Alcatel-Lucent 1643 AMS Manual de usuario

Alcatel-Lucent

1643 AMS Access

Multiplexer Small

Cost-effective STM-1

multiservice metro access

Alcatel-Lucent 1643 AMS Access Multiplexer Small2

The Alcatel-Lucent 1643 Access Multiplexer Small

(AMS) is a compact multiservice provisioning

platform (MSPP) that allows service providers

to deliver new services to small and medium

enterprises (SME). Delivering cost-effective,

multiservice access, the 1643 AMS adds Ethernet to

traditional TDM and SDH networks, eliminating the

need for overlay equipment. Extending networks

to the customer premises, it is energy efﬁcient and

compact, improving the use of space and reducing

operating expenditures (OPEX) while offering

enhanced revenue-generating potential.

Alcatel-Lucent 1643 AMS Access Multiplexer Small2

Alcatel-Lucent 1643 AMS Access Multiplexer Small 3

New services, such as triple play and

business Ethernet, are placing great

demands on the existing transport

infrastructure. To be proﬁtable, service

providers must reduce OPEX while

meeting SME demands by offering a

host of revenue-generating Internet

Protocol (IP) and Ethernet services.

At the same time, they must avoid

the complexity and expense of over-

lay networks.

The Alcatel-Lucent 1643 AMS,

a compact multiservice customer

premises equipment (CPE), econo-

mically transports TDM and Ethernet

services over SDH networks. This

system converges voice and data

trafﬁc, eliminating the need for

overlay networks.

The 1643 AMS efﬁciently delivers

enterprise network services, such as

LAN and Private Branch Exchange

(PBX) interconnection over ﬁber,

all services where high performance

and reliability are essential attributes.

Used for interofﬁce applications in

both access and mobile networks, it

facilitates LAN-to-LAN communica-

tions on campus and virtual private

networks (VPNs). The 1643 AMS

has the ﬂexibility to function in diverse

local-loop environments, supporting

various ring conﬁgurations for ﬁber-

to-the-business or -home (FTTB or

FTTH) applications.

Meeting enterprise demands

Beneﬁts

• Offers a cost-effective multiservice access platform for SME customers

• Increases revenue potential while reducing OPEX

• Extends Ethernet service to the customer premises over SDH facilities

• Delivers a wide range of installation options

• Offers versatile and robust management capabilities and network protection

• Supports ber and copper access for SDH, TDM and Ethernet trafc

through both optical and electrical interfaces

Alcatel-Lucent 1643 AMS Access Multiplexer Small4

Enhanced revenue potential,

reduced expenses

The 1643 AMS system enhances

service-provider revenue-generating

opportunities by delivering services

such as IP transport, Ethernet Layer

2 VPN and TDM. It decreases OPEX

through efﬁcient use of space in

tight environments and low power

consumption.

Extended Ethernet services

When deploying the optional

Alcatel-Lucent Tr a n s L A N ®Cards,

the 1643 AMS delivers a diverse

mix of standardized Ethernet

services. Depending on the Tra n s -

LAN Card selected, the 1643 AMS

provides numerous capabilities:

• Full Layer 2 switching functional-

ity: point-to-point and point-to-

multipoint

• Virtual concatenation (VCAT) and

generic framing procedure (GFP)

• Link capacity adjustment scheme

(LCAS)

• International Electotechnical

Commission (IEEE) 802.1Q and

802.1ad virtual local area network

(VLAN) tagging

• VLAN trunking, saving physical

interfaces at hub locations

As shown in Figure 1, the 1643 AMS

supports cost-efﬁcient and reliable

multiservice transport for metro

access. It can be deployed with other

SDH platforms, such as the Alcatel-

Lucent 1645 AMC, for aggregation

to higher speed networks.

Figure 1. 1643 AMC supporting a typical metro-access application

STM-4

1350 OMS

10/100/1000

Ethernet

10/100/1000

Ethernet

10/100/1000

Ethernet

10/100/1000

Ethernet

STM-1

STM-4

E1, E3, DS3,

STM-1 E1, E3, DS3,

STM-1

10/100/1000

Ethernet

E1, E3, DS3

SDH

(STM-16/64)

1850 TSS

16XX OMSN

1643 AMS 1645 AMC ATM

switch

RouterPABX

Versatile and robust

management capabilities

As part of the Alcatel-Lucent optical

portfolio, the 1643 AMS is supported

by the Alcatel-Lucent 1350 Optical

Management System (OMS), a

flexible network management

package customized to meet speciﬁc

operational needs. With OMS, the

1643 AMS is managed through an

embedded communications channel.

The 1643 AMS also supports a PC-

based craft interface for local and

remote management and low-cost

centralized alarming. In addition,

the 1643 AMS can be integrated into

Simple Network Management Protocol

(SNMP) management systems.

The 1643 AMS derives fault-manage-

ment information by monitoring and

analyzing information contained in

the path overhead of each virtual

container (VC). Alarm information

is ﬁltered and displayed locally, and

transmitted to the management-

center database.

Performance-management infor-

mation from the overhead bytes is

analyzed and stored in the database

of the 1643 AMS. When equipped

with a Tr a n s L A N Card, the 1643

AMS stores Ethernet-speciﬁc per-

formance information. This feature

facilitates quick turnaround for

physical-configuration changes.

For data communication networks

(DCNs), the 1643 AMS offers several

data communication channel (DCC)

functions, providing multivendor

interworking opportunities.

The 1643 AMS is a compact and

cost-effective multiservice unit that

enables next-generation services over

existing SDH networks.

Wide range of installation

options

The 1643 AMS is designed for

rack-mounted applications, while

offering both street-cabinet and CPE

installation capabilities. Using either

DC or AC power, it also provides

operating ﬂexibility.

AlcatelvLucent 1643 AMS Access Multiplexer Small 5

1643 AMC

Alcatel-Lucent 1643 AMS Access Multiplexer Small6

Fiber and copper

access options

When ﬁber access is available,

the 1643 AMS is installed directly

as CPE. If the last mile to the

customer premise must be bridged

through copper, the 1643 AMS

provides a symmetric high-speed

digital subscriber line (SHDSL)

option. As a result, E1 over copper

or 10/100BASE-T Ethernet access

through up to four combined SHDSL

copper lines can be served.

The base 1643 AMS conﬁguration

consists of a main board with 16 E1

ports, cages for two Small Form Fac-

tor Pluggables (SFPs) and one option-

board slot. The hot-pluggable SFPs

used in terminal-multiplexer or add/

drop multiplexer (ADM) applications,

are offered in three different types:

• STM-1 optical line interface:

S-1.1, L-1.1, L-1.2 (SFP)

• STM-1 electrical interface

• STM-1 bidirectional

In addition, there is an option board

available to support one of the follow-

ing interface types: E1, DS1, E3, DS3,

SHDSL and 10/100/1000BASE-T and

1000BASE-X Ethernet.

Alcatel-Lucent 1643 AMS Access Multiplexer Small6

Alcatel-Lucent 1643 AMS Access Multiplexer Small 7

Cost-effective

next-generation services

The E1 ports offer an Integrated

Services Digital Network (ISDN)

mode, meeting to G.704 and I.431

speciﬁcations, and they support

retiming mode and frame-slip

control. The system offers ﬂexible

and adaptive bandwidth allocation

by transporting LAN trafﬁc in

VCAT VC-12s or VC-3s.

The 1643 AMS adds Ethernet,

Fast Ethernet (FE) and Gigabit

Ethernet (GigE) transport service

to the existing SDH infrastructure.

A more cost-effective alternative

to separate networks, it converges

voice and data trafﬁc, eliminating

the need for overlay networks and

increasing the network’s revenue-

generating opportunities.

This compact STM-1 multiservice

CPE provides cost-effective next-

generation services to SME custo-

mers and offers a variety of aggregate

interfaces suitable for short-range

or long-range transmission. Its

standards-based approach ensures

rock-solid performance in enterprise

applications where reliability is crucial

for business-critical communications.

The 1643 AMS delivers cross-feature

availability and circuit-pack compat-

ibility with other Alcatel-Lucent

optical products, a very high mean

time between failures (MTBF) rate

and a very low failure rate. Using a

Tr a n s L A N Card to leverage existing

SDH investments, this multiservice

CPE is used for enterprise network

applications with high performance

and reliability requirements. It also

offers a ﬂexible choice of optical and

tributary interfaces.

Key features

• Low-cost multiservice access

over the established SDH base

• Wide range of SFP interface

types: S1.1, L1.1, L1.2, STM-1

bidirectional and STM-1

electrical

• Ethernet, FE and GigE with an

optional TransLAN Card

• Space- and energy-saving

compact design

• VC-12, VC-3 SNC protection

and 1+1 multiplexer section

protection (MSP)

• Orderwire support

• E1/Ethernet over copper

(TU-12) through SHDSL

• Street cabinet or CPE

installation options

• Optional Ethernet Layer 2

switching and aggregation

www.alcatel-lucent.com Alcatel, Lucent, Alcatel-Lucent and the Alcatel-Lucent logo

are trademarks of Alcatel-Lucent. All other trademarks are the property of their respective owners.

The information presented is subject to change without notice. Alcatel-Lucent assumes no responsibility

Alcatel-Lucent delivers end-to-end communi-

cations solutions to service providers and en-

terprises anywhere in the world. Leveraging its

network equipment as well as services, Alcatel-

Lucent facilitates its customers’ service offerings

and revenue streams. As the recognized world

leader in optical networking, Alcatel-Lucent is

in a unique position to help service providers

navigate through current market conditions.

Alcatel-Lucent, with its global reach and scale,

combined with local presence in over 130

countries, makes use of a deep understanding

of global market dynamics, as well as the ability

to anticipate local requirements.

Recognized World Leader

in Optical Networking

Otros manuales para 1643 AMS

Otros manuales de Multiplexor de Alcatel-Lucent

Alcatel-Lucent

Alcatel-Lucent 1655 AMU Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 1660 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 1643 AMS Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7330 Manual de instalación y operación

Alcatel-Lucent

Alcatel-Lucent 1645 AMC Manual de usuario

Alcatel-Lucent

Alcatel-Lucent Data Multiplexer Explore 1665 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent Data Multiplexer Explore 1665 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent Data Multiplexer Explore 1665 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent Data Multiplexer 1665 DMX Manual de usuario

Alcatel-Lucent

Alcatel-Lucent Data Multiplexer Explore 1665 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 1643 AMS Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 1511 BA Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 3600 MainStreet Manual de operación y mantenimiento

Alcatel-Lucent

Alcatel-Lucent 1645 AMC Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 1643 AMS Manual técnico

Alcatel-Lucent

Alcatel-Lucent 1643 AMS Manual de usuario

Manuales populares de Multiplexor de otras marcas

Campbell

Campbell AM416 Manual de usuario

Paradyne

Paradyne SIM2000 Manual de usuario

Panasonic

Panasonic WJFS616 - SWITCHER Manual de usuario

Lanex

Lanex TM-77 Manual de usuario

Bosch

Bosch VSS8394/01T Manual de usuario

Quark-Elec

Quark-Elec QK-A035 Manual de usuario

ADTRAN

ADTRAN Frameport 768 Manual de usuario

Elo TouchSystems

Elo TouchSystems E247 Manual de usuario

Paradyne

Paradyne Hotwire 8786 Manual de usuario

RFL Electronics

RFL Electronics 9508D UCC Manual de usuario

Miranda

Miranda AMX-101i Manual de instrucciones

ShipModul

ShipModul MiniPlex-AIX NMEA-0183 Manual de usuario

GE StoreSafe SDVR-10 Manual de usuario

Pickering

Pickering 40-613 Manual de usuario

Pickering

Pickering 40-667C Manual de usuario

American Fibertek

American Fibertek MTX-8410C Manual de usuario

ADC

ADC HiGain ELU-319 5E Manual de usuario

Paradyne

Paradyne Hotwire 8774 Manual de usuario
