Akuvox E16 Series Manual de usuario

Allen Wrench x 1

A05/E16 x 1

ST4x20 screw x 4

Wall-mounting bracket x 1

Universal Accessories:

Digital Wrist Temperature

Detector x 1

Cable locking plate x 1

Plastic wall anchor x 4

Please make sure the package contains the following items:

Digital Temperature Detector Accessories (Oponal) :

Camera

Photosensitive Sensor

Infrared LED

White Light LED

MIC (For E16 only)

Loudspeaker

RF Card Reader

Back cover x 1

Torx Wrench x 1 Torx Screw x 5

LCD

The bracket for

the device with

temperature

detector

The bracket for

the device with

no temperature

detector

M2.5x6 Screw x 2 Rubber Plug x 3（S,M,L） Diode x 1

M4x30 screw x 2

Digital Forehead Temperature

Detector x 1

E16/A05

M3x10.5 Screw x 2 M3x6 Screw x 2

Installaon

1.1 With embedded one-gang juncon box (86x86 mm or 2x3 inches in size) in the wall

Mark the two positioning

holes of the wall-mounting

bracket on the wall.

Insert two plastic wall

anchors into the two

drilled holes.

Use a hand drill with 5 mm diameter

bit to make two positioning holes

with 25 mm in depth in the marked

positions.

1. Step1: Wall-mounng Bracket Installaon

Fix the wall-mounting bracket

with two M4x30 screws and

two ST4x20 screws.

Fix the wall-mounting bracket on

the embedded box with two

M4x30 screws.

Remove the two M4x30 screws

and take oﬀ the wall-mounting

bracket.

1.1.1 With 86x86 mm embedded junction box in the wall

1.1.2 With 2x3 inches embedded single-gang box in the Wall

Finish the bracket installation.Fix the wall-mounting bracket on the single-gang

junction box with the two M4x30 screws.

E16/A05

According to the position of the

cable, put the wall-mounting

bracket closely on to the wall

and mark the four positioning

holes, while making sure that

relative positions between

wall-mounting bracket and wire

hole are correct.

Note: The positioning holes

should be marked in the center

of the holes.

Take oﬀ the

wall-mounting and

drill the four marked

positioning holes

and the wire holes

using 5 mm hand

drills.

Fix the wall-mounting

bracket with four ST4x20

screws.

Insert four plastic wall

anchors into the holes.

2.Step 2: Device Installaon

Lead the wires from the wall-mount bracket and

the detector through the square hole on the back

cover, connecting them to the corresponding

interface of the main board.

Select a suitable size rubber plug to push all the

cables into the back cover. Fix cable locking plate

to the back cover with two M2.5x6 screws.

Fasten the back cover with

four Torx screws using the

Torx wrench attached.

Take out the device along

with the back cover, cable

locking plate, rubber plug

and corresponding screws.

1.2 Without embedded gang box in the wall

2.1 Device Installaon without Digital Forehead or Wrist Temperature Detector

E16/A05

Installation is completed.

Hang the device on to the square hanger on the wall mounting bracket,

pull down the device to make it fall completely on to the square hanger

on the wall-mounting bracket, then use the Torx Wrench attached to

tighten the device with the Torx screw.

2.2 Device Installaon with Digital Forehead Temperature Detector (Oponal)

Fasten the detector on to the nuts on the device’s rear cover with two M3X10.5

screws using the Allen wrench attached, and lead the wires from the wall-mount

bracket and the detector through the square hole on the back cover, connecting them

to the corresponding interface of the main board. And then select a suitable size

rubber plug to push all the cables into the back cover. Fix the cable locking plate to

the back cover with two M2.5x6 screws.

Hang the device on to the square hanger on the wall mounting

bracket, pull down the device to make it fall completely on to

the square hanger on the wall-mounting bracket, then use the

Torx Wrench attached with to tighten the device with the Torx

screw.

Installation is completed.

Take out the door phone and the

digital forehead temperature

detector and then take out back

cover,cable locking plate,and

rubber plug.

Fasten the back cover with

four Torx screws using the

Torx wrench attached.

E16/A05

2.3 Device Installaon with Digital Wrist Temperature Detector (Oponal)

Tighten the detector on to the inner

threaded bolt with two M3x6 screw

using the Allen wrench attached in the

same way on both side.

Fix the two holes of the detector

onto the installation pins on the

wall-bracket either on the left or

right according to your

preference.

Fasten the back cover with four

Torx screws using the Torx

wrench attached.

Take out the device along with

the back cover，cable locking

plate，rubber plug，and

corresponding screws.

Hang the device on to the square hanger on the wall

mounting bracket, pull down the device to make it fall

completely on to the square hanger on the wall-mounting

bracket, then use the Torx wrench attached to tighten the

device with the Torx screws.

Installation is completed.

Lead the wires from the wall-mount bracket and the detector

through the square hole on the back cover, connecting them

to the corresponding interface of the main board. And then

select a suitable size rubber plug to push all the cables into

the back cover. Fix cable locking plate to the back cover with

two M2.5x6 screws.

Wire of detector

E16/A05

Device Wiring

When you connect a device containting a

coil, such as a relay or an electromagnetic

lock, it is necessary to protect the

intercom against voltage peak while

switching oﬀ the induction load. For this

way of protection we recommend a diode

1 A / 200 V (included in the accessories)

connected antiparallet to the device.

Warning

E16/A05

Applicaon Network Topology

Network Video Recorder

(third party)

SIP Video Phone

LAN

PoE PoE PoE PoE

PC(third party)

PoE PoE

Indoor Monitor

E16 E16 A05 A05

Conﬁguraon

1.IP address Checking: Long press any where on the initial screen for approximately ﬁve

minutes to go to project PIN screen where you enter the default PIN “admin” and press

Conﬁrm tab to go to Setting screen where you press Info icon to check for the device IP

address. ( for E16 series door phone only)

2.Account Registration:On the web interface, go to the path Account -> Basic page to

information)

3.DTMF code conﬁguration: On the web interface, go the path: Access Control->relay to set

up the DTMF code in the corresponding area.

E16/A05

AKUVOX (XIAMEN) NETWORKS CO., LTD.

ADD: 10/F, NO.56 GUANRI ROAD, SOFTWARE PARK II, XIAMEN 361009, CHINA

www.akuvox.com

Notice Information

Akuvox E16/A05 ﬁrmware contains third-party open source software under the terms of the GNU General Public

License(GPL). Akuvox is committed to meeting the requirements of the GNU General Public License (GPL) and will

make all required source code available.

The source code of software under the terms of GNU GPL can be downloaded online: http://www.akuvox.com/gpl.

Information contained in this document is believed to be accurate and reliable at the time of printing. This

document is subject to change without notice, any update to this document can be viewed on Akuvox’s website:

E16/A05

Operaon

Make a call:

Enter the IP or SIP number and press Dial key to make a call

Receive a call:

E16/A05 supports Auto Answer by default. Incoming call from indoor device will be

answered automatically.

Unlock by DTMF:

During the call, press the corresponding DTMF code from the answer unit to unlock

E16/A05 remotely.

Unlock by RF Card：

Place the predeﬁned RF card in the RF reader area to open the door.
