This HOW TO guide is suitable for the AKS 3004 Stabiliser, and is applicable
to both the red (original) and black (new) versions.
HOW TO FIT THE AKS 3004 STABILISER
1 Before starting you must
ensure the handbrake is on.
2 Unscrew the two nuts on the
coupling head and remove the
front bolt.
3 Take the dowel provided
and hammer it through the
coupling head to push the rear
bolt out.
4 Once the dowel has replaced
the bolt inside the coupling
head you should be able
to remove the rear bolt
completely. You may need to
push the coupling head to ease
the process.
5 Slide the coupling head off of
the overrun.
6 DO NOT place the AKS 3004
Stabiliser over the overrun.
1
4
2
3
5
FITMENT
6
This HOW TO guide is suitable for the AKS 3004 Stabiliser, and is applicable
to both the red (original) and black (new) versions.
HOW TO FIT THE AKS 3004 STABILISER
7 The new AKS 3004 Stabiliser
slides
onto the overrun.
8 Push the stabiliser until its
holes line up with the holes in
the overrun.
9 Take the two new bolts
supplied with the stabiliser,
and insert the bolt with the
washer into the front hole.
10 Hammer the bolt without the
washer into the rear hole,
forcing the dowel out of the
other side.
11 Screw the supplied nuts onto
both bolts.
12 Tighten both bolts with a
torque wrench to 86Nm.
FITMENT
10
8
9
11 12
7
