Advantech FPM-30CT Manual de usuario
FPM-30
Flat Panel Monitor with
10.4" Color TFT LCD Display
Copyright Notice
This document is copyrighted by Advantech Co., Ltd. All rights
are reserved. Advantech Co., Ltd., reserves the right to make
improvements to the products described in this manual at any time.
Specifications are thus subject to change without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of Advantech Co., Ltd. Information provided in this
manual is intended to be accurate and reliable. However, Advan-
tech Co., Ltd., assumes no responsibility for its use, nor for any
infringements upon the rights of third parties which may result
from its use.
All brand and product names mentioned herein are trademarks or
registered trademarks of their respective holders.
Part No. 2002030020, 1st Edition
Printed in Taiwan, November 1996
Contents
Chapter 1 Introduction..................................1
Checklist ................................................................................. 2
Introduction............................................................................ 2
Specifications.......................................................................... 3
Flat Panel Displays................................................................. 4
Connectors .............................................................................. 5
Connection Diagram.............................................................. 6
Dimensions.............................................................................. 7
Chapter 2 System Setup...............................9
Wall Mounting ..................................................................... 10
Panel Mounting .................................................................... 11
Exploded Diagram ............................................................... 12
Chapter 1 Introduction 1
1
Introduction
This chapter includes:
•Checklist
•Introduction
•Specifications
•Flat Panel Displays
•Connectors
•Connector Diagram
•Dimensions
CHAPTER
2FPM-30 User's Manual
Checklist
nFPM-30
nAccessory Pack, including:
•FPM-30 User's Manual
•PCA-6653 Manual
•PCA-6653 Disk
•PCA-6653 Video Display Card
•Component Bag
•Screw Bag
Introduction
Advantech's FPM-30 series flat panel monitors are a state-of-the-art
alternative to conventional CRT monitors. They offer the traditional
advantages of flat panel displays — small-size, light weight and low
power consumption — with the added security of a rugged
NEMA4/12 (IP52/56) compliant design.
The flat panel monitor package includes an ISA-bus video display
card and your choice of flat panel displays: color TFT/DSTN LCD,
B/W LCD. The display card supports simultaneous use of LCD
panels and analog CRT monitors. A shielded 1.8 meter cable con-
nects the FPM-30 and the video display card, allowing remote
operation. Add an optional touchscreen to create the ultimate user
interface. The FPM-30's compact size and extended range allow easy
placement in almost any location.
Chapter 1 Introduction 3
Specifications
General
•Construction: Heavy-duty aluminum and steel chassis
•Front panel: NEMA 4/12 (IP 52/56)
•Control: One waterproof brightness/contrast adjustment knob
(monochrome series only)
•Mounting: Panelmount or wallmount
•Dimensions:
Width: 13.0" (330 mm)
Height: 9.5" (242 mm)
Depth: 2.0" (50 mm)
•Weight: 7.7 lbs (3.5 kg)
Video Display Card
•Model: PCA-6653
•Board: 16-bit ISA-bus, half-size
•Video Chip: CHIPS 65545
•Memory: 1 MB on board, frame buffer 512 KB (optional)
•Max. Resolution: 1024 x 768 for both flat panel and CRT displays
•Connectors: One DB-44 connector for flat panel display
One DB-15 connector for CRT
•Simultaneous CRT/LCD display: Available with TFT, B/W LCD
•Power Consumption: +5 V @ 1 A, max.
Touchscreen (optional)
•Type: Analog resistive
•Resolution: Transmission @ 75%
•Controller: RS-232 interface
•Power Consumption: +5 V @ 200 mA
•Software drivers: DOS and Windows supported
•Life cycle: 30 Million touches
•Surface: Meets ASTM-D-1044 standard (Taber Abrasion Test)
4FPM-30 User's Manual
Flat Panel Displays
Model FPM-30CT FPM-30M
Display Type TFT Color LCD Mono LCD
Size (diagonal) 10.4" 10.4"
Max. Resolution 640 x 480 640 x 480
Max. Colors 256 K Colors 64 Greyscale levels
Viewing Angle 90º 50º
Dot Size (mm) 0.33 x 0.33 0.33 x 0.33
Luminance (cd/m2) 160 70
LCD Model Toshiba
LTM10C042
or compatibles
Sharp LM64P89
or compatibles
Temperature 0 ~ 50º 0 ~ 45º
VR Controls N/A Contrast
Simultaneous Mode Yes Yes
LCD MTBF 50,000 hours 50,000 hours
Backlight MTBF 10,000 hours 10,000 hours
Chapter 1 Introduction 5
Connectors
The following connectors are situated on the left hand side of the
FPM-30. Also refer to the diagram overleaf.
Video I/O Port (DB-44)
This connector links the FPM-30 to the PCA-6653 display card. The
figure below shows how to connect the DB-44 to the PCA-6653.
Note: The Display card provides power to the FPM-30; no external
power is required.
WARNING: Make sure that your display card corresponds
with your choice of display! If you install a TFT LCD display
card and connect a Mono LCD, or vise versa, you risk
damaging your display. Do not use any VGA card other than
the PCA-6653 shipped with this panel display.
Touchscreen Connector (DB-9) (optional)
This connector will be present only if a touchscreen is installed. It
must be connected to the RS-232 port of the CPU card in your chassis.
The touchscreen cable is included with all orders which include the
touchscreen option.
External Keyboard Connector
The FPM-30 provides an external keyboard connector to let you
attach a PC/AT standard keyboard. The figure below shows the
correct wiring method. Be sure the internal keyboard connector
between PCA-6653 (EXT.KBD) and the CPU card (KBD) has been
connected.
6FPM-30 User's Manual
Connection Diagram
Chapter 1 Introduction 7
Dimensions
Unit: mm
