ADX FIRESTORM MK06 Manual de usuario
FIRESTORM
MK06
7.1 RGB
GAMING HEADSET
INSTRUCTION MANUAL
AFSH0520
Contents
Safety Warnings.................................................................3
Unpacking..........................................................................4
Product Overview..............................................................5
System Requirements .......................................................6
Software Installation.........................................................6
Connections .......................................................................7
User Interface.....................................................................8
User Interface.....................................................................9
Speaker Setting .................................................................9
Mic Setting ...................................................................... 14
Hints and Tips.................................................................. 17
Specications.................................................................. 17
3
Safety Warnings
• For trac safety, do not use earphones while driving or
cycling.
• Listening to loud sounds for prolonged periods of time
may permanently damage your hearing.
• Before putting on earphones, turn the volume
down then put the earphones on and slowly
increase the volume until you reach a comfortable
listening level.
4
Thank you for purchasing your new
product.
We recommend that you spend some time reading
this instruction manual in order that you fully
understand all the operational features it oers.
You will also nd some hints and tips to help you
resolve any issues.
Read all the safety instructions carefully before
use and keep this instruction manual for future
reference.
Unpacking
Remove all items from the packaging. Retain the
packaging. If you dispose of it please do so according to
local regulations.
The following items are included:
• Gaming Headset
• Microphone
• 3.5mm audio cable x 1
• Type C audio cable x 1
• Instruction Manual (downloadable)
• Software (downloadable)
5
Product Overview
1. Microphone
2. USB audio socket
3. 3.5mm audio socket
4. / Mute button
5. Volume control 1
23
45
6
Software Installation
1. Plug the unit into the USB port of your computer.
2. Download the latest gaming software from
http://ADXgaming.com/downloads
3. Run the software installer.
4. Follow the installation instruction to complete the
installation.
5. Choose ADX AFSH0520.exe from the desktop to start
the software.
• Software only works when the headset is
connected with the type C audio cable.
• The software is not available for MAC OS.
System Requirements
Operating Systems: Microsoft® Windows® 8 / 10
Hardware: 1 available USB port
7
Connections
Mobile Device
Computer
Game Controller
USB audio cable
Type C port will disable
while using the 3.5mm
audio cable.
8
Playback
Speakers
Out In
EQ KS SF
EM VF
VSS SMX
Speakers Out
44.1 KHz
2
Capture
Mic In
Volume Control
Master
8.00 dB
Front
-7.00 dB
-7.00
Mic
RL
User Interface
Choose ADX AFSH0520.exe from the desktop to start the
software.
1. Software Information.
2. Setting options.
3. Minimise the software.
4. Exit the software.
5. Enabled feature will be highlighted.
6. Switch between Status and Prole panel.
7. Adjust the volume.
8. Mute or restore the sound.
5
1 2
3 4
6 7 8
9
Open
Volume Control
Window Media Player
Sound Recorder
Multimedi Preperties
Settings
Exit
10:00
20/9/2020
Playback
Speakers
Out In
EQ KS SF
EM VF
VSS SMX
Speakers Out
44.1 KHz
2
Capture
Mic In
Volume Control
Master
8.00 dB
Front
-7.00 dB
-7.00
Mic
Volume Control
Sample Rate
Equalizer
Environment Effects
7.1 Virtual Speaker Shifter
Xear SingFX
Xear Surround Max
RL
Speaker Setting
Right click on to show a speaker menu.
1. Volume Control
2. Sample Rate
3. Equalizer
4. Environment Eects
5. Virtual Speaker Shifter
6. Xear SingFX
7. Xear Surround Max
Menu
Right click the icon from the system tray will pop up a
menu that links to Windows default software.
1. Open the headset software.
2. Open the default Windows Volume Control.
3. Open the default Windows Media Player.
4. Open the default Windows Sound Recorder.
5. Open the default Windows Multimedia Properties.
6. Open the headset software Settings.
7. Exit the headset software.
1
2
5
6
7
4
3
1
2
3
4
5
6
7
10
Playback
Speakers
Out In
EQ KS SF
EM VF
VSS SMX
Speakers Out
44.1 KHz
2
Capture
Mic In
Volume Control
Master
8.00 dB
Front
-7.00 dB
-7.00
Mic
RL
1. Volume Control
1
2
5
4
3
1. Adjust the volume.
2. Mute or restore the
sound.
3. Adjust the left or right
front speaker volume
individually.
4. Lock the left and right
speaker to adjust at once.
5. Range of volume in dB is
between -37.00 and 0.00.
Playback
Speakers
Out In
EQ KS SF
EM VF
VSS SMX
Speakers Out
44.1 KHz
2
Capture
Mic In
Sample Rate
Mic
44.1 KHz 48 KHz
2. Sample Rate
1. Choose a dierent audio sample rate of your choice.
1
