Adexa EP-1ST Manual de usuario
Electric Pizza Oven
EP-1ST
EP-2ST
User’s Manual
Thank you for purchasing and using this product.
In order to make full use the appliance and reduce the unnecessary loss and damage,
please read this book carefully and keep it for file for reference.
WARNING!
！This appliance is not apply to physical, sensory or metal defect or people who
lack of experience or knowledge (includes child);
！Any refitting, incorrect installation, adjustment and maintenance may cause
wealth damage and death. Please contact the supplier and ask the trained
professionals to adjust and maintain the product.
！Do not store any flammable or corrosive gas, liquid or substances near the
appliance.
！Do use the standard power. The appliance must be grounding safely for
safety before using.
！Do not use any sharp or hard substance to damage the surface of the body or
heating element.
1. Parameters:
Model EP-1ST EP-2ST
Voltage 220-240V/50Hz 220-240V/50Hz
Input power 2000W 3000W
Chamber layer 1 2
Chamber dimension
L×W×H mm 410x400x120 410x400x120
Outline dimension
L×W×H mm 580x561x275 580x561x435
Temp. range 50~350°C 50~350°C
Timing range 120min 120min
Temp. Fuse 360℃360℃
Net weight（kg）20 33
2. Exterior Structure
EP-1ST
EP-2ST
3. Installation
1、The electric connection should be done by the certificated stuff. The ground wire should be
firm.
2、Locate the appliance on a stable place which avoid water.
3、The service voltage should be identical with the supply voltage. Please install disconnecting
device with at least 3 mm distance on the fixed circuit. It is suggested to install a leakage
protection switch.
NOTICE!
！If the appliance is installed close to the wall, clapboard, kitchen equipments
or decoration plate, please use inflammable materials with these equipments.
Otherwise, cover these equipments with inflammable insulation materials and
pay attention to fire safety regulations.
！If the radiant heater is closed to other appliance or area, please make them
with inflammable materials. Otherwise, they should be covered with
inflammable materials and pay attention to fire safety regulations.
4. Instruction:
1、Make sure the service voltage is corresponding with the rated voltage and grounding is safety
before installation.
2、Do not put any substances on the top of the appliance during operation, especially the
flammable substances, like towel or clothes.
3、Please stop using and cut off the power if any error happens.
NOTICE!
The appliance will have smoke for the first time to use. Please rotate the
thermostat to 200℃and plug in with nothing for 30 minutes to discharge the
humidity before roasting.
5. Maintenance
1．Make sure to cut off the power before cleaning and maintenance for safety.
2．Make sure the appliance has cooled down before cleaning and maintenance.
3．Clean the appliance with wet towel with non-corrosive cleaner after using daily.
NOTICE!
！DO NOT CLEAN THE APPLIANCE WITH SPRAYING WATER.
6. Circuit Diagram
7. Troubleshooting
1、Make sure the power is cut off before maintenance.
2、It is prohibited to short the circuit after the thermal circuit breaker is damaged.
NO. Error Reason Repair
1 Do not work The power is not on Connect the power
2 The leakage
protection switch is
stripped
The electric components
leakage
Stop using and repair
3 The heating time is
too long
The power is not
corresponding with the
requirements
Heating elements damaged
Connect the electric as required
Stop using and repair
4 The temperature is
out of control
Temperature sensor drop off
Temperature control
components damaged
Fix the temperature sensor
Stop using and repair
NOTICE!
！The maintenance should be done by the certificated stuff. Otherwise, the
inspection by other people could be dangerous.
！If the power soft wire is damaged, please change it with oil proof soft
protection jacket (No. 57 of GB/T 5013.1（IEC 60245，IDT）bought from the
manufactory or maintenance department. Otherwise, they should be changed
by the stuff from similar department.
ADEXADIRECTLIMITED
GROUNDFLOORUNIT1214PURLEYWAYCROYDONCR04XGLONDONUNITEDKINGDOM
ECDeclarationofConformity
AdexaDirectLimiteddeclaresthat:
EquipmentType: Electricpizzaoven
Model:EP‐1ST,EP‐2ST
ImportedBy:ADEXADIRECTLIMITED
GROUNDFLOORUNIT1214PURLEYWAYCROYDONCR04XG
LONDON,UNITEDKINGDOM
SerialNumber:
YearofManufacture:
Brand:ADEXA
ApplicationofCouncilDirective(s):EMC2014/30/EU
LVD2014/35/EU
Standards:
EN55014‐1:2017
EN61000‐3‐2:2014
EN61000‐3‐3:2013
EN55014‐2:2015
EN60335‐1:2012+A11:2014+A13:2017
+A1:2019+A2:2019+A14:2019
EN60335‐2‐36:2002+A1:2004+A2:2008+A11:2012
EN62233:2008
I,theundersigned,herebydeclarethattheequipmentspecifiedaboveconformstotheabove
Directive(s)andStandard(s).
Date: 01.09.2017
Signature:
FullName:HakanBaykal
Position:PurchaseManager
