Addonics Technologies NAS2XU2 Manual de usuario

Technical Support

If you need any assistance to get your unit functioning properly, please have your

product information ready and contact Addonics Technical Support at:

Hours: 8:30 am - 6:00 pm PST

Phone: 408-453-6212

Email: http://www.addonics.com/support/query/

v5.1.11

T E C H N O L O G I E S

www.addonics.com

User Guide

NAS 2.0 Adapter

(NAS2XU2)

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

For more detailed information on setting up the NAS2XU2 adapter, refer to the

User Manual located on the CD that came with the device.

The NAS 2.0 adapter is a flexible, economical and powerful unit for your Network.

Follow the instructions to help you connect, setup, and configure it.

Note: Any external USB storage device that you connect to the NAS 2.0 adapter

will initially be required to be formatted. This means, if you are connecting an external

USB drive with data on it, the hard drive will be formatted erasing all the information.

Network Environment

There are 3 different setup conditions you can choose:

A. Setup NAS2XU2 as a DHCP Client:

If the NAS2XU2 is connected to a LAN network with an active

DHCP server, it will obtain an IP address from DHCP server

automatically.

B. Setup NAS2XU2 as DHCP Server:

If your LAN network does not have an active DHCP server, the

NAS2XU2 will immediately act as DHCP server and assign itself an

IP address for installation.

C. Setup NAS2XU2 in Static IP environment:

You first need to configure the IP address for NAS2XU2 to operate

in the static IP environment. For Configuring details, please refer to

“LAN Config” setup page.

Illustration of a NAS2XU2 connected over the network

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

I. NAS2XU2 Hardware Installation

1. Connect external USB Storage device into USB port of the NAS

Adapter. Power on the USB Storage device.

2. Connect LAN cable via LAN switch and Router.

3. Connect 5V power adapter to power up the NAS adapter

NAS2XU2 connected directly to a computer’s NIC card

If you connect the NAS2XU2 to a computer directly, the will act as a DHCP server,

assigning itself an IP address automatically and will also assign an IP address to the

computer’s network card. This configuration will not enable you to see the drive on

the network.

NAS2XU2 connected to a Router or Switch

When the NAS2XU2 is connected to a LAN network with an active DHCP server, it

will obtain an IP address from DHCP server automatically. Or if your LAN network

does not have an active DHCP server, NAS2XU2 will immediately act as DHCP

server and assign itself an IP address for installation.

II. Search NAS2XU2 using SDisk Utility

1. Browse the CD enclosed in the product package. Copy and paste

“SDisk Utility” in to your computer then double click the icon to start

search.

Note: “SDisk utility” was written with JAVA script, please make sure your computer

has installed JAVA before, if not please install the JAVA JRE from the CD drive.

Access LED

System LED

Power LED

5V Power Jack

Reset Button

RJ45 Socket USB Printer

USB Mass

Storage Device

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

2. When NAS2XU2 has been found, click “Connect” to enter web GUI

utility.

Open NAS2XU2 web GUI by using web browser.

1. Open web browser and type default host name “storage” in the

search bar.

2. Default login is “admin” for both User name and password. Click

“OK” to enter configurations.

Identification

You can change and modify your host, group name and password from this page.

Click “Apply” to save the setting.

Host name: This is used to identify your device on the network. If you prefer

a different name, type in the new name and click “Apply” to save setting.

Group Name: This should be the same as your workgroup. In general, the

default “WORKGROUP” will be OK. But if your workstation belongs to

different workgroup, type in the correct group name to modify.

For Window OS, right click on “My computer” and choose “Properties”, go to the

computer name tab to see your current workgroup.

If using a Mac OS system, to join a Windows workgroup, open the directory access

utility (under Applications-> utilities). Select SMB and click configure to modify the

settings (administrator access required to access this option.)

Note: We strongly suggest you to change the password as soon as you

logged in, to prevent unauthorized access.

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

LAN Configuration

By default, “LAN Config” is set to “Automatic IP”. This will allow the NAS2XU2 to

obtain its IP address automatically. If you prefer setting it manually, select the static

IP option, enter your own value and click “Apply” to confirm the new setting.

Disk Utility

In this page, you can manage hard disk settings of the USB storage device.

Format: For first time installation, you need to format hard disk into FAT32

file system. Formatting the drive will erase all data on the hard drive.

Warning: For hard drives with data on it, create a backup before

proceeding to format the hard drive!

Tip: You can transfer back the backup data to the NAS Public folder for

sharing via the network or USB connection of the USB Storage device.

Scan Disk: After the scan, it will show file content information and health

status for the hard disk.

To access Samba PUBLIC folder of NAS2XU2 in Windows

Click on the Windows icon located on the bottom left corner of the screen, on the

“Search programs and files” \\ followed by the IP address.

Eg:\\192.168.1.121 and press Enter key to continue.

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

Type “Guest” as username. Leave password empty. Click on OK.

This will direct you to the Public folder on the NAS drive.

Now you have set up the folder that you wish to share on your NAS . This folder can

be access from other computer on your local network.

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

To list the NAS drive in Network Places

Go to Network Places in Windows XP, under Network Tasks, click on the “Set

up a home or small office network”. Follow the wizard and once completed,

reboot your system.

For Vista and Windows 7, enable file sharing when accessing the NAS over

the network.

To access Samba PUBLIC folder of NAS2XU2 in Ubuntu 8.04

First, using the console get the prerequisites for the samba file system:

$ sudo aptitude install samba smbfs

$ mkdir /mnt/NAS

$ sudo mount.cifs //NAS__IP_address/Public /mnt/NAS -o username=Guest

To access Samba PUBLIC folder of NAS2XU2 in Mac OS X

1. Start at the "Go" drop down menu at the top of your screen,

then click "Connect to server".

2. Type into the "Server Address" field 'smb://' followed by the

IP address of the NAS2XU2 you want to connect.

3. Click the "Connect" button in the bottom right corner of the

window.

4. Enter in a username and password. Click the "OK" button in

the bottom right hand corner of the window to finish.

Note: The workgroup name needs to be the workgroup the

PC belongs to. If you don't know the workgroup that the PC

belongs to you can find out by right clicking on the "My

Computer" desktop icon on the PC, selecting "Properties"

and then selecting the "Computer Name" tab. The work

group name is about half way down the window.

5. Select the "share" you are after. This simply refers to a

particular group of shared files. Click "OK".

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

www.addonics.com

Phone: 408-573-8580

Fax: 408-573-8588

Email: http://www.addonics.com/sales/query/
