Advantech MIC-3000 Series Manual de usuario

Advantech CompactPCI™

Modular Industrial Computer

MIB-3081A

6U-8-slot backplane

with CT bus and rear I/O

for CompactPCI™

MIB-3081A User Manual --- Page

This document is copyrighted, 2003. All rights are reserved. The original manufacturer

reserves the right to make improvements to the products described in this manual at

any time without notice.

No part of this manual may be reproduced, copied, translated or transmitted in any

form or by any means without the prior written permission of the original manufacturer.

Information provided in this manual is intended to be accurate and reliable. However,

the original manufacturer assumes no responsibility for its use, nor for any

infringements upon the rights of third parties which may result from its use.

Acknowledgements

PICMGTM, CompactPCI TM and the PICMG TM, CompactPCI TM logos are trademarks of the

PCI Industrial Computers Manufacturers Group

All other product names or trademarks are properties of their respective owners.

Part Number: 2008308110 1st Edition

Printed in Taiwan July 2003

MIB-3081A User Manual --- Page

III

Product warranty

Advantech warrants to you, the original purchaser, that each of its productswill be free

from defects in materials and workmanship for one year from the date of purchase.

This warranty does not apply to any products which have been repaired or altered by

persons other than repair personnel authorized by Advantech, or which have been

subject to misuse, abuse, accident or improper installation.

Advantech assumes no liability under the terms of this warranty as a consequence of

such events.

Because of Advantech’s high quality-control standards and rigorous testing, most of

our customers never need to use our repair service. If an Advantech product is

defective, it will be repaired or replaced at no charge during the warranty period. For

out-of-warranty repairs, you will be billed according to the cost of replacement

materials, service time and freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, CPU speed,

Advantech products used, other hardware and software used, etc.) Note anything

abnormal and list any on-screen messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your manual, product, and

any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandize

authorization) number from your dealer. This allows us to process your return more

quickly.

4. Carefully pack the defective product, a fully-completed Repair and Replacement

Order Card and a photocopy proof of purchase date (such as your sales receipt) in a

shippable container. A product returned without proof of the purchase date is not

eligible for warranty service.

5.Write the RMA number visibly on the outside of the package and ship it prepaid to

your dealer.

MIB-3081A User Manual --- Page

Packing List

Before installation, ensure that the following materials have been received:

* The MIB-3081A backplane

* This user’s manual in PDF

If any of these items are missing or damaged, contact your distributor or sales

representative immediately.

Technical Support and Sales Assistance

If you have any technical questions about the MIB-3081A or any other Advantech

products, please visit our support website at:

• http://www.advantech.com.tw/support

For more information about Advantech's products and sales information, please visit:

• http://www.advantech.com

MIB-3081A User Manual --- Page

Contents

1.Introduction....................................................................................1

1.1 General Information ........................................................................... 2

1.2 Features ........................................................................................... 3

1.3 Specification ..................................................................................... 4

2. Hardware Configuration .................................................................... 5

2.1 Slot Assignments ............................................................................... 6

2.2 Connector and Jumper Locations .......................................................... 9

2.3 Ground Configuration ........................................................................ 14

2.4 Computer Telephony Bus ................................................................... 15

2.5 Clock Routing Configuration ............................................................... 15

B. Pin Assignments ............................................................................. 17

B.1 System Slot P1 Connector (1-P1) .............................................................. 18

B.2 System Slot P2 Connector (1-P2) .............................................................. 19

B.3 System Slot P3 Connector (1-P3) .............................................................. 20

B.4 System Slot P4 Connector (1-P4) .............................................................. 21

B.5 System Slot P5 Connector (1-P5) .............................................................. 22

B.6 Peripheral Slot P1 Connector (2-P1 to 8-P1) ............................................... 23

B.7 Peripheral Slot P2 Connector (2-P2 to 8-P2) ............................................... 24

B.8 Peripheral Slot P3 Connnector (2-P3 to 8-P3) .............................................. 25

B.9 Peripheral Slot P4 Connector (2-P4 to 8-P4) ............................................... 26

B.10 Peripheral Slot P5 Connector (2-P5 to 8-P5) .............................................. 27

B.11 Alarm Board Interface Connector (CN8) ................................................... 28

B.12 Fan Module Connector (FAN1 ~ FAN6) ...................................................... 28

B.13 ATX Power Connector (ATX1 and ATX2) ................................................... 29

B.14 Power Connector for Peripherals (CN1and CN2) ....................................... 30

B.15 Power Switch Connector (CN4) ................................................................ 30

MIB-3081A User Manual --- Page

Figures

Figure 2-1: Slot numbering of the MIB-3081A ..................................................7

Figure 2-2: The connector and jumper locations on the front side ....................... 10

Figure 2-3: The connector and jumper locations on the rear side ......................... 11

MIB-3081A User Manual --- Page

VII

Tables

Table 2-1: System to peripheral slot signal assignment ........................................8

Table 2-2: MIB-3081A Connector and jumper description ...................................9

Table 2-3: V I/O voltage selection ................................................................... 13

Table B-1: System slot P1 connector ............................................................... 18

Table B-2: System slot P2 connector ............................................................... 19

Table B-3: System slot P3 connector ............................................................... 20

Table B-4: System slot P4 connector ............................................................... 21

Table B-5: System slot P5 connector ............................................................... 22

Table B-6: Peripheral slot P1 connector ........................................................... 23

Table B-7: Peripheral slot P2 connector ........................................................... 24

Table B-8: Peripheral slot P3 connector ............................................................ 25

Table B-9: Peripheral slot P4 connector ........................................................... 26

Table B-10: Peripheral slot P5 connector .......................................................... 27

MIB-3081A User Manual --- Page

Introduction

MIB-3081A User Manual --- Page

1.1 General Information

The MIB-3081A is a 6U-sized CT backplane that provides eight CompactPCI slots. One

slot is assigned to the CPU board and seven slots to the peripheral boards. The

MIB-3081A supports front and rear I/O wiring, providing simplified system cabling. The

backplane also complies with PICMG 2.5 Computer Telephony Specification, providing

H.110 CT bus on the P4 connectors.

The MIB-3081A provides 3-pin connector for connecting up to six cooling fans. A 26-pin

connector can be used for connecting an external alarm module (MIC-3924 series) to

detect system internal conditions, such as bus voltages and fan speed. In order to

provide users with a flexible system configuration, the MIC-3081 includes two standard

ATX power connectors to accept up to two ATX power supplies.

The MIB-3081A complies with PICMG 2.1 Hot-Swap Specification, providing full

hot-swapping capability. Users can build a hot-swap system using hot-swap plug-in

boards and software.

1.2 Features

-Front and rear I/O supports

-H.110 CT bus compliant (PICMG 2.5)

-Eight 32-bit CompactPCI slots (64-bit upon request)

-Complies with PICMG 2.1 Hot-Swap Specification

-Accepts up to two ATX power supplies

-Alarm module interface

-Fan interface

1.3 Specification

· 8 CompactPCI slots (one system slot and 7 peripheral slots)

· Front and rear I/O supports

· Bus width: 32-bit (64-bit upon request)

· 8-layer PCB, 3.0 mm thick

· Separate power and ground planes

· Power connectors: Two ATX power connectors for connecting standard ATX power

supplies

· 26-pin connector for MIC-3924 alarm board signals

· Complies with CompactPCI Specification PICMG 2.0, Ver.2.1

MIB-3081A User Manual --- Page

· Complies with CompactPCI Hot Swap Specification PICMG 2.1, Ver.1.0

· Complies with Computer Telephony Specification PICMG 2.5, Ver.1.0

· V I/O Voltage: 3.3 V or 5 V, jumper selectable

· Logic Ground and Chassis Ground can be isolated or common

· Dimensions: 183.5 x 262.2 mm

· Operating temperature: -40 ~ 80°C (-40 ~ 176°F)
