Scala
HD Media Player
USER MANUAL
SCALA HD Media Player User Manual
2
Table of Contents
1 Before you start ...................................................................................................................................................................................................................................4
1.1 Safety notices...........................................................................................................................................................................................................................4
1.2 Warranty ..................................................................................................................................................................................................................................4
1.3 Specification............................................................................................................................................................................................................................5
1.4 Package contents......................................................................................................................................................................................................................7
2 HDD Installation..................................................................................................................................................................................................................................8
3 Setting the Scala HD Media Player...................................................................................................................................................................................................10
3.1 Front / Back Panel layout ......................................................................................................................................................................................................10
3.2 Remote control layout ...........................................................................................................................................................................................................11
3.3 Connecting Scala HD Media Player to your TV...................................................................................................................................................................12
3.4 Initiating the Scala HD Media Player (optional)...................................................................................................................................................................12
4 System Menu.....................................................................................................................................................................................................................................13
4.1 Setup......................................................................................................................................................................................................................................13
4.1.1 Audio setup................................................................................................................................................................................................................14
4.1.2 Video setup ................................................................................................................................................................................................................15
4.1.3 Network setup............................................................................................................................................................................................................16
4.1.4 System setup..............................................................................................................................................................................................................17
4.1.5 MISC setup................................................................................................................................................................................................................18
4.2 Browser..................................................................................................................................................................................................................................19
4.2.1 Play Movies...............................................................................................................................................................................................................20
4.2.2 Play Music.................................................................................................................................................................................................................22
4.2.3 Show Photo................................................................................................................................................................................................................23
4.2.4 Adding contents to PLAYLIST .................................................................................................................................................................................24
4.2.5 Adding contents to PLAYLIST .................................................................................................................................................................................25
SCALA HD Media Player User Manual
3
4.3 File Copy ...............................................................................................................................................................................................................................26
5 Transcoding Software........................................................................................................................................................................................................................27
5.1 Install and run under Transcode Server.................................................................................................................................................................................27
5.2 Adding Share Folders on PC.................................................................................................................................................................................................28
5.3 Connecting to File Sharing folders and BT download management.....................................................................................................................................29
5.3.1 Set up the Scala HD Media Player ............................................................................................................................................................................30
5.3.2 Connect to File Sharing Folder..................................................................................................................................................................................30
5.3.3 Connect to BT Download Management....................................................................................................................................................................31
5.3.4 Account Management................................................................................................................................................................................................35
SCALA HD Media Player User Manual
4
1 Before you start
1.1 Safety notices
1. Caution during HDD installation: Always unplug the power cable before inserting Hard Drive. Electrostatic
discharge (ESD) can damage system components. If an ESD-controlled workstation is not available, wear an
antistatic wrist strap or touch an earthed surface before handling the HDD or SSD.
2. A power supply with a different voltage will damage the product and void its warranty.
3. Keep this equipment away from humidity or any type of moisture.
4. DO NOT drop /shake the device or put any weight on top of it.
1.2 Warranty
Warranties extend only to defects that occur during normal use and do not extend to damage to products that
results from incompatibility, abuse, misuse, negligence, unauthorized repair, modification, incorrect
installation, incorrect voltage supply, air/water pollution, any accident or natural disasters. The warranty
extends only on Akasa enclosure and does not cover a defective HDD, TV, router etc. as a result of a defective
media player or the power adapter. Keep your original sales receipt in a safe place. Nothing herein should be
construed as constituting an additional warranty.
SCALA HD Media Player User Manual
5
1.3 Specification
■ Connections
Video Output
Composite Out
HDMI 1.3 Out
Audio Output
Audio Out L/R
SPDIF(Optical)
File transfer port
2 x USB 2.0 Host port
Date transfer with PC
USB 2.0 mini port
Ethernet
10/100Mbps RJ-45
■ Optional wireless dongle
Wireless USB Dongle WI-FI 802.11g
AK-NTWF01
Note: Please note that only certain USB dongle will work with this device.
SCALA HD Media Player User Manual
6
■ Media format support
Video Decoding
(Movie)
DivX 3/4/5/6,Xvid
AVI / MKV
H.264, AVC TS / AVI / MKV / MOV / M2TS
MPEG-1
MPG / MPEG / DAT
MPEG-2
MPG / MPEG / VOB / ISO / IFO / TS / TP / M2TS
MPEG-4 MP4 / AVI / MOV
WMV9
WMV
FLV
FLV (Support up to 352x288)
Real Video 8/9/10
RM/RMVB (Support up to 720p)
Audio Decoding
(Movie)
Dolby DigitalAC3/Plus/TrueHD 5.1ch, DTS/HD MasterAudio 7.1ch
MPEG-I Layer 1/2/3,MPEG-II Layer 1/2, MPEG4 HE AACv2, Real Audio, AAC, LPCM
HDMI RAW/SPDIF RAW
Audio Decoding
(Music) WMA, MP3, Real Audio (RA), WAV, OGG, AAC, FLAC, ASF, M3U, MKA, MP4
Picture Format JPG, JPEG, BMP, PNG, GIF, TIFF
Subtitle SRT, SUB, SMI, IDX/SUB, SSA, ASS
Note: The specification and design is subject to change without any notice.
SCALA HD Media Player User Manual
7
1.4 Package contents
Scala HD Media player
DC Adaptor (12V 2A)
Remote control
2 x AAAbatteries
HDMI cable
Composite AV cable
USB cable for connection with PC
Quick guide
HDD screws
CD with Bit Torrent P2Psoftware and installation manual
SCALA HD Media Player User Manual
8
2 HDD Installation
NOTE: The SCALA Media Player can play media files from external storage via USB or Network without an internal drive.
Installing the internal drive enables you to store files locally for easy access, backup or simply to free up space on your PC.
Step 1 Open the box by undoing the two securing screws and sliding the system out of the aluminium housing
Step 2 Place the HDD on the tray aligning the SATAconnectors and gently insert the HDD until fully connected
SCALA HD Media Player User Manual
9
Step 3 Secure the HDD with two screws provided
Step 4 Slide the system back into the enclosure and secure with the screws on both corner.
SCALA HD Media Player User Manual
10
3 Setting the Scala HD Media Player
3.1 Front / Back Panel layout
IrDA Receiver
USB 1
USB Device Indicator
HDD Indicator
LAN/Data access Indicator
Power/Standby Indicator
Composite
Output Optical Output HDMI Connector Data Transfer
with PC
LAN Connector
Power Switch
USB 2 Host Port
DC Connector
