Flat Panel Transfer Board (FPTB)

User's Manual

Manual Revision: 2.00

Revision Date: August 9, 2012

Part Number: 50-1J040-1000

Document History

Revision Date Changes

2.00 2012/08/09 Initial Release

2 FPTB User's Manual

Preface

Disclaimer

The information in this document is subject to change without prior notice in order to improve reliability,

design, and function and does not represent a commitment on the part of the manufacturer. In no event will

the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of

the use or inability to use the product or documentation, even if advised of the possibility of such damages.

This document contains proprietary information protected by copyright.

All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic, or other

means in any form without prior written permission of ADLINK Technology Inc.

Trademark Information

COM Express®is a registered trademark of the PCI Industrial Computer Manufacturers Group (PICMG).

Product names mentioned herein are used for identification purposes only and may be trademarks and/or

registered trademarks of their respective companies.

FPTB User's Manual 3

Table of Contents

Preface ................................................................................................................. 3

1Introduction................................................................................................. 5

1.1 Overview....................................................................................................... 5

1.2 Functional Block Diagram............................................................................. 5

1.3 Mechanical Drawing ..................................................................................... 6

1.4 Applications .................................................................................................. 7

2Connectors and Jumpers .......................................................................... 9

2.1 Board Layout ................................................................................................ 9

2.2 Connector Pin Definitions........................................................................... 10

2.3 Jumper Settings.......................................................................................... 13

3Getting Started.......................................................................................... 14

3.1 Jumper Settings.......................................................................................... 14

3.2 LVDS Input to FPTB................................................................................... 15

3.3 TTL Output to Display Panel....................................................................... 16

3.4 FPTB Power Connector.............................................................................. 16

3.5 Power Up the System................................................................................. 16

Technical Support ............................................................................................. 17

4 FPTB User's Manual

Introduction

1.1

Overview

The Flat Panel Transfer Board (FPTB) is intended for prototyping and verification of LVDS

and TTL flat panel displays with COM Express systems. The FPTB is equipped with an

LVDS-to-TTL converter to allow users to implement TTL displays with COM Express systems

that support LVDS only. Onboard PWM circuitry supports backlight control for LVDS and TTL

displays.

1.2

Functional Block Diagram

LVDS Signal Output

(CN6)

TTL Signal Output

(CN5)

LVDS-to-TTL Converter

(DS90CF386)

LVDS Signal Switch Array

(PI3USB20)

Backlight Control

(CN8)

PWM Circuitry

TTL

LVDS

LVDS Signal Input

from COM Express carrier

(CN4)

LVDS_SMCLK/SMDAT signals

FPTB User's Manual 5

1.3

Mechanical Drawing

Dimensions in mm.

6 FPTB User's Manual

1.4

Applications

The FPTB is intended for use in the following situations:

•nanoX/Express-BASE →FPTB →Customer’s cable to TTL display: This

configuration provides LVDS-to-TTL conversion and backlight control when using an

ADLINK reference carrier board with a TTL display. User must provide the cable

connection from the FPTB's TTL output and backlight control connectors to the TTL panel

inputs.

TTL Display

FPTB

TTL

Signal

5V and

12V Input

Backlight

control

nanoX/Express-BASE

Carrier Board

LVDS output

LVDS-to-LVDS cable

ADLINK P/N: 30-20449-0000

•Customer carrier (with LVDS output) →Customer’s cable to FPTB →HannStar

LVDS panel: This configuration provides backlight control and convenient verification of

LVDS function when using a customer carrier board with the HannStar 10.1” LVDS flat

panel display. User must provide the cable connection from the customer carrier board

LVDS output to the FPTB's LVDS input connector.

ADLINK P/N: 29-90100-F000

Backlight

control

LVDS

signal

ADLINK P/N: 30-20243-2000

Customer

Carrier Board

LVDS output

5V and

12V Input

FPTB

FPTB User's Manual 7

•Customer carrier (with LVDS output) →Customer’s cable to FPTB →FPTB →

Customer’s cable to TTL panel: This configuration provides LVDS-to-TTL conversion

and backlight control when using a customer carrier board with a TTL display. User must

provide the cable connections from the customer carrier board LVDS output to the

FPTB's LVDS input connector and from the FPTB's TTL output and backlight control

connectors to the TTL panel inputs.

TTL Display

Customer

Carrier Board

LVDS output

FPTB

TTL

Signal

5V and

12V Input

Backlight

control

•Customer carrier (with LVDS output) →Customer’s cable to FPTB →FPTB →

Customer’s cable to other LVDS panel: This configuration provides backlight control

when using a customer carrier board with a customer LVDS flat panel display. User must

provide the cable connection from the customer carrier board LVDS output to the FPTB's

LVDS input connector and from the FPTB's LVDS output and backlight control

connectors to the LVDS panel inputs.

LVDS Display

Customer

Carrier Board

LVDS output

FPTB

LVDS

Signal

5V and

12V Input

Backlight

control

8 FPTB User's Manual

Connectors and Jumpers

2.1

Board Layout

FPTB (Flat Panel Transfer Board) Connector and Jumper Locations

Connector Description

CN1 Power Connector

CN4 LVDS Input Connector

CN5 TTL Output Connector

CN6 LVDS Output Connector

CN8 Backlight Control Connector

JP1 Backlight Voltage Jumper

JP2 Panel Voltage Jumper

JP4 LVDS/TTL Mode Selector Jumper

JP5 Backlight Control Mode Jumper

FPTB User's Manual 9

2.2

Connector Pin Definitions

CN1: Power Connector (Floppy power connector)

Pin Signal

1 +5V

2 GND

3 GND

4 +12V

CN4: LVDS Input Connector (2x17 box header, 2.00 mm pitch)

Pin Signal Pin Signal

1 LVDS_CLK_A 2 LVDS_DTA_A

3 PNL_PWR 4 PNL_PWR

5 GND 6 LVDS_A-N0

7 LVDS_A-P0 8 VDD_EN

9 LVDS_A-N1 10 LVDS_A-P1

11 BL_EN_2 12 LVDS_A-P2

13 LVDS_A-N2 14 N.C

15 LVDS_ACLK _ N 16 LVDS_ACLK _ P

17 PNL_PWR 18 LVDS_A-P3

19 LVDS_A-N3 20 GND

21 LVDS_B-N0 22 LVDS_B-P0

23 GND 24 LVDS_B-N1

25 LVDS_B-P1 26 GND

27 LVDS_B-N2 28 LVDS_B-P2

29 GND 30 LVDS_BCLK _ P

31 LVDS_BCLK _ N 32 N.C

33 LVDS_B-P3 34 LVDS_B-N3

10 FPTB User's Manual
