Advantech FPM-3170 Series Manual de usuario

FPM-3170 Series

Industrial Flat Panel

Monitor with 17" LCD in

VGA/Video

User Manual

FPM-3170 Series User Manual ii

This document is copyrighted by Advantech Co., Ltd. All rights are

reserved. Advantech Co., Ltd. reserves the right to make

improvements to the products described in this manual at any time. Spec-

ifications are thus subject to change without notice.

No part of this manual may be reproduced, copied, translated, or transmit-

ted in any form or by any means without the prior written permission of

Advantech Co., Ltd. Information provided in this manual is intended to

be accurate and reliable. However, Advantech Co., Ltd., assumes no

responsibility for its use, nor for any infringements upon the rights of

third parties which may result from its use.

All brand and product names mentioned herein are trademarks or regis-

tered trademarks of their respective holders.

This Manual Covers the Following Models

- FPM-3170G

- FPM-3170G-R

- FPM-3171GA

- FPM-3171GA-R

Part No 2003317000 1st Edition

Printed in Taiwan March 2005

FCC Class B

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interfer-

ence when the equipment is operated in a residential environment. This

equipment generates, uses and can radiate radio frequency energy. If not

installed and used in accordance with this user's manual, it may cause

harmful interference to radio communications. Note that even when this

equipment is installed and used in accordance with this user’s manual,

there is still no guarantee that interference will not occur. If this equip-

ment is believed to be causing harmful interference to radio or television

reception, this can be determined by turning the equipment on and off. If

the interference is occurring, the user is encouraged to try to correct the

interference by one or more of the following measures:

•Reorient or relocate the receiving antenna

•Increase the separation between the equipment and the receiver

•Connect the equipment to a power outlet on a circuit different from that

to which the receiver is connected

•Consult the dealer or an experienced radio/TV technician for help

FPM-3170 Series User Manual iv

Additional Information and Assistance

1.Visit the Advantech web site at www.advantech.com where you can

find the latest information about the product.

2.Contact your distributor, sales representative, or Advantech's customer

service center for technical support if you need

additional assistance. Please have the following information ready before

you call:

•Product name and serial number

•Description of your peripheral attachments

•Description of your software (operating system, version, application

software, etc.)

•A complete description of the problem

•The exact wording of any error messages

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User's Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a damp

cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the equip-

ment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or let-

ting it fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment

from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place anything

over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power

source to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be

opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service

personnel:

a. The power cord or plug is damaged.

b. Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

d. The equipment does not work well, or you cannot get it to work according to

the user's manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED

ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW

-20° C (-4° F) OR ABOVE 60° C (140° F). THIS MAY DAMAGE THE

EQUIPMENT.

The sound pressure level at the operator's position according to IEC 704-1:1982 is

no more than 70dB(A).

DISCLAIMER: This set of instructions is given according to IEC 704-1. Advan-

tech disclaims all responsibility for the accuracy of any statements contained

herein.

FPM-3170 Series User Manual vi

W i c h t i g e S i c h e r h e i s h i n w e i s e

1. Bitte lesen sie Sich diese Hinweise sorgfältig durch.

2. Heben Sie diese Anleitung für den späteren Gebrauch auf.

3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie

Keine Flüssig-oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur

Reinigung.

4. Die NetzanschluBsteckdose soll nahe dem Gerät angebracht und leicht

zugänglich sein.

5. Das Gerät ist vor Feuchtigkeit zu schützen.

6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen

oder Fallen könnte Verletzungen hervorrufen.

7. Die Belüftungsöffnungen dienen zur Luftzirkulation die das Gerät vor überhit-

zung schützt. Sorgen Sie dafür, daB diese Öffnungen nicht abgedeckt werden.

8. Beachten Sie beim. AnschluB an das Stromnetz die AnschluBwerte.

9. Verlegen Sie die NetzanschluBleitung so, daB niemand darüber fallen kann. Es

sollte auch nichts auf der Leitung abgestellt werden.

10. Alle Hinweise und Warnungen die sich am Geräten befinden sind zu

beachten.

11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten Sie es vom

Stromnetz trennen. Somit wird im Falle einer Überspannung eine Beschädigung

vermieden.

12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder Flüssigkeiten

in das Gerät gelangen. Dies könnte einen Brand bzw. elektrischen Schlag aus-

lösen.

13. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen

Sicherheit nur von authorisiertem Servicepersonal geöffnet werden.

14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen

und von einer qualifizierten Servicestelle zu überprüfen:

a - Netzkabel oder Netzstecker sind beschädigt.

b - Flüssigkeit ist in das Gerät eingedrungen.

c - Das Gerät war Feuchtigkeit ausgesetzt.

d - Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert oder

Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen.

e - Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.

f - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.

Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt

70dB(A) oder weiger.

DISCLAIMER: This set of instructions is given according to IEC704-1. Advan-

tech disclaims all responsibility for the accuracy of any statements contained

herein.

Table of Contents

Contents

Chapter 1 Introduction ..................................................... 2

1.1 Introduction ....................................................................... 2

1.2 Specifications .................................................................... 2

1.2.1 General ........................................................................... 2

1.2.2 Touchscreen (Optional) ................................................. 3

1.3 LCD Specifications ........................................................... 3

1.4 Connectors......................................................................... 4

1.5 Dimensions........................................................................ 5

Figure 1.1:FPM-3170G Dimensions .............................. 5

Figure 1.2:FPM-3171GA Dimensions ........................... 6

Chapter 2 System Setup.................................................... 8

2.1 Mounting the Monitor ....................................................... 8

2.1.1 Wall Mounting ............................................................... 8

Figure 2.1:FPM-3170 with Brackets ............................. 8

Figure 2.2:Hook Bracket ................................................ 8

2.1.2 Panel Mounting .............................................................. 9

Figure 2.3:Panel Mnt. (cut out dim.: 451 x 340 mm) .... 9

Figure 2.4:Bracket Arranged for Panel Mounting ......... 9

2.1.3 Rack Mounting ............................................................ 10

Figure 2.5:Rack Mounting ........................................... 10

2.2 Desktop Mounting........................................................... 11

Figure 2.6:FPM-3170 Mounted on Desktop Stand ...... 11

Figure 2.7:A Complete Desktop Stand ........................ 11

2.3 Swing Arm Mounting...................................................... 12

Figure 2.8:Swing Arm for the FPM-3170 series ......... 12

Appendix A Touchscreen Driver Installation .................. 14

A.1 Introduction ..................................................................... 14

A.2 Touchscreen Specifications............................................. 14

A.2.1 Electrical ...................................................................... 14

A.2.2 Optical .......................................................................... 14

A.2.3 Mechanical ................................................................... 14

A.2.4 Durability ..................................................................... 14

A.2.5 Chemical Resistance .................................................... 15

A.3 Installation of Touchscreen Driver.................................. 15

A.4 Configuring PenMount Windows 2000/XP Driver......... 20

A.4.1 PenMount Control Panel ............................................. 20

A.4.2 PenMount Monitor Menu Icon .................................... 30

A.4.3 PenMount Rotating Functions ..................................... 31

Appendix B Supported Input Timing Modes .................. 34

B.1 Supported Input Timing Modes ...................................... 34

Appendix C OSD Operation .............................................. 36

C.1 OSD Operation Keypad .................................................. 36

1 Chapter1

Introduction

This chapter includes:

•Introduction

•Specifications

•LCD Specification

•Connectors

•Dimensions

CHAPTER

FPM-3170 Series User Manual 2

Chapter 1 Introduction

1.1 Introduction

Advantech's FPM-3170 Series consist of 17" color TFT LCD flat panel

monitors built specifically for industrial applications. With the optional

touchscreen, FPM-3170 monitors are excellent and user-friendly system

control interfaces.

The FPM-3170 Series includes the FPM-3170G and FPM-3171GA.

FPM-3170G comes standard with Direct-VGA, DVI-D, Video, S-Video

ports, which not only can connect to popular PC VGA Cards, but also

devices with video output, like cameras.

FPM-3171GA provides an alternative solution for users that do not

require Video interface, and is equipped with a Direct-VGA port.

The whole chassis of FPM-3170G and FPM-3171GA is made of stainless

steel, and the front panel is of aluminum with NEMA4/IP65 compliance.

The FPM-3170 monitors provide optional touch screen versions (FPM-

3170G-R and FPM-3171GA-R). With an 8-wire resistive type touch-

screen, the monitors can be immediately transformed into a remote con-

trol system.

1.2 Specifications

1.2.1 General

• Control: OSD (On Screen Display) control pad on front side

• Mounting: Rackmount, panelmount, wallmount and VESA arm

mounting

• I/O port: VGA connector, DVI (FPM-3170G only), Video (FPM-

3170G only), S-Video (FPM-3170G only), DC power input, power

switch (FPM-3170G only), and RS-232 port (Touchscreen version

only)

• Power Adapter: External 48W power adapter, with AC 100~230V

input and DC +12V @ 4A output

• Operating temperature: 0 ~ 50 ° C

• Storage Temperature: -20 ~ 60 ° C

• Storage Humidity: 5 ~ 95% non-condensing

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de Advantech

Advantech

Advantech PAX-332 Series Manual de usuario

Advantech

Advantech USC-M6 Series Manual de instalación y operación

Advantech

Advantech IDS-3106N-80VGA1E Manual de usuario

Advantech

Advantech IDP-31101W Manual de usuario

Advantech

Advantech IDS31-190 Manual de usuario

Advantech

Advantech IDK-1108R-45SVA1E Manual de usuario

Advantech

Advantech IDK-1110P-series Manual de usuario

Advantech

Advantech iHealthcare POC-W213 Manual de instrucciones

Advantech

Advantech IDK-2112 Series Manual de usuario

Advantech

Advantech FPM-3155 Series Manual de usuario

Advantech

Advantech PAX-327 Series Manual de usuario

Advantech

Advantech IDS-3206 Series Manual de usuario

Advantech

Advantech KT-E240FEE Manual de instrucciones

Advantech

Advantech ProFlat IDP-31215W Manual de usuario

Advantech

Advantech PDC-W240 Manual de instrucciones

Advantech

Advantech DSD-5028 Series Manual de usuario

Advantech

Advantech IDS-3106 Series Manual de usuario

Advantech

Advantech IDS-3117 Series Manual de usuario

Advantech

Advantech KT-D213U8B Manual de usuario

Advantech

Advantech RMD-1150F-8 Manual de usuario

Advantech

Advantech FPM-5152G Series Manual de usuario

Advantech

Advantech IDK-1112P-50XGA1 Manual de usuario

Advantech

Advantech POC-WP242 Manual de usuario

Advantech

Advantech PAX-327-C8 Series Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
