Advantech AMAX-3245 Manual de usuario
User Manual
AMAX-3245
AMAX-3245 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2019
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Intel® and Pentium® are trademarks of Intel Corporation.
All other product names or trademarks are properties of their respective owners.
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact your local supplier for
ordering information.
Part No. 2003X32410 Edition 1
Printed in Taiwan December 2019
iii AMAX-3245 User Manual
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Technical Support and Assistance
1. Visit the Advantech web site at http://support.advantech.com.cn support where
you can find the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (OS, version, application software, etc.)
–A complete description of the problem
–The exact wording of any error messages
AMAX-3245 User Manual iv
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.
v AMAX-3245 User Manual
Contents
Chapter 1 Introduction..........................................1
1.1 Introduction ............................................................................................... 2
1.2 Features .................................................................................................... 2
1.3 Hardware Specifications ........................................................................... 2
1.3.1 Axis ............................................................................................... 2
1.3.2 Digital Input ................................................................................... 2
1.3.3 Digital Output ................................................................................ 3
1.3.4 Pulse Input .................................................................................... 3
1.3.5 Pulse Output ................................................................................. 3
1.3.6 General ......................................................................................... 4
Chapter 2 Hardware Wiring ..................................5
2.1 Dimensions ............................................................................................... 6
2.1.1 Top view........................................................................................ 6
2.1.2 Front View..................................................................................... 6
2.1.3 Side View ...................................................................................... 6
2.2 Connection Terminal ................................................................................. 7
2.2.1 Rotary switch (SW1-2) .................................................................. 7
2.2.2 Power terminal (CN1) ................................................................... 7
2.2.3 D-Sub Output Terminal (CN2-CN5) .............................................. 8
2.2.4 5-pin Motion Control Signal Connectors (CN6-CN9) .................... 8
2.2.5 6-pin general output connectors (CN10)....................................... 9
2.2.6 6-pin quick connectors (CN11) ..................................................... 9
2.2.7 LED Indicators .............................................................................. 9
Chapter 3 Hardware Wiring ................................11
3.1 Output Pulse [CW±/PULS±, CCW±/DIR±] .............................................. 12
Figure 3.1 Optocoupler Interface ............................................... 12
Figure 3.2 Linear Drive Interface ............................................... 12
3.2 Over Traveling Limit Switch Input [LMT+/-] & Home (ORG) ................... 13
Figure 3.3 Circuit Diagram of Limit Input Signals and Home (CN6-
CN9) ......................................................................... 13
3.3 Position latch [LTC] ................................................................................. 13
3.4 In-Position Signal [INP] ........................................................................... 13
3.5 Alarm [ALM] ............................................................................................ 13
3.6 Encoder Input [ECA+/-, ECB+/-, ECZ+/-] ................................................ 14
Figure 3.4 Circuit Diagram of Encoder Feedback...................... 14
3.7 Emergency Stop Input [EMG] ................................................................. 14
Figure 3.5 Circuit Diagram of Emergency Stop Input Signal ..... 14
3.8 External Power Input [VEX]..................................................................... 14
3.9 Activate Servo ON [SVON] ..................................................................... 14
3.10 Servo Error Counter Clear [ERC]............................................................ 15
3.11 Position Compare Output [CMP]............................................................. 15
3.12 Digital Input (CN10)................................................................................. 15
3.13 Digital Output (CN11).............................................................................. 16
Figure 3.6 Circuit Diagram of General Output (Non-Inductive
Load) ........................................................................ 16
Figure 3.7 Circuit Diagram of General Output (Inductive Load) 16
AMAX-3245 User Manual vi
Chapter 1
1Introduction
AMAX-3245 User Manual 2
1.1 Introduction
The AMAX-3245 is an 4-axis EtherCAT pulse module that can connect to the upper
EtherCAT motion control card PCI/PCI-1203 and pulsed stepper and servo motors.
The open frame design makes it convenient to connect to Mitsubishi J3/J4, Yaskwa
Sigma V/7 and Panasonic A4/A5 servo motor drives via a dedicated cable through
the D-sub 26-pin interface.
In addition to high-precision motion interpolation, continuous contouring and axes
synchronization, the AMAX-3245 also offers high-speed position comparison trigger
(Compare Trigger) and latch (Latch) functions, making it ideal for a variety of automa-
tion industry applications.
1.2 Features
Max. 5 MHz pulse output
Up to 32 bit incremental encoder input. Encoder input is 2.5 MHz for CW/CCW
mode, 2.5 MHz for 4xAB mode.
Suitable for DIN-rail mounting; terminal on the module which can be directly
connected to third party servo drive
Easily visible LED indicators on board to do diagnosis
Programmable interrupt
Memory buffer (10K points) for trajectory planning
2-axis position compare triggering up to 100 KHz, and memory buffer is up to
100 K points
Position latch
Supports gantry control
1.3 Hardware Specifications
1.3.1 Axis
1.3.2 Digital Input
Item Description
Number of axes 4
Control type Pulse
Item Description
Channels LMT+,LMT-, ORG, INP, ALM, EMG, LTC
Type Single-ended, optical isolation
Input voltage:
L (max) 4Vdc
H (min) 10Vdc
H (max) 30Vdc
Max. input delay time 100Us
Input impedance 6kΩ
Protection 1,000V isolation
3 AMAX-3245 User Manual
Chapter 1 Introduction
1.3.3 Digital Output
1.3.4 Pulse Input
1.3.5 Pulse Output
Item Description
Channels SVON, ERC, RST, CMP
Type Single-ended, optical isolation, sink (Sink)
Operating voltage Low 10Vdc
High 30Vdc
Max. sink current 100mA/ channel
Max. output delay time 100us
Protection 1,000V isolation
Item Description
Max. frequency 2.5MHz x1, x2, x4 (A/B phase only)
Type Differential, optical isolation
Input voltage
L (max) 1Vdc
H (min) 3.5Vdc
H (max) 5Vdc
Min. width for H / L pulse 200ns
Item Description
Max. frequency 5Mpps
Type Differential, optical isolation
Output voltage
L (max) 0.7Vdc
H (min) 2Vdc
H (max) 3.9Vdc
Output current 3VDC/18mA
Output signal mode Linear drive differential output
Control range 32bit
AMAX-3245 User Manual 4
1.3.6 General
Item Description
Connection terminal
2 x RJ-45: network interfaces
1 x Terminal block (4P) for power input
4 x Terminal block (5P) for home and Limit
1 x Terminal block (6P) for 4DI
1 x Terminal block (6P) for 4DO
4 x DB-26: connect servo drive
Dimension 165 x 75 x 56 mm (6.5 x 2.9 x 2.2")
Certification CE, FCC Class A
Power consump-
tion: MAX 6W (250mA @ 24V)
Temperature Operating 0~60 °C (refer to IEC 60068-2-1,2)
Storage -20~85 °C
Relative humidity: 5~95% RH non-condensing (refer to IEC 60068-2-3)
External Power Voltage DC +24 V
