AG Neovo SC-17 Manual de usuario

www.agneovo.com

A cost-effective 17” surveillance

display with the quality, connectivity

and performance essential for any

security environment.

With the AG Neovo SC-17, security centres can keep an eye on

budgets without losing sight of performance. Digital and analogue

video inputs, including looping BNC I/O, minimise installation

cost. Auto NTSC/PAL detection, settings key lock and auto settings

adjustment reduce maintenance hassle. Quick signal-switching and

rapid response time improve surveillance eciency, while built-in

speakers provide an additional level of security. All this and more

make the SC-17 the perfect value display choice for any security

environment.

> High 1280 × 1024 SXGA resolution

> Anti-Burn-inTM technology

> Video inputs (BNC in x 1, BNC out x 1)

> Looping video inputs for multiple connections

> Quick signal-switching time ( ≤ 0.8 sec. )

> NTSC/PAL auto-detection

> Selectable signal source

> PC compatible

> Built-in speakers

> Key lock function

> Auto-adjustment for optimal setting

> Security socket

> VESA standard wall mount

SC-17

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: SC1700 Version 2.0, 20100430

Speciﬁcations SC-17

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Display Colour

Response Time

Panel Life Time

TFT LCD

17.0” (432 mm)

SXGA 1280 x 1024

0.264 mm

250 cd/m2 (Typical)

1000:1 (Typical)

160°/160° (Typical)

16.7M

3 ms (GTG)

50,000 hrs (Minimum)

Frequency (H/V) H: 31 kHz - 80 kHz

V: 56 Hz - 75 Hz

Max. Pixel Clock 140 MHz

Input Analogue

Digital

BNC Security

D-Sub via DVI-VGA cable

29-Pin DVI-I

BNC Connector in / out

Audio Audio In

Speaker

3.5 mm Audio Line-in

1W x 2

Power AC-DC Adaptor

Power

Consumption

External

AC 100-240 V, 50-60 Hz

< 26 W (On)

< 1.5 W (Off)

Plug & Play VESA DCC 2B

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 85%

Storage

Conditions

Temperature

Humidity

-20 °C ~ 60 °C

5% ~ 95%

Mounting VESA FPMPMI Yes (100 mm)

Tilt Tilt -5° ~ +15°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

372 x 361 x 164mm

(14.7” x 14.2” x 6.5”)

420 x 430 x 160mm

(16.5” x 16.9” x 6.3”)

Weight Product Weight

Packaged Weight

3.6 kg (7.9 lbs)

5.5 kg (12.1 lbs)

Regulation

Approval

Certiﬁcations &

Compliance

UL/CUL, FCC-B, RoHS

Accessories Supplied User manual, power cord,

power adaptor, DVI-VGA

cable, audio cable

SC-17

Video versatility, including VGA, DVI

and BNC In/Out

Stylish and slim design ideal for

professional security environments

Looping video inputs allow multiple

display connections

Built-in speakers enable more rigorous

security monitoring
