FAVORIT 64860

Dishwasher

Instruction book

PERFEKT IN FORM UND FUNKTION

152959 56/1en 3-01-2005 10:14 Pagina 1

Dear customer,

Please read this User Information carefully and keep it to refer to at a

later date.

Pass it on to any subsequent owner of the appliance.

The following symbols are used in the text:

Safety instructions

Warning! Notes that concern your personal safety.

Attention! Notes that show how to avoid damage to the appliance.

Useful tips and hints

Environmental information

Your dishwasher has the new washing system ”IMPULSE WASHING”.

With this dishwashing system the motor speed and spray pressure

are varied during the wash cycle to achieve better cleaning of the

dishes. It is for this reason that the noise level varies during the

dishwashing cycle.

152959 56/1en 3-01-2005 10:14 Pagina 2

CONTENTS

Operating instructions 4

Safety instructions 4

Disposal 6

Economical and ecological dishwashing 6

Description of the appliance 7

The control panel 8

Prior to using for the first time 11

The water softener 11

Filling with dishwasher salt 14

Rinse aid 15

In daily use 17

Loading cutlery and dishes 17

The lower basket 19

The cutlery basket 20

The upper basket 21

Adjusting the height of the upper basket 22

Use of detergent 23

Different kinds of detergent 24

Washing programmes 26

Starting a washing programme 28

Maintenance and cleaning 33

Cleaning the filters 33

What to do, when... 36

Service 39

Technical specifications 40

Installation instructions 41

Fitting under a counter 41

Levelling 41

Water supply connections 42

Water inlet hose with safety valve 43

Water outlet hose connection 44

Electrical connection 45

Hints for test centres 46

Contents

152959 56/1en 3-01-2005 10:14 Pagina 3

OPERATING INSTRUCTIONS

Safety instructions

The safety of AEG electrical appliances conforms to accepted rules of

technology and the Appliance Safety Act. We as manufacturers,

however, see ourselves as being obliged to familiarise you with the

following safety instructions.

It is most important that this instruction book should be retained

with the appliance for future reference. Should the appliance be

sold or transferred to another owner, or should you move house

and leave the appliance, always ensure that the book is left with

the appliance in order that the new owner can get to know the

functioning of the appliance and the relevant safety information.

This information has been provided in the interest of your safety.

You MUST read it carefully before installing or using the

appliance.

Installation

●Check your dishwasher for any transport damage. Never connect a

damaged machine. If your dishwasher is damaged, you should

contact your supplier.

●For safety reasons it is dangerous to alter the specifications or

attempt to modify this product in any way.

●Any electrical and plumbing work required to install this appliance

should be carried out by a qualified and competent person.

●Care must be taken to ensure that the appliance does not stand on

the electrical supply cable.

●The sides of the dishwasher must never be drilled to prevent

damage to hydraulic components.

Child safety

●This appliance is designed to be operated by adults.

●Children should not be allowed to tamper with the controls or play

with the product.

●Packaging parts may be dangerous for children, who could even be

suffocated! You should therefore keep all packaging well away

from children.

Operating instructions

152959 56/1en 3-01-2005 10:14 Pagina 4

●The water in your dishwasher is not for drinking. Detergent residues

may still be present in your machine. Keep children well away from

your dishwasher when the door is open.

●Keep all detergents in a safe place out of children’s reach.

Your dishwasher in day-to-day use

●Items that are contaminated by petrol, paint, steel or iron debris,

corrosive, acidic or alkaline chemicals must not be washed in this

dishwasher.

●Under no circumstances should you open the door whilst the

appliance is in operation, especially during the washing phase, hot

water may escape. However, if the door is opened, a safety device

ensures that the machine stops.

●Only use products (detergent, salt and rinse aid) specifically

designed for use in dishwashers.

●Long bladed knives stored in an upright position are a potential

hazard.

●Long and/or sharp items of cutlery such as carving knives must be

positioned horizontally in the upper basket.

●Ensure that the door of the dishwasher is always closed when it is

not being loaded or unloaded. In this way you will avoid anybody

tripping over the open door and hurting themeselves.

●When finishing loading or unloading close the door, as an open

door can be a hazard.

●Do not sit or stand on the open door.

●Isolate the appliance from the power supply and turn off the water

supply after use.

●This product should be serviced by an authorised service engineer,

and only genuine spare parts should be used.

●Under no circumstances should you attempt to repair the machine

yourself. Repairs carried out by inexperienced persons may cause

injury or serious malfunctioning. Contact your local Service Force

Centre. Always insist on genuine spare parts.

Operating instructions

152959 56/1en 3-01-2005 10:14 Pagina 5

Disposal

Dispose of the dishwasher packaging material correctly.

All packaging materials can be recycled.

Plastic parts are marked with standard international abbreviations:

>PE< for polyethylene, e.g. sheet wrapping material.

>PS< for polystyrene, e.g. padding material (always CFC-free).

>POM< for polyoxymethylene, e.g. plastic clips.

Cardboard packaging is manufactured from recycled paper and should

be deposited in the waste paper collection for recycling.

As and when you cease to use your dishwasher and withdraw it from

service, your should render it unserviceable before having it disposed

of.

Warning! Children at play could lock themselves in your dishwasher or

otherwise endanger their lives. Therefore cut off the power supply

cable and make the door closing device unusable to prevent children

from being trapped inside.

For the disposing of the appliance please take it to a recycling centre

or to your dealer who may, for a small contribution to the costs,

dispose it for you.

Economical and ecological dishwashing

●Ensure that the water softener is correctly adjusted.

●Do not pre-wash under running water.

●Select the wash programme to suit the nature and degree of the

soiling on the dishes.

●Do not use more detergent, special salt and rinse aid than is

recommended in these operating instructions and by the

manufacturer of the respective product.

Operating instructions

152959 56/1en 3-01-2005 10:14 Pagina 6

Operating instructions

Description of the appliance

1. Upper basket stop

2. Water hardness switch

3. Salt container

4. Detergent dispenser

5. Control panel

6. Rating plate

7. Rinse aid dispenser

8. Filters

9. Lower spray arm

10. Upper spray arm

11. Upper basket

12.Worktop

IN154

152959 56/1en 3-01-2005 10:14 Pagina 7

Operating instructions

Function buttons: in addition to the dishwashing programme

selected, the following functions can also be set with the help of these

buttons:

- water softener setting,

- activation/deactivation of the rinse aid dispenser,

- the cancelling of a programme in progress.

Programme selection buttons: the selection of a washing

programme occurs by pressing one of these buttons (see "Washing

programmes" chart).

"Delay start" button: this option allows the start of the programme

to be delayed from 1 to 19 hours.

The digital display indicates:

- the level of hardness to which the water softener is set,

- if the rinse aid dispenser is activated/deactivated,

- the countdown of the delay start,

- the approximative remaining time of the running programme,

- fault codes concerning malfunction of the dishwasher.

The control panel

ON/OFF button

Programme selection

buttons

Function buttons

Digital display

Indicator lights

“Delay start”

button“3 in 1” button

1 2 3

Phase

indicator lights

ON/OFF

indicator light

“Programme in progress”

indicator light

152959 56/1en 3-01-2005 10:14 Pagina 8

Operating instructions

Phase indicator lights: have the following meanings:

As soon as you select a washing programme, the phase indicator lights

for that programme will illuminate.

As the programme starts, the phase indicator lights turn off except for

the indicator light of the phase in progress.

Indicator lights: have the following meanings:

The salt and rinse aid indicator lights are never illuminated while a

washing programme is running even if filling with salt and rinse aid is

necessary.

Prewash: illuminates when the prewash phase is running

Wash: illuminates when the washing phase is running

Rinse: illuminates when the rinsing phase is running

Drying: illuminates when the drying phase is running

End of programme: illuminates when the washing

programme has ended.

Salt refilling indicator light, illuminates when the salt has

run out

Rinse aid refilling indicator light, illuminates when the rinse

aid has run out

Water tap: illuminates when the dishwasher does not fill

with water

Check the filter: illuminates at regular intervals,

independent of the amount of soiling of the filtres, to

remind you to check the filters and, if necessary, to clean

them.

Open door: illuminates when the door is open or not

properly closed.

152959 56/1en 3-01-2005 10:14 Pagina 9

“Programme in progress” indicator light: have the following

meaning:

"3 in 1" button: This appliance is equipped with the function 3 in 1,

that allows the use of the "3 in 1" combi detergent tablets.

This function can be selected with all washing programmes.

With the selection of this function the inflow of rinse aid and salt

from each respective supply container is automatically deactivated and

also the indicator lights for salt and rinse aid are deactivated.

Once selected this function (button indicator light illuminated ) it will

remain active also for the following washing programmes, to

deactivate the function, press the button (button indicator light off).

Operating instructions

illuminates a washing programme has been set and remains

illuminated for all the programme’s duration.

Turns off when the washing programme has ended.

When the delay start is set, this indicator light turns off.

Once the countdown has elapsed and the washing

programme starts, it will illuminate again.

152959 56/1en 3-01-2005 10:14 Pagina 10

Tabla de contenidos

Otros manuales de Lavavajillas de AEG Electrolux

AEG Electrolux

AEG Electrolux Favorit 86080FUM Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 35085 VI Manual de usuario

AEG Electrolux

AEG Electrolux Built-In Dishwasher Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 55330VI0 Manual de usuario

AEG Electrolux

AEG Electrolux ESF 655W Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 75011 VIL Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT OPTIMA AA Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT55322VI0 Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 88070 Vi Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 84980 VI Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 88070 i Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 60760 Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 88015 VI Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 86080 Vi Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 99001 VI Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 89020 VI Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 60850 vi Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 35020 VI Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 86410 I Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 88010 VIL Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 80870 Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT AAAUTO Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 60660 Manual de usuario

AEG Electrolux

AEG Electrolux FAVORIT 89020 I Manual de usuario

Manuales populares de Lavavajillas de otras marcas

Electrolux

Electrolux ESI5211LOX Manual de usuario

KitchenAid

KitchenAid KUDB230B Manual de usuario

Brandt

Brandt BDJ424DB Manual de usuario

Asko

Asko DSD767UXXL.AU Manual de usuario

Beko

Beko DFN26210W Manual de usuario

NEFF

NEFF S153ITX00E Hoja de especificaciones

Midea

Midea SV 4.45 wi Manual de usuario

LG LDF7932 Manual de usuario

Gorenje

Gorenje GV63214 Manual de usuario

Hotpoint

Hotpoint HDA1100ZWH Manual de servicio

Blomberg

Blomberg LDFN2240W Manual de usuario

AEG

AEG FFB83836PM Manual de usuario

Cylinda

Cylinda DM3220RFD Manual de usuario

Atag

Atag DW8214MB Manual de usuario

GE GLD8000 Series Manual de usuario

Siemens

Siemens SN23HI02KE Hoja de especificaciones

Omega

Omega ODW717X Manual de usuario

BORETTI

BORETTI BVW-683 Manual de usuario
