AdvanPOS WP-T800 Manual de usuario
1 Station Thermal Line
Receipt Printer
Model: WP-T800
Version: 1.05
WP-T800 1 Station Thermal Line Printer
- 1 -
CONTENTS
1. GENERAL DESCRIPTION 3
1.1 OVERVIEW ..................................................................................................... 3
1.2 FEATURES ...................................................................................................... 3
1.3 ACCESSORIES ................................................................................................ 3
2. SPECIFICATION 4
2.1 MAIN SPECIFICATIONS ..................................................................................... 4
2.2 OPERATING SPECIFICATIONS............................................................................ 6
3. EXTERNAL APPEARANCE AND PART DESCRIPTIONS 6
4. INSTALLATIONS 8
4.1 HOW TO CONNECT POWER ADAPTER................................................................ 8
4.2 HOW TO CONNECT CASH DRAWER ................................................................... 9
4.3 SETTING OF THE PRINTER COVER AND SETTING PAPER.................................... 10
5. CONTROL PANEL 12
5.1 BASIC OPERATION ........................................................................................ 12
5.2 SWITCH OPERATION (COMBINED SWITCH OPERATION) ..................................... 13
5.3 SETTING ...................................................................................................... 14
6. INTERFACE SPECIFICATIONS 17
6.1 CHANGING THE INTERFACE CARD.................................................................... 17
6.2 SERIAL INTERFACE SPECIFICATIONS ................................................................ 17
6.3 PARALLEL INTERFACE SPECIFICATIONS ............................................................ 19
6.4 USB(P) INTERFACE SPECIFICATIONS .............................................................. 19
6.5 ETHERNET INTERFACE SPECIFICATIONS........................................................... 21
7. DRAWER KICK CONNECTOR 22
7.1 SPECIFICATIONS ........................................................................................... 22
7.2 CONNECTOR’S PIN CONNECTION.................................................................... 22
7.3 DRIVE CIRCUIT ............................................................................................. 22
8. COMMAND 22
8.1 CONTROL CODES LIST................................................................................... 23
9. CHARACTER CODE TABLES 31
9.1 INTERNATIONAL CHARACTER SETS.................................................................. 31
9.2 CODE PAGE:00H TO 7FH ............................................................................. 32
9.3 CODE PAGE:PC437 (USA, EUROPEAN STANDARD)........................................ 33
9.4 CODE PAGE:KATAKANA (JAPANESE)............................................................... 34
9.5 CODE PAGE:PC850 (MULTILINGUAL)............................................................. 35
9.6 CODE PAGE:PC860 (PORTUGUESE).............................................................. 36
WP-T800 1 Station Thermal Line Printer
- 2 -
9.7 CODE PAGE:PC863 (CANADIAN-FRENCH) ..................................................... 37
9.8 CODE PAGE:PC865 (NORDIC) ...................................................................... 38
9.9 CODE PAGE:PC852 (EASTERN EUROPE)....................................................... 39
9.10 CODE PAGE:PC866 (RUSSIAN)................................................................... 40
9.11 CODE PAGE:PC857 (TURKISH) ................................................................... 41
9.12 WINDOWS CODE PAGE ................................................................................ 42
10. EXTERNAL DIMENSIONS 43
WP-T800 1 Station Thermal Line Printer
- 3 -
1. GENERAL DESCRIPTION
1.1 Overview
The WP-T800 Series Line Thermal Receipt Printer is designed for use with ECR,
electronic instruments, computer peripheral equipment, kitchen printers and so
on.
1.2 Features
1. Compact desktop Line Thermal printer.
2. Easy loading designed for dropping the paper roll
3. Interface conformity to RS-232C, centronics ,USB port depends on the
Interface card which is remove able and other option of Interface for different
application.
4. Command protocol is compatible with ESC/POS.
5. 2 drawer kick-out.
6. The resident data buffer has storage capacity of about 128K-bytes, enable
data to be received even while printing.
7. Support download bit image, directly bit image and bar-code printing.
8. The sensors include paper end, paper near end and cover sensor.
1.3 Accessories
The following parts are included in this set of printer. Please confirm.
Paper roll (1 roll)
Power adapter (1 unit)
Power core (1 unit)
User’s manual and driver CD (1 unit)
Option( one of items below will be included)
Cable for RS-232C (depend on RS-232C interface card) (1 unit)
Cable for Centronics (depend on Centronics interface card) (1 unit)
Cable for USB (depend on USB interface card) (1 unit)
WP-T800 1 Station Thermal Line Printer
- 4 -
2. SPECIFICATION
2.1 Main Specifications
Item Description
1 Printing method Thermal line
2 Printing speed 220mm / s
3 Command ESC/POS
4 Driver Linux, Windows and OPOS
5 Character structure Alphanumeric( A) Alphanumeric( B) Kanji
12×24 9×17 24×24
6 Columns 80mm/58mm 42 / 37 columns 56 / 49 columns 21 / 18 columns
7 Character size 1.50(W) x 3.00(H) 1.13(W) x 2.15(H) 3.00(W) x 3.00(H)
8 Density 203dpi
9 Fonts Multilingual code page x 12, Chinese, Japanese, Thai, Korean,
Others
10 Bar code UPC-A, UPC-E, EAN13, EAN8, CODE39, CODE93,
CODABAR, CODE128, ITF
11 Detectors Paper end, Paper near end, Cover, Printer head overhead and
Cutter jam
12 Paper Single-ply thermal paper roll
13 Paper roll size 79.5 ±0.5 (W) x 83 mm (Dai.)
14 Paper thickness 0.05 ~ 0.06 mm
15 Drawer output 2
16 Reliability Head 100 km or more
Cutter 1000,000 times
17 Memory
Buffer 4k bytes
SRAM 128k bytes
Flash 512k bytes
18 Power supply +24 VDC / 2.5 A
19 Interface RS-232C, Parallel, USB and Ethernet are optional
20 Gross weight 2.70 kg
21 External dimension 140(W) x 190(D) x 135(H)mm
WP-T800 1 Station Thermal Line Printer
- 5 -
22 Temperature Operating 0 ~ 45℃
Storage -10 ~ 50℃
23 Humidity Operating 10 ~ 90 ％RH
Storage 10 ~ 90 ％RH
WP-T800 1 Station Thermal Line Printer
- 6 -
2.2 Operating Specifications
Item Specifications
Temperature/
Humidity
Operating
0 to 45℃(41 to 113℃F),0 to 90% RH no
condensation allowed.(Refer to ambient
operating ranges in the figure below.)
Storage:(shipped packed state) -10 to +50℃(14 to 122℃F),10 to 90% RH
(excluding paper)
34 40 45
Temperature
〔℃〕
〔%RH〕
90%
65%
50%
65
0
90
WP-T800 1 Station Thermal Line Printer
- 7 -
3. EXTERNAL APPEARANCE AND PART DESCRIPTIONS
1 Printer cover
2 Cover open lever
3 Cutter cover
4 Power switch
5 Control panel
6 DIP switch cover
7 Interface connector
8 Power connector
9 Cash Drawer connector
WP-T800 1 Station Thermal Line Printer
- 8 -
4. INSTALLATIONS
4.1 How to Connect Power Adapter
(1) Ensure that the power switch is OFF.
(2) Plug the power connector into the printer’s power connector at the arrow mark
facing upward.
(3) Plug the power cord into the outlet, and turn on the power.
(4) Connector Specifications shows as below:
Pin Number Signal Name
1 +24VDC
2 GND
3 NC
Shell Frame GND
WP-T800 1 Station Thermal Line Printer
- 9 -
4.2 How to Connect Cash Drawer
(1)Ensure that the power switch is OFF.
(2)Plug the cash drawer connector into the Drawer kick out connector at the arrow
mark facing upward.
(3)Plug the connector into the RJ11 phone jack.
Note: Power for drawer kick out is 24vdc, if voltage of cash drawer is different, it
may cause cannot open situation or harm the cash drawer.
