Advantech ASMB-584 Manual de instalación y operación
ASMB-584 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 ASMB-584 Startup Manual
• 1 Driver CD (user’s manual is included)
• 2 Serial ATA HDD data cables
• 2 Serial ATA HDD power cables
• 1 I/O port bracket
• 1 Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
http://www.adobe.com/downloads/ (Acrobat is a
trademark of Adobe)
LGA 1150 Intel® Xeon® E3 V3 Micro ATX Server Board
with 2 x PCIe x16 slots (x8 link), 1 x PCIe x4, 1 x PCI,
USB 3.0, PCIe Gen III, Dual LANs
Startup Manual
Standard SBC Functions
• CPU: LGA 1150 Intel® Xeon® E3 v3 processors
• BIOS: AMI 128 Mb SPI BIOS
• Chipset: Intel® C226
• System memory: Dual Channel DDR3 ECC/Non-ECC
1066/1333/1600 MHz unbuffered DIMM, Max. 32 GB
Note: Due to the inherent limitations of PC architecture,
the system may not fully detect 32 GB RAM
when 32 GB RAM is installed.
• SATA3 Interface: 6 SATA3 6Gb/s ports to support Intel
Matrix Storage with software RAID 0, 1, 10 & 5. (for
Windows only)
• Serial ports: Two serial ports, only supports RS-232
• Parallel port: One parallel port, supports SPP/EPP/ECP
modes.
• Keyboard/Mouse connector: Supports standard PS/2
keyboard and mouse via KMBS2 pin header
• Watchdog timer: 255 level timer intervals (sec)
• USB 3.0: Supports up to four USB 3.0 ports. Two ports
are in rear I/O, and two ports are on-board pin header.
• USB 2.0: Supports up to 9 USB 2.0 ports (1* Type-A)
VGA Interface
• Chipset: CPU integrated Intel HD graphics controller
• Display Memory: 1 GB maximum shared memory with 2
GB and above system memory installed
• Resolution:
- Supports RGB up to 1920 x 1200 resolution @ 60 Hz
refresh rate
- Supports DVI up to 1920 x 1200 resolution@ 60 Hz
refresh rate
- Supports DP up to 1920 x 1200 resolution@ 60 Hz
refresh rate (Both DP ports only support active dongle to
connect to HDMI/DVI monitor)
Ethernet Interface
• Interface: 10/100/1000 Mbps
• Controller: LAN1:Intel
®
I217LM; LAN2: Intel® I210-AT
Mechanical and Environmental
• Dimensions (L x W): 244 x 244 mm (9.6” x 9.6”)
• Power supply voltage: +3.3 V, +5 V, ±12 V, 5 Vsb
• Power consumption: Max. load: +3.3 V @ 3.7 A, +5 V @
2.22 A, +12 V @ 0.07 A, +12 V (8P) @ 3.77 A, +5 Vsb @
0.12 A, -12 V @ 0.02 A
• Operating temperature: 0 ~ 60° C (Depends on CPU
speed and cooler solution)
• Weight: 0.5 kg (weight of board)
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/applied-computing-
systems/
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/new_de-
fault.aspx
This manual is for the ASMB-584 series Rev. A1
Part No. 2006S58410
Print in China
1st Edition,
May 2013
2 ASMB-584 Startup Manual
Connector list
LANLED1 LAN1/2 LED extension con-
nector
VOLT1 Voltage Display
AUDIO1 Audio Connector
DP1 Display Port 1
DP2 Display Port 2
SGPIO1 Serial General Purpose I/O
JFP1 Power Switch / Reset connector
JFP2 External speaker / HDD LED
connector/ SM Bus connector
JFP3
Keyboard Lock and Power LED
Suspend: Fast flash (ATX/ AT)
System On: ON (ATX/ AT)
System Off: OFF (ATX/AT)
SPDIF_OUT1 SPDIF Audio output pin header
BMC1 BMC connector to support IPMI-
1000 module
Jumper list
Label Function
JCMOS1 CMOS clear
JME1 Intel ME Disable Jumper for ME/
BIOS update
JWDT1 Watch Dog Reset
JUSB1, JUSB2
On board USB port (USB 2, 3,
6 ~ 12) power source switch
between +5 VSB and +5 V
CPUFAN_
SEL1,SYSFAN_SEL1
FAN PWM(1-2)/DC mode selec-
tion(2-3)
PSON1 AT(1-2) / ATX(2-3)
JCASE1 Case Open
JPEG2 PCIEX16_SLOT6 PCIe Link sw-
tich between one x8 or two x4
The board has a number of jumpers that allow you to con-
figure your system to suit your application. The table below
lists the function of each jumper and connector.
Connector list
Label Function
ATXPWR1 ATX 24 Pin main power connec-
tor (for System)
ATX12V1 Processor power connector(for
CPU)
SATA0~5 SATA III (6Gb/s)
USB6_7, USB8_9,
USB10_11 USB 2.0 Port 6~11 (Header)
USB12 USB 2.0 Port 12 (USB Type A)
USB2_3 USB 3.0 Port 2 3 (Header)
PCI_SLOT4 PCI slot
PCIEX4_SLOT5 PCIE x4 slot
PCIEX16_SLOT6,
PCIEX16_SLOT7 PCIE x16 slots (x8 link)
DIMMA0,DIMMA1,
DIMMB0,DIMMB1 DDR3 slot
CPUFAN0 CPU FAN connector
SYSFAN0,SYSFAN1,
SYSFAN2,SYSFAN3 System FAN connector
LAN1_USB0_1,
LAN2_USB4_5
LAN1 / USB 3.0 port 0, 1 stack
connector
LAN2 / USB 2.0 port 4, 5 stack
connector
VGA1 VGA connector
DVI1 DVI-D connector
KBMS2 External keyboard and mouse
connector(6 pin)
SPI_CN1 SPI flash card pin header
LANLED1 LAN LED extension connector
SMBUS1 SM Bus From PCH
GPIO1 8-bit GPIO header
FPAUD1 Audio front panel header
LPT1 Parallel port
COM1~2 Serial port: RS-232
PMBUS1 PMBUS connector to communi-
cate with power supply
LPC1 Low pin count connector for
Advantech TPM LPC modules
Jumpers and Connectors
ASMB-584 Startup Manual 3
JCMOS1: CMOS clear function
Pins
Result
1-2 Keep CMOS data*
2-3
Clear CMOS data
*: Default
JWDT1: Watchdog timer output option
Closed Pins
Result
1-2 System reset*
2-3 NC
*: Default
PSON1: ATX, AT mode selector
Closed Pins
Result
1-2 AT Mode
2-3 ATX Mode*
*: Default
Keep CMOS data Clear CMOS data
1 2 3
1 2 3
System Reset 1-2 Closed NC 2-3 Closed
1 2 3
1 2 3
AT Mode 1-2 closed ATX Mode 2-3 closed
1 2 3
1 2 3
The CD disc contains a driver installer program that will
lead you through the installation of various device drivers
needed to take full advantage of your motherboard.
The computer is supplied with a battery-powered realtime
clock circuit. There is a danger of explosion if battery is
incorrectly replaced. Replace only with same or equivalent
type recommended by the manufacturer. Discard used bat-
teries according to manufacturer’s instructions.
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired opera-
tion
Jumpers and Connectors Software Installation
Declaration of Conformity
4 ASMB-584 Startup Manual
Board Layout: Jumper and Connector Locations
Board Layout
FPAUD1
COM2
COM1
AUDIO1
LAN2_USB4_5
LAN1_USB0_1DP2
VGA1 +
DV I1
PCIEX16_SLOT7
DP1
SPDIF_OUT1 SYSFAN3
LPT1
KBMS2
ATX12V1
LANLED1
PCIEX4_SLOT5
PCI_SLOT4
JPEG2
KBMS2
GPIO1
USB10_11
USB8 9
DIMMB1
DIMMA1
DIMMB0
PCIEX16_SLOT6
USB8
_
9
USB6_7
USB2_3JCASE1
SYSFAN SEL1
DIMMA0
BMC1
SYSFAN1
SPI_CN1
USB12
SYSFAN
_
SEL1
ATXPWR1
PMBUS1
0 2 4
SATAIII
JME1
JUSB1
SYSFAN1
VOLT1
PMBUS1
SMBUS1
CPUFAN_SEL1
JFP3
JCMOS1
1 3 5
JFP1+
JFP2
SYSFAN2
SGPIO1
JWDT1
CPUFAN0LPC1
PSON1
SYSFAN0
3 6 9 12
25811
PWRSW RESET
HDDLED
SNMP
JFP1
&
25 8 11
1 4 7 10
HDDLED
SM_BUS
SPEAKER
JPF2
&
PWRLED & KEYLOCK
12345JFP3
