Futuresun HP V2
Sunlamp Model HP 24/22: HELIX™
US: "Future Sun HP"
Owner’s Manual
Vers. V.02 /February 2007
2
Futuresun HP V2
Control Panel
1Display Shows accrued session time, information on operational conditions/status of
the unit and error codes
2Button “START” Starts the tanning session
3Button “STOP” Stops the tanning session
4Button “+”
In combination with pre-selected function, this button
increases the intensity of the facials
increases the speed of the body cooling fans
increases the (music) volume
(re)activates the facials or the AC unit
5Button “–”
In combination with pre-selected function, this button
reduces the intensity of the facials
reduces the speed of the body cooling fans
reduces the (music) volume
turns off the facials or the AC unit
6Button “Shoulder
Tanner”
Pre-selects the function for the control of the active shoulder tanner
(ON/OFF)
(only for units with this optional feature)
7Button “Facials” Pre-selects function for control of the facials
8Button “Cooling Top” Pre-selects function for control of air vent cooling at the head-end
9Button “Cooling Bench” Pre-selects function for control of air vent cooling at the bench, head- and
foot-end.
10 Button “Add. Fan
Shoulder Tanner”
Pre-selects function for control of the additional cooling fan at the active
shoulder tanner
(only for units with this optional feature)
11 Button “AC-unit” Pre-selects function for control of AC-unit (ON/OFF)
12 Button “SunFresh” Activates SunFresh-Watermist
(only for units with active shoulder tanner)
13 Button “Music” Pre-selects function for control of music volume
14 Button “SunHaze-
Aroma”
Activates SunHaze-Aroma-System
(only for units with active shoulder tanner)
3
Futuresun HP V2
Unit without active shoulder tanner (standard
version)
1Bench acrylic 8Air vents at head-end of the bench
2Hinge profile at bench acrylic 9Control panel
3Air vents at foot-end of the bench 10 Facials
4Endcaps bench (left and right) 11 Air vents at head-end of the top
5Body cooling Fan (air intake) 12 Top profile and handle
6Front cover plate 13 Backlighting at top canopy
7LED backlighting at front cover plate
4
Futuresun HP V2
Unit with active shoulder tanner (optional)
1Bench acrylic 8Active shoulder tanner
2Hinge profile at bench acrylic 9Control panel
3Air vents at foot-end of the bench 10 Facials
4Endcaps bench ( left and right) 11 Air vents at head-end of the top
5Body cooling fan (air intake) 12 Top profile and handle
6Front cover plate 13 Backlighting at top
7LED backlighting at front cover plate
5
Futuresun HP V2
Rear view of the unit
1Exhaust air stack
2Fan for body cooling at the facials
3Entry stud for supply cables of external timer and loudspeakers
4Entry stud for power supply
5Type labels
1
2
3
4
5
6
Futuresun HP V2
Inside view of bench with components
1SunHaze aroma system (optional)
2Aroma cartridge for SunHaze system (optional)
3SunFresh-container (optional)
4Condensation water (AC) container (optional)
5AC unit (optional)
6Ballasts inserts
7Ballast tray
8Power supply for purification system inside SunFresh container
7
Futuresun HP V2
Preface
The purpose of this manual is to assist you in the
safe and proper installation and operation of the high
performance tanning unit Sunlamp Model HP 24/22:
HELIX™, herein referred to as “Futuresun HP” or
“sunbed”
This manual is addressed to:
service personnel,
authorized and skilled electrical personnel,
qualified tanning salon personnel and
end-users
Every person who
transports,
assembles,
starts,
operates,
set the controls,
maintains,
cleans,
disassembles,
stores or
disposes of
this sunbed has to make sure that this manual has
been carefully read and that its contents is fully
understood. Keep this manual in a place close to the
sunbed for further reference.
Format
Various elements in this manual show a standardized
format to make it easier to distinguish between
standard text elements,
detailed lists or
steps of action
These notes contain hints and
information on the economic use of the
sunbed.
References to chapters are set in italics.
8
Futuresun HP V2
Description
The Futuresun HP is a high-performance tanning bed
exclusively designed for use in commercial tanning
salons.
The technical layout was designed for power,
performance and reliability.
The unit is equipped with 22 low-pressure lamps, 20
high-intensity body, 2 high-intensity shoulder(optional)
and 4 high-intensity facials.
The filters and reflectors used for the facials and body
have received several layers of a proprietory coating,
which focuses and filters the tanning efficient UV-light.
The infra-red emission (heat) is conveyed back into
the unit. This technology and the integrated design
of filters, reflectors and lamps allow for an increased
tanning intensity at lower wattages and reduced
energy consumption.
The equipment ventilation was designed for fault-free
operation under heavy duty use with back-to-back
sessions. The intensity of the body cooling can be
individually adjusted as well as the direction of the
airflow. As an additional option an air conditioning unit
provides a well-tempered tanning ambience.
With the electronic control panel the user can choose
individual set-ups for AC-unit, body cooling, intensity
of facials, music volume etc. during a tanning session.
The display also shows accrued session time. On the
operator level a special code gives access to various
set-up selections and maintenance options.
The Futuresun HP can be equipped with additional
features. Optional features are the active shoulder
tanner with two HID fields which emit additional
tanning power for the shoulder region. A strong
turbo fan provides extra cooling for the face and
upper body area. In combination with the active
shoulder tanner the SunHaze aroma function and the
SunFresh watermist option are also available. The
turbo fan conveys the selected aroma into the tanning
tunnel and maskss the typical tanning odor. With the
SunFresh option there is a special nozzle located
at the Turbo fan which sprays a finely vaporised
watermist onto the upper body region. Both functions
are available to the customer on an “on demand”
basis.
Further options are loudspeakers, air conditioning unit
incl. condensation water container and pump, heat
recycling system and accessories for connecting the
unit to the on-site exhaust system.
9
Futuresun HP V2
Safety Instructions
In this chapter you will find information on the proper
and improper use of the sunbed, obligations of the
operator, residual risks and general and specific
dangers.
Read this chapter carefully prior to first operating the
sunbed.
The operator is obliged to make sure that all safety
instructions are known, understood, and strictly
observed.
If you sell or in any other way dispose of the sunbed,
include this Owner’s Manual with the shipment.
Please send the name, address,
phone or fax number of the new owner
immediately to Advanced UV Light or its
authorized local/national distributor in
order to provide up-dates about important
or unexpected safety actions to the new
owner.
Safety instructions – further
details
In this manual you find the following categories of
safety instructions and notices:
DANGER!
Notices containing the
word DANGER refer to a
dangerous situation which
can result in fatal or serious
injuries.
WARNING!
Notices containing the
word WARNING refer to a
dangerous situation which
can eventually result in
fatal or severe injuries or
damages to goods and
property.
CAUTION!
Notices containing the
word CAUTION refer to a
situation which can result
in minor injuries or damages
to goods and property.
Obligations of the Operator
Advanced UV Light GmbH is not responsible for any
damages caused by improper use of the sunbed or
disregard of the instructions provided in this manual.
The operator of the Futuresun HP must ensure that
only skilled and authorized personnel assembles
this sunbed ready for use and operates, maintains,
and cleans it.
The operator must make the following documents
available to all staff performing transport and
assembly work, and/or performing operation,
maintenance and cleaning jobs:
– this manual,
– all applicable standards and regulations for the
prevention of accidents at the work place and
provisions for a safe workplace-environment,
– all additional national standards which are
applicable.
Operator must also ensure that all safety
instructions are strictly observed.
Operator guarantees that only skilled personnel
with the necessary expertise assembles this
sunbed ready for use and only specifically trained
staff operates, maintains and cleans this sunbed.
Before and during any use of the sunbed, the
operator or a person authorized by the operator
must ensure that:
– the proper use of the sunbed is guaranteed and
– all safety standards are observed.
10
Futuresun HP V2
Proper Use of the Sunbed
Only adults whose skin is suitable for cosmetic
tanning are allowed to use this sunbed.
The following persons are not allowed to use a
sunbed:
children and young adolescents under age,
persons with increased sensitivity to UV-light,
persons with allergic reactions caused by UV-light
exposure,
persons with skin diseases who should not tan,
persons with coronary and circulatory diseases,
persons with a history of skin cancer or an
hereditary inclination of developing skin cancer
persons with symptoms of disease,
persons with other unidentified health problems,
or persons with pacemakers
under medication or using medication which may
have adverse effects in combination with UV-light
exposure.
Proper use of the sunbed include observation of the
following directives:
observe recommended exposure times according
to individual skin type at all times!
always wear protective eye-wear!
Operate this sunbed only in commercial tanning
salons, fitness studios or beauty salons subject to
the supervision and control of specifically trained
staff.
Proper use of this sunbed also includes diligent
consideration of all the information provided in this
manual and especially to follow all safety instructions.
Every other use of the sunbed is regarded as
improper and may result in damages to goods or
property and eventually cause serious personal harm.
Advanced UV Light GmbH is not responsible for
damages or injuries caused by improper use.
Improper Use of the Sunbed
The use of this sunbed by
children or young adolescents under age,
persons suffering from diseases,
persons with pacemakers,
persons disregarding the recommended exposure
times
persons not wearing protective eye-wear
are improper uses of this sunbed and may cause
serious personal harm.
Advanced UV Light GmbH is not responsible for
personal damages caused by improper use.
Notice of Residual Risks
This sunbed is designed according to state-of-the-
art standards and in compliance with current safety
regulations, as well as relevant technical standards.
The construction is designed to prevent potential
dangers or to make provisions for eventual risks.
In spite of these provisions, there still remain residual
risks when using this sunbed.
Eventual risks for persons, as well as goods and
property, can be caused by:
operation of the sunbed in an improper way,
use of the sunbed in an improper way
transportation of the sunbed in an improper way,
the start up/turn off of the sunbed in an improper
way,
maintenance or cleaning in an improper way.
Otros manuales para Future Sun HP
1
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Cama de bronceado de ADVANCED UV LIGHT
