwidth needs grow within

metropolitan and regional networks. When

a new service offering is created, Alcatel-

Lucent clients can increase support for

hundreds of subtended rings from the

same NE and from a variety of interfaces,

to support the myriad offerings that they

will want to provide.

The ability to grow networks with

an installed base of equipment provides

businesses with rapid returns on their

investments and saves operational and

engineering expenses. Key functionality,

such as OC-192, VT1.5 grooming and

transmultiplexer support, allows Alcatel-

Lucent clients to get ahead of their

competition when rolling out next-

generation services. On-board, point-to-

point DS0 grooming eliminates the need

for a second NE or for inter-machine

trunks. No competitor’s solution beats

the Alcatel-Lucent 1677 SL for integrated

functionality.

Scalability for Increasing Capacity

BANDWIDTH MANAGEMENT

Successful businesses efﬁciently manage bandwidth and network resources.

As large metropolitan and regional networks evolve to support hundreds

of rings and terabytes of capacity in a region, it is imperative that they

have the power and ﬂexibility to switch and groom end-customer services

in the most resource-efﬁcient way possible. This means taking small,

disparate feeds that are currently transported inefﬁciently and combining

them into appropriately sized trunks to maximize return on investment.

The Alcatel-Lucent 1677 SL grooms trafﬁc by taking circuits from

multiple interfaces and switching them onto one pipe for transport across

the network. The Alcatel-Lucent 1677 SL supports STS-n (n = 1 to 48c)

grooming to make the most efﬁcient use of the carrier’s network infra-

structure (see Figure 1). Additionally, two optional modules provide DS0

and VT1.5 switching capability, allowing ﬁne-grain bandwidth manage-

ment. Full-featured wideband and narrowband grooming are also possible

with this modest-sized platform using the transmultiplexing card, and

carriers may deploy this capability as needed.

In contrast to the traditional centralized model, the multi-ring termina-

tion and bandwidth-grooming capabilities of the Alcatel-Lucent 1677 SL

ﬁt the emerging optical network model that disperses bandwidth manage-

ment to the edge of the network.

1.5

STS-n Matrix

STS-1

Figure 1 - Bandwidth Grooming

ALCATEL-LUCENT >3

INTEROPERABILITY

As businesses roll out new network equip-

ment, this equipment must be integrated

into their back-ofﬁce environments and

under their operations support systems

(OSSs), which provide provisioning,

monitoring and management of multiple

vendors’ NEs. Hence, the network manage-

ment architecture must provide standard,

user-friendly, open interfaces to allow

other third-party vendors to pick up sup-

port for the product. This enables them to

provide comprehensive management such

as end-to-end provisioning and monitoring

across multiple NEs. The Alcatel-Lucent

1677 SL is designed with the goal of

deployment in a carrier-class environment

and includes development for open inter-

faces for OSS integration. The Alcatel-

Lucent 1677 SL supports interworking

standards such as open systems inter-

connection (OSI) and target ID address

resolution protocol (TARP), and these

allow integration with other vendors’

systems.

MULTIFUNCTIONALITY

Any new capital expenditure must be

justiﬁed by increased revenues and prof-

itability, and the Alcatel-Lucent 1677 SL

provides these beneﬁts. For example, its

multi-ring feature allows numerous users

and circuits to be supported on one NE,

thus eliminating the need for multiple NEs

(see Figure 2). This decrease in equipment

use results in an immediate reduction

in CAPEX, followed by ongoing savings

in OPEX.

In addition to the valuable protection

and restoration capabilities of SONET, the

Alcatel-Lucent 1677 SL offers businesses

the opportunity to deliver Gigabit Ethernet

services. The Gigabit Ethernet interface

of the Alcatel-Lucent 1677 SL makes use

of leading-edge technology to permit the

transport of data services over the existing

SONET infrastructure. This capability

enables new revenue sources in return

for compellingly low deployment costs.

Alcatel-Lucent was one of the ﬁrst

vendors to support VCAT, the standard

that enables businesses to map Ethernet

4<ALCATEL-LUCENT

OC-48 UPSR

OC-48

UPSR

OC-12

UPSR

OC-192

UPSR

OC-192 BLSR

Figure 2 - Multi-Ring Capability

directly onto a SONET network (see

Figure 3). VCAT enables these operators

to offer low-cost Ethernet services, while

maintaining all the beneﬁts of SONET

networking and without requiring drastic

changes to the network infrastructure

or operational systems.

GOING FROM STRENGTH TO STRENGTH

Alcatel-Lucent continues to invest heavily

in the development of the 1677 SL, winning

industry interest and customer satisfaction.

Recently added functionality includes

Gigabit Ethernet broadcast, dual-ring

interconnection, transmultiplexing without

the need for a vertical switch controller

(VSC), DS1 management integration, and

DS0 grooming. More is on the way for this

exceptionally ﬂexible and upgradeable

solution.

KEY ALCATEL-LUCENT 1677 SL FEATURES

> Interfaces: DS1, DS3, OC-3, OC-12,

OC-48, OC-192

>Ring APS: 1+1 uni/bidirectional,

UPSR, BLSR 2F, unprotected

> STS-n grooming (80 Gb/s)

>VT1.5 grooming (10 Gb/s)

> DS0 grooming (2.5 Gb/s)

> Transmultiplexing (5 Gb/s)

ALCATEL-LUCENT >5

Ethernet

Streams

SONET

STS-1s

VC Group

STS-1... Xv

Figure 3 - Ethernet Signals are mapped into

SONET and then virtually concatenated

THE ALCATEL-LUCENT ADVANTAGE

Alcatel-Lucent is in the best position to help

service providers achieve network optimization

by converging disparate services into one

network to offer triple play services.

Alcatel-Lucent is the world leader in the design

and supply of future-safe, next-generation

digital cross-connects and multiservice

platforms. Our transport solutions offer the

versatility and scalability that have become

the mainstays of successful service providers

the world over.

Moreover, Alcatel-Lucent is in the enviable

position of offering customers the best

expertise, service and support available.

www.alcatel-lucent.com

Alcatel, Lucent, Alcatel-Lucent and the Alcatel-Lucent logo are trademarks of Alcatel-Lucent.

All other trademarks are the property of their respective owners.

Alcatel-Lucent assumes no responsibility for the accuracy of the information presented, which is subject to change without notice.

Otros manuales para 1677 SONET Link

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de red de Alcatel-Lucent

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7302 Guía de instalación

Alcatel-Lucent

Alcatel-Lucent OAW-AP85 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent Rainbow Office Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 100 GbE Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7330 Manual de instalación y operación

Alcatel-Lucent

Alcatel-Lucent 1353 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent OmniVista 4760 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent Metrospan Edge 1692 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent Litespan 1540 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent VitalQIP AMS 1000 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent OmniAccess 700 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent Service Aggregation Router 7705 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent Network Device K-12 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent VitalQIP Appliance Manager 5000 Platform Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7302 Manual técnico

Alcatel-Lucent

Alcatel-Lucent Broadband 700 MHz Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7342 ISAM FTTU Manual de usuario

Alcatel-Lucent

Alcatel-Lucent Intelligent Services Access Manager Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 9364 Guía

Alcatel-Lucent

Alcatel-Lucent 9764 Series Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5580 Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario

Lanner

Lanner NCA-1525 Manual de usuario
