Instruction Booklet Gas Hob
GB IE
2
Welcome to the world of Electrolux
Thank you for choosing a first class product from Electrolux, which hopefully will
provide you with lots of pleasure in the future.
The Electrolux ambition is to offer a wide variety of quality products that make
your life more comfortable.
You find some examples on the cover in this manual. Please take a few minutes to
study this manual so that you can take advantage of the benefits of your new
machine.
We promise that it will provide a superior User Experience delivering Ease-of-
Mind.
Good luck!
3
Contents
Important Safety Information ..................................................................................... 2
Instructions for the User ............................................................................................... 5
Description of the Hob ............................................................................................................ 5
Operation...................................................................................................................................... 6
Maintenance and Cleaning ................................................................................................... 8
The Hob Top ................................................................................................................................. 8
Pan Supports ............................................................................................................................... 8
The Burners .................................................................................................................................. 8
The Ignition Electrode ............................................................................................................. 8
Something Not Working? ....................................................................................................... 9
Service and Spare Parts ........................................................................................................ 10
Guarantee Conditions........................................................................................................... 11
Instructions for the Installer ...................................................................................... 12
Engineer technical data ....................................................................................................... 12
Important safety requirements ......................................................................................... 14
Location...................................................................................................................................... 14
Installation ................................................................................................................................ 15
Gas Connection ....................................................................................................................... 16
Cut Out Size .............................................................................................................................. 17
Building In ................................................................................................................................ 17
Building over a cupboard or drawer .............................................................................. 17
Building over a kitchen unit with door ........................................................................ 18
Fitting the hob to the worktop ........................................................................................ 19
Electrical connections ........................................................................................................... 20
Permanent Connection ........................................................................................................ 21
Wiring diagram ....................................................................................................................... 21
Fault Finding ............................................................................................................................ 22
Preliminary Electrical Systems Check .............................................................................. 22
Ignition System / Gas Ignition ........................................................................................... 24
Commissioning ........................................................................................................................ 25
Pressure Testing ....................................................................................................................... 25
Conversion from Natural Gas to LPG .............................................................................. 26
Guide to Use the instructions
The following symbols will be found in the text to guide you throughout the Instructions:
Safety Instructions
Step by step instructions for an
operation
Hints and Tips
Environmental information
!!
!!
!
"
4
Important Safety Information
You MUST read these warnings carefully before installing or using the hob. If
you need assistance, contact our Customer Care Department on 08705 350350
Installation
#This appliance must be installed and serviced by a competent person as stated
in the Gas Safety (Installation and Use) Regulations Current Editions and the
IEE Wiring Regulations.
#For appliances installed in the Republic of Ireland please refer to NSAI-Domestic
Gas Installations I.S.813 Current Editions and the ETCI Rules for Electrical
Installations.
#Remove all packaging before using the hob.
#Ensure that the gas and electrical supply complies with the type stated on the
rating plate, located near the gas supply pipe.
#Do not attempt to modify the hob in any way.
Child Safety
#This hob is designed to be operated by adults. Do not allow children to play
near or with the hob.
#This appliance is not intended for use by children or other persons whose
physical, sensory or mental capabilities or lack of experience and knowledge
prevents them from using the appliance safely without supervision or instruction
by a responsible person to ensure that they can use the appliance safely.
#The hob gets hot when it is in use. Children should be kept away until it has
cooled.
#Children can also injure themselves by pulling pans or pots off the hob.
During Use
#This hob is intended for domestic cooking only. It is not designed for commercial
or industrial purposes.
#This appliance is not connected to a combustion products evacuation device. It
must be installed and connected in accordance with current installation
regulations. Particular attention shall be given to the relevant requirements
regarding ventilation.
#When in use a gas cooking hob will produce heat and moisture in the room in
which it has been installed. Ensure there is a continuous air supply, keeping air
vents in good condition or installing a cooker hood with a venting hose.
#Ensure a good ventilation around the appliance. A poor air supply could cause
lack of oxygen.
5
#Ensure the control knobs are in the ‘OFF’ position when not in use.
#When using other electrical appliances, ensure the cable does not come into
contact with the hot surfaces of the cooking appliance.
#Unstable or misshapen pans should not be used on the hob as unstable pans
can cause an accident by tipping or spillage.
#Never leave the hob unattended when cooking with oil and fats.
#Never use plastic or aluminium foil dishes on the hob.
#Perishable food, plastic items and areosols may be affected by heat and should
not be stored above or below the hob unit.
#This appliance cannot be cleaned with steam or with a steam cleaning machine.
Service
#This hob should only be repaired or serviced by an authorised Service Engineer
and only genuine approved spare parts should be used.
Environmental Information
#After installation, please dispose of the packaging with due regard to safety
and the environment.
#When disposing of an old appliance, make it unusable, by cutting off the cable.
#The symbol on the product or on its packaging indicates that this product
may not be treated as household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this product,
please contact your local city office, your household waste disposal service or
the shop where you purchased the product.
"
Keep this instruction book for future reference and ensure it is passed on to
any new owner.
These instructions are only valid for countries whose identification symbols
are shown on the cover of this instruction booklet and on the appliance
itself.
#When using the hob for a long period time, the ventilation should be improved,
by opening a window or increasing the extractor speed.
#Do not use this hob if it is in contact with water. Do not operate the hob with
wet hands.
6
1. Hob Top
2. Semi-rapid Burner
3. Triple Crown Burner
4. Auxiliary Burner
5. Control knob for front left burner (semi-rapid)
6. Control knob for back left burner (semi-rapid)
7. Control knob for back right burner (triple crown)
8. Control knob for front right burner (auxiliary)
Description of the Hobs
INSTALLATION
Any gas installation must be carried out by a registered competent person,
and in accordance with existing rules and regulations.
The relevant instructions are to be found in the second section of this manual.
Please, ensure that, once the hob is installed, it is easily accessible for the
engineer in the event of a breakdown.
WHEN THE HOB IS FIRST INSTALLED
Once the hob has been installed, it is important to remove any protective materials,
which were put on in the factory.
The manufacturer will not accept liability, should the above instructions or any of
the other safety instructions incorporated in this book be ignored.
2
1
2
4
3
5678
7
Hob burners control knobs
The symbols on the knobs mean that :
# there is no gas supply
there is maximum gas supply
there is minimum gas supply
Lighting the burners
For easier lighting, proceed before putting a pan on the pan support.
To light a burner:
#turn the relevant knob anticlockwise to
maximum position ( ).
#Upon ignition, keep the knob pushed down
about 5 seconds. This will allow the
"thermocouple" (Fig. 1 - letter D) to be heated
and the safety device to be switched off,
otherwise the gas supply would be interrupted.
#Then adjust the flame as required.
If the burner does not ignite, turn the control
knob to zero, and try again.
When switching on the mains, after installation
or a power cut, it is quite normal for the spark
generator to be activated automatically.
In the absence of electricity, ignition can occur
without the electrical device; in this case,
approach the burner with a flame, push the
relevant knob down and turn it anti-clockwise
until it reaches the “maximum” position.
If the control knobs become difficult to turn, please contact your local Service
Force Centre.
Operation
!
Fig. 1
A- Burner cap
B- Burner crown
C- Ignition electrode
D- Thermocouple
8
Burner minimum maximum
diameter diameter
Triple crown (ultra-rapid) 180 mm 260 mm
Medium (semi-rapid)
rear 120 mm 220 mm
front 120 mm 180 mm
Small (auxiliary) 80 mm 160 mm
As soon as a liquid starts boiling, turn down the flame so that it will
barely keep the liquid simmering.
Use only pans or pots with flat bottom.
If you use a saucepan which is smaller than the recommended size, the
flame will spread beyond the bottom of the vessel, causing the handle to
overheat.
Carefully supervise cooking with fat or oil, since these types of foodstuff
can result in a fire, if over-heated.
The stainless steel can become tarnished if excessively heated. Therefore
prolonged cooking with potstones, earthenware pans or cast-iron plates
is inadvisable. Also, do not use aluminium foil to protect the top during
use.
Make sure pots do not protrude over the edges of the cooktop and that
they are centrally positioned on the rings in order to obtain lower gas
consumption.
Do not place unstable or deformed pots on the rings: they could tip over
or spill their contents, causing accidents.
Pots must not enter the control zone.
It is advisable to use cast iron recipients or steak plates only on the rear
burners, so as not to damage the electronic lighting components.
Using the hob correctly
To ensure maximum burner efficiency, it is strongly recommended that you use only
pots and pans with a flat bottom fitting the size of the burner used, so that flame
will not spread beyond the bottom of the vessel (see the table beside).
9
Using the Wok Stand
A wok stand is provided to enable you to use a round
bottomed wok on the hob. The wok stand must only
be used on the triple crown burner, and should not
be used with any other type of wok or pan. When
fitting the wok stand, ensure the recesses in the fra-
me fit securely onto the bars of the pan supports, as
shown in the picture.
quale bruciatore
suggerisre per la gri-
glia WOK qui?
10
Before any maintenance or cleaning can be carried out, you must
DISCONNECT the hob from the electricity supply.
The hob is best cleaned whilst it is still warm, as spillage can be removed
more easily than if it is left to cool.
This appliance cannot be cleaned with steam or with a steam cleaning
machine.
The Hob Top
Regularly wipe over the hob top using a soft cloth well wrung out in warm water
to which a little wasing up liquid has been added. Avoid the use of the following:
- household detergent and bleaches;
- impregnated pads unsuitable for non-stick
saucepans;
- steel wool pads;
- bath/sink stain removers.
Should the hob top become heavily soiled, the
following products are recommended:
- For stainless steel hobs use a proprietary stainless
steel cleaner.
- For other hobs use Hob Brite or Bar Keepers Friend.
Do not leave acid or alkaline substances (e.g.
vinegar, salt, lemon juice, etc.) on the cooktop.
Pan Supports
The pan supports are dishwasher proof. If washing
them by hand, take care when drying them as the
enamelling process occasionally leaves rough edges.
If necessay, remove stubborn stains using a paste
cleaner.
After cleaning, make sure that the pan supports are
correctly positioned.
To make burners work properly, ensure that pan
supports are placed in a way that the arms are centred
upon the burner as shown in the picture.
Pay attention when replacing the pan supports
in order to avoid damaging the hob top.
Maintenance and Cleaning
NO
YES
Tabla de contenidos
Otros manuales de Quemador de AEG
AEG
AEG 61 B4A 00 AA Manual de usuario
AEG
AEG 35772 G Manual de usuario
AEG
AEG HK8542H1XB Manual de usuario
AEG
AEG IKE95751FB Manual de usuario
AEG
AEG 68042K-MN Manual de usuario
AEG
AEG HDB95623NB Manual de usuario
AEG
AEG CERAMIC HOB 6010 K Manual de usuario
AEG
AEG KFA29SIO Manual de usuario
AEG
AEG HK654070FB Manual de usuario
AEG
AEG HGB95520YM Manual de usuario
AEG
AEG 6000K Manual de usuario
AEG
AEG IDK84454IB Manual técnico
AEG
AEG IBK64200CB Manual de usuario
AEG
AEG IKB64443IB Manual de usuario
AEG
AEG HK955070XB Manual de usuario
AEG
AEG HK854401FB Manual de usuario
AEG
AEG HK312000H Manual de usuario
AEG
AEG B 99852G Manual de usuario
AEG
AEG HKB75540NB Manual de usuario
AEG
AEG EES23101ZM Manual de usuario
