AEG A18FIW34HT Manual de usuario

A18FIW34HT

Original instructions

Important!

It is essential that you read the instructions in this manual before assembling,

operating and maintaining the product.

Subject to technical modifications.

1. Anvil

2. Direction of rotation selector

3. Variable speed switch trigger

4. Handle, insulated gripping surface

5. T mode

6. Speed mode

7. LED light

8. Battery port

9. Belt clip bracket

10. Belt clip boom lift

11. Belt clip on person

12. Belt clip cover

13. Screw

TIGHT

H M L

10 11

TIGHT

H M L

TIGHT

H M L

Remove the battery pack beforestarting any work on the machine.

TIGHT

H M L

TIGHT

H M L

START

STOP

TIGHT

H M L

TIGHT

H M L

TIGHT

H M L

Remove the battery pack beforestarting any work on the machine.

TIGHT

H M L

TIGHT

H M L

START

STOP

TIGHT

H M L

TIGHT

H M L

click

Remove the battery pack before starting any

work on the machine.

78-100 %

33-54 %

55-77 %

10-32 %

<10 %

click

Remove the battery pack before starting any

work on the machine.

78-100 %

33-54 %

55-77 %

10-32 %

<10 %

TIGHT

H M L

TIGHT

H M L

TIGHT

H M L

TIGHT

H M L

TIGHT

H M L

TIGHT

H M L

TIGHT

H M L

TIGHT

H M L

TIGHT

click

Remove the battery pack before starting any

work on the machine.

TIGHT

H M L

TIGHT

H M L

TIGHT

H M L

TIGHT

H M L

TIGHT

H M L

TIGHT

H M L

TIGHT

H M L

TIGHT

H M L

TIGHT

click

Remove the battery pack before starting any

work on the machine.

T mode: low torque

T mode: medium torque

T mode: maximum torque

Speed mode

T mode: low torque

Torque 200 Nm

Use this mode to drive small fasteners when low torque

is required. In this mode, the product will automatically

stop after it has impacted on the fastener, thus preventing

damage to the workpiece or fastener.

T mode: medium torque

Torque 790 Nm

Use this mode to drive medium-sized fasteners when

medium torque is required. In this mode, the product will

automatically stop after it has impacted on the fastener,

thus preventing damage to the workpiece or fastener.

T mode: maximum torque

Torque 1230 Nm

Use this mode to drive large fasteners when high torque

is required. In this mode, the product will automatically

stop after it has impacted on the fastener, thus preventing

damage to the workpiece or fastener.

Speed mode: 3

Torque 1660 Nm

Use this mode to drive large fasteners when maxmium

force and speed are required.

Speed mode: 2

Torque 900 Nm

Use this mode to drive medium-sized fasteners when

medium force and speed are required.

Speed mode: 1

Torque 115 Nm

Use this mode to drive small fasteners when lowest speed

and force are required.

START

STOP

START

STOP

LOCK

Remove the battery pack before starting any

work on the machine.
