www.agneovo.com

REACH

H-W22

A brilliant 22” widescreen display

for home and ofﬁce environments

that require multimedia

performance at an affordable price.

Featuring an impressive 22” widescreen and built-in HDCP for

HD-format video, the H-W22 is designed expressly for video,

gaming, and other multimedia applications. e super-resolution

1680 x 1050 panel and swi response time make for awless video

playback. Capable of displaying two full-sized open windows

at the same time, the convenient widescreen format allows for

increased productivity. e slim H-W22 is an ideal multimedia

solution for cost-conscience home and oce environments.

> 22” widescreen format

> WSXGA+1680 x 1050 resolution

> Slim and sleek design

> Fast 3 ms response time

> Crisp 1000:1 contrast ratio

> Dual analogue and digital inputs

> Built-in HDCP for HD-format video

> Integrated speakers

> Auto-adjustment for optimal viewing

> Easy-to-use friendly OSD

> Kensington® security socket

> VESA standard wall mount

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: HW2200 Version 23.0, 20100701

Speciﬁcations H-W22

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Surface Treatments

Viewing Angle (H/V)

Display Colour

Response Time

Panel Life Time

TFT LCD

22.0” (559 mm)

WSXGA+1680 x 1050

0.282 mm

300 cd/m2(Ty pical)

1000:1 (Typical)

Hard Coating (3H),

Anti-glare Treatment

170°/160° (Typical)

16.7M

3 ms (GTG)

50,000 hrs (Minimum)

Frequency (H/V) H: 30 kHz - 83 kHz

V: 56 Hz - 75 Hz

Max. Pixel Clock Analogue

Digital

190 MHz

165 MHz

Input Analogue

Digital

15-Pin D-Sub

24-Pin DVI-D

Audio Audio In

Speaker

3.5 mm Audio Line-in

2 W x 2

Power AC-DC Adaptor

Power

Consumption

Internal

AC 100 - 240 V, 50 - 60 Hz

< 52 W (On)

< 2 W (Stand-by)

< 1 W (Off)

Plug & Play VESA DCC 2B, DCC/CI

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 90%

Storage

Conditions

Temperature

Humidity

-20 °C ~ 60 °C

5% ~ 95%

Mounting VESA FPMPMI Yes (100 mm)

Tilt Tilt -5° ~ +25°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

506 x 405 x 211 mm

(19.9” x 15.9” x 8.3”)

591 x 522 x 174 mm

(23.3” x 20.6” x 6.9”)

Weight Product Weight

Packaged Product Weight

4.9 kg (10.8 lbs)

5.9 kg (13.0 lbs)

Regulation

Approval

Certiﬁcations &

Compliance

UL/CUL, TUV/GS, CB,

GOST-R, FCC, CE, BSMI,

WEEE, RoHS, Vista/Basic,

REACH

Accessories Supplied Quick Guide, CD ROM

(user manual and drivers),

15-Pin D-Sub cable, 24-Pin

DVI-D cable, audio cable,

AC power cord, base

Widescreen format allows for greater productivity by

enabling two windows to be open at the same time

without any overlap

VESA standard wall mount allows for secure

mounting almost anywhere

Integrated stereo speakers provide rich sound to accompany

games, DVDs and other visual entertainment

H-W22
