Advance acoustic SC250 Guía del usuario

9435 Winnetka Avenue North

Brooklyn Park, MN 55445

www.advance-us.com

Phone 800-850-5559

Fax 800-989-6566

240 Superior Boulevard

Mississauga, Ontario, Canada L5T 2L2

www.nilﬁsk-advance.ca

Phone 800-668-8400

Fax 80 0 -263 -5111

ATTENTION! Do not use the machine before you have read and understood the Instructions for Use Manual.

2. Fill the solution tank with water.

The water temperature must not

exceed 105° F (40° C).

3. The tank cap can be used for dosing

the detergent. One full cap is 30 ml

giving 0.5% detergent of the 1.6 gal

(6 L) tank capacity. (*)

4. Adjust the handle to the desired

height. Turn the machine on with

the power button.

1. Disconnect the battery charger cord

from the machine and electrical

outlet.

17. Clean the debris collection tray.16. Clean the squeegee bars and

the cylindrical brush with water.

Check for wear and replace

when necessary.

15. Remove the squeegee bars.

Remove the cylindrical brush by

turning the side knob clockwise.

13. Remove the cover and clean it with

hot water. Remove the ball ﬂoat

cage along with the ﬂoat and

clean them thoroughly.

12. Empty the recovery and solution

tanks. Clean them out with water.

11. For transporting and parking the

machine, push the pedal down

(slightly lift the front of the machine

by tilting the handlebar).

9. For double scrubbing, press the

vacuum suction button to switch the

vacuum off.

10. Turn the machine off with the

power button.

5. Lift the pedal to lower the machine

and start working.

6. Grab the handles to activate the

brush and solution ﬂow, then start

cleaning the ﬂoor.

7. Press the solution button to select

the type of cleaning required.

8. For sweeping functions, lift/lock the

right lever to lift the front squeegees

in order to collect light debris.

When ﬁnished using

14. Check and clean the solution and

vacuum ﬁlters regularly.

19. Charge the batteries: Connect

the battery charger cord from the

machine to an electical outlet.

18. Clean the machine using a damp

cloth and where needed use a

neutral cleaning product.

20. Store the machine in a clean and

dry place.

(*) ALWAYS FOLLOW THE DETERGENT DOSING RECOMMENDATION ON THE LABEL OF THE CHEMICAL PRODUCT USED.

USE AND MAINTENANCE

SC250™

9435 Winnetka Avenue North

Brooklyn Park, MN 55445

www.advance-us.com

Phone 800-850-5559

Fax 800-989-6566

240 Superior Boulevard

Mississauga, Ontario, Canada L5T 2L2

www.nilﬁsk-advance.ca

Phone 800-668-8400

Fax 80 0 -263 -5111

ATTENTION! Do not use the machine before you have read and understood the Instructions for Use Manual.

The machine

doesn’t work

as it should?

The suction

doesn’t work

as it should?

The machine

doesn’t clean

as it should?

The brush

doesn’t work

as it should?

TROUBLESHOOTING

SC250™

1. Adjust the brush pressure by turning

the regulation knob.

2. Check for brush wear, and make

sure that it is installed correctly.

3. Check to see if there is debris that is

preventing the brush from rotating.

1. Check if the battery is charged. 2. Check if the battery is correctly

ﬁtting in the machine. (*)

3. Machine fault indicated by LED’s

blinking. (*)

(*) For these causes the maintenance

procedure must be performed by an

authorized Advance Service Center.

For further information refer to the

Service Manual, available at any

Advance Service Center.

1. Check if the recovery tank is full. 2. Check if dirt and debris are clogging

the squeegee inlet and if the blades

are worn or damaged.

3. Rinse the inside of the duct recovery

hose with water.

4. Check if the ﬂoat cage is clean.

1. Check to see if the solution ﬁlter is

dirty. Clean it if necessary.

2. Check if the holes in solution

dispensers are clogged. Remove

them and clean if needed.

3. Check to make sure the quick

connect valve is not leaking.
