AGI W13 Manual de usuario
Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
Part Number: 30262 R1
Revised: November 2021
Original Instructions
W13
Portable Grain Auger
Assembly Manual
This manual applies to the following models:
Westfield W13, Hutchinson W13, Mayrath W13:
51', 61', 71'
New in this Manual
The following changes have been made in this revision of the manual:
Description Section
Updated manual format various sections
W13 – PORTABLE GRAIN AUGER
30262 R1 3
CONTENTS
1. Introduction ............................................................................................................................................ 4
1.1 Serial Number Location............................................................................................................. 4
2. Safety....................................................................................................................................................... 5
2.1 Safety Alert Symbol and Signal Words...................................................................................... 5
2.2 General Safety Information....................................................................................................... 5
2.3 Rotating Flighting Safety ........................................................................................................... 6
2.4 Rotating Parts Safety................................................................................................................. 6
2.5 Drives and Lockout Safety......................................................................................................... 6
2.5.1 PTO Driveline Safety................................................................................................... 7
2.6 Tire Safety.................................................................................................................................. 7
2.7 Personal Protective Equipment................................................................................................. 8
2.8 Safety Equipment ...................................................................................................................... 9
2.9 Safety Decals ............................................................................................................................. 9
2.9.1 Decal Installation/Replacement................................................................................. 9
2.9.2 Safety Decal Locations and Details ............................................................................ 9
3. Assembly ............................................................................................................................................... 16
3.1 Assembly Safety ...................................................................................................................... 16
3.2 Check Shipment....................................................................................................................... 16
3.3 Before You Begin..................................................................................................................... 16
3.4 Arrange the Tubes and Apply Model Decals .......................................................................... 17
3.5 Connect the Auger Tubes........................................................................................................ 20
3.6 Install the Track Shoe and Track Stop..................................................................................... 20
3.7 Intake Hitch ............................................................................................................................. 22
3.8 Install the Multi-Stage Driveshaft ........................................................................................... 22
3.9 Shaft Drive Gearbox ................................................................................................................ 23
3.10 Driveshaft Shield ................................................................................................................... 24
3.11 Install the Spout .................................................................................................................... 25
3.12 Install the Truss ..................................................................................................................... 25
3.13 Assemble the Frame.............................................................................................................. 27
3.14 Connect the Auger Tube to the Frame ................................................................................. 29
3.15 Install the Lift Cylinders and Cables ...................................................................................... 30
3.16 Hydraulic Hose Attachment .................................................................................................. 34
3.17 Attach the PTO Driveline....................................................................................................... 34
3.18 Apply the Lubricant to the Upper Housing........................................................................... 34
3.19 Install the Plastic Manual Container ..................................................................................... 35
4. Specifications ........................................................................................................................................ 36
5. Appendix ............................................................................................................................................... 37
5.1 Bolt Torque.............................................................................................................................. 37
6. AGI Limited Warranty........................................................................................................................... 39
4 30262 R1
1. Introduction
Before assembling, please read this manual. Familiarize yourself with the process and the necessary
precautions for efficient and safe assembly of this AGI Portable Grain Auger.
Everyone present at the assembly site is required to be familiar with all safety precautions.
Keep this manual available for frequent reference and review it with new personnel. Call your local
distributor or dealer if you need assistance or additional information.
1.1. Serial Number Location
The serial number location for your auger is shown in the figure below. Have the serial number ready when
ordering parts or requesting service or other information. Record information in the table below for easy
reference.
Model Number
Serial Number
Date Received
1. INTRODUCTION W13 – PORTABLE GRAIN AUGER
30262 R1 5
2. Safety
2.1. Safety Alert Symbol and Signal Words
This safety alert symbol indicates important safety messages in this manual. When you see
this symbol, be alert to the possibility of injury or death, carefully read the message that
follows, and inform others.
Signal Words: Note the use of the signal words DANGER,WARNING,CAUTION, and NOTICE with the safety
messages. The appropriate signal word for each message has been selected using the definitions below as a
guideline.
Indicates an imminently hazardous situation that, if not avoided, will result in serious injury or
death.
Indicates a hazardous situation that, if not avoided, could result in serious injury or death.
Indicates a hazardous situation that, if not avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation that, if not avoided, may result in property damage.
2.2. General Safety Information
Read and understand all safety instructions, safety decals, and manuals and follow them when assembling the
equipment.
• Only experienced personnel who are familiar with this type of assembly and
installation should perform this work. Untrained assemblers/installers expose
themselves and bystanders to possible serious injury or death.
• Do not modify the auger in any way or deviate from the instructions in this manual without written
permission from the manufacturer. Unauthorized modification or methods may impair the function and/or
safety. Any unauthorized modification will void the warranty.
• Follow a health and safety program for your worksite. Contact your local occupational health and safety
organization for information.
• Contact your local representative or AGI if you need assistance or additional information.
• Always follow applicable local codes and regulations.
W13 – PORTABLE GRAIN AUGER 2. SAFETY
6 30262 R1
2.3. Rotating Flighting Safety
• KEEP AWAY from rotating flighting.
• DO NOT remove or modify flighting guards, doors, or covers.
Keep in good working order. Have replaced if damaged.
• DO NOT operate the auger without all guards, doors, and
covers in place.
• NEVER touch the flighting. Use a stick or other tool to
remove an obstruction or clean out.
• Shut off and lock out power to adjust, service, or clean.
2.4. Rotating Parts Safety
• Keep body, hair, and clothing away from rotating pulleys,
belts, chains, and sprockets.
• Do not operate with any guard removed or modified. Keep
guards in good working order.
• Shut off and lock out power source before inspecting or
servicing machine.
2.5. Drives and Lockout Safety
Inspect the power source(s) before using and know how to shut down in an emergency.
Whenever you service or adjust your equipment, make sure you shut down the power
source and unplug or remove the key (as applicable) to prevent inadvertent start-up and
hazardous energy release. Know the procedure(s) that applies to your equipment from the
following power source(s). Ensure that all personnel are clear before turning on power to
equipment.
2. SAFETY W13 – PORTABLE GRAIN AUGER
30262 R1 7
2.5.1 PTO Driveline Safety
Drive
• Keep body, hair, and clothing away from rotating PTO
driveline.
• Make certain the driveline shields telescope and rotate freely
on driveline before attaching.
• Make certain the driveline is securely attached at both ends.
• Do not operate auger unless all driveline, tractor, and
equipment shields are in place and in good working order.
• Do not exceed the specified operating speed.
• Keep universal joint angles small and equal. Do not exceed
maximum recommended length for PTO driveline.
• Engage tractor park brake and/or chock wheels.
Lockout
• Position all controls in neutral, shut off tractor’s engine, and remove key from tractor.
• If removing key is impossible, remove PTO driveline from tractor.
2.6. Tire Safety
Failure to follow proper procedures when mounting a tire on a
wheel or rim can produce an explosion that may result in
serious injury or death.
• DO NOT attempt to mount a tire unless you have the proper
equipment and experience to do the job.
• Have a qualified tire dealer or repair service perform
required tire maintenance.
• When replacing worn tires, make sure they meet the original
tire specifications. Never undersize the replacement tire.
• DO NOT weld to the tire rim with the tire mounted on the
rim. This action may cause an explosion which could result in
serious injury or death.
• Inflate tires to the manufacturer’s recommended pressure.
• Tires should not be operated at speeds higher than their
rated speed.
• Keep wheel lug nuts tightened to manufacturer’s
recommendations.
• Never reinflate a tire that has been run flat or seriously
under-inflated without removing the tire from the wheel.
Have the tire and wheel closely inspected for damage before
remounting.
W13 – PORTABLE GRAIN AUGER 2. SAFETY
8 30262 R1
2.7. Personal Protective Equipment
The following Personal Protective Equipment (PPE) should be worn when operating or maintaining the
equipment.
Safety Glasses
• Wear safety glasses at all times to protect eyes from debris.
Hearing Protection
• Wear ear protection to prevent hearing damage.
Coveralls
• Wear coveralls to protect skin.
Hard Hat
• Wear a hard hat to help protect your head.
Steel-Toe Boots
• Wear steel-toe boots to protect feet from falling debris.
Work Gloves
• Wear work gloves to protect your hands from sharp and rough edges.
Dust Mask
• Wear a dust mask to prevent breathing potentially harmful dust.
2. SAFETY W13 – PORTABLE GRAIN AUGER
30262 R1 9
2.8. Safety Equipment
The following safety equipment should be kept on site.
Fire Extinguisher
• Provide a fire extinguisher for use in case of an accident. Store in a highly visible and
accessible place.
First-Aid Kit
• Have a properly-stocked first-aid kit available for use should the need arise, and
know how to use it.
2.9. Safety Decals
• Keep safety decals clean and legible at all times.
• Replace safety decals that are missing or have become illegible. See decal location figures that follow.
• Replaced parts must display the same decal(s) as the original part.
• Replacement safety decals are available free of charge from your distributor, dealer, or factory as applicable.
2.9.1 Decal Installation/Replacement
1. Decal area must be clean and dry, with a temperature above 50°F (10°C).
2. Decide on the exact position before you remove the backing paper.
3. Align the decal over the specified area and carefully press the small portion with the exposed sticky backing
in place.
4. Slowly peel back the remaining paper and carefully smooth the remaining portion of the decal in place.
5. Small air pockets can be pierced with a pin and smoothed out using the decal backing paper.
2.9.2 Safety Decal Locations and Details
Replicas of the safety decals that are attached to the auger and their messages are shown in the figure(s) that
follow. Safe operation and use of the auger requires that you familiarize yourself with the various safety decals
and the areas or particular functions that the decals apply to, as well as the safety precautions that must be
taken to avoid serious injury, death, or damage.
W13 – PORTABLE GRAIN AUGER 2. SAFETY
