HF - VISION 10 & PHOENIX
Lighting Technologies
HF Remote Control
for VISION 10 and PHOENIX
Lighting Technologies
Instruction
Manual
ME 2103 1106.02.103
Page 2
Rev. : 002
HF - VISION 10 & PHOENIX
Lighting Technologies
Page 3
Rev. : 002
HF - VISION 10 & PHOENIX
Lighting Technologies
Summary
1. Introduction 4
2. Unpacking - Delivery 4
3. Generalities - Safety 5
4. Installation 6
4.1. Hardware 6
4.1.1. Components 6
4.1.2. Installation with one HF Receiver 7
4.1.3. Installation with more than one HF Receiver 7
4.2. Software 9
5. Quick Start 10
6. Operating Mode 11
6.1. Switch ON 11
6.2. Menu 12
6.2.1. Menu - Display 13
6.3. Standard Functional Operation 21
6.3.1. Direct Mode 21
6.3.2. Command Line Mode 21
6.4. Display Key History List 22
6.5. Special key functionalities 23
6.5.1. The SHIFT key 23
6.6. Switch OFF 23
7. Resetting the transmitter 24
8. Technical Characteristics 25
9. The Satellite Control Center Software 26
9.1. Before installation 26
9.2. Installating the software 26
9.2.1. SCC Set-up 26
9.3. Starting SCC 28
9.4. Main Screen 28
9.5. Configuration 29
9.5.1. Configuration - Communication 29
9.5.2. Configuration - Satellites 30
9.5.3. General 30
9.5.4. Terminals 31
9.5.5. Satellites / Receivers 31
9.6. Running SCC 35
9.6.1. Status 35
9.6.2. The Data screen display box 35
9.7. The About window 36
9.8. Exit 36
Page 4
Rev. : 002
HF - VISION 10 & PHOENIX
Lighting Technologies
1. Introduction
Welcome to the world of full HF remote controlling of show light!
TheADBHFremotecontrolsystemHFRemotesystemallowsyoutoremotecontrolany
ADB VISION 10 desk from wherever you are in your show venue: on stage, in the
auditorium, during the rigging on ladders, trusses etc.! This very compact and light
weight hand-held remote control unit offers you all the comfort to remote operate the
most important functions on your lighting desk:
•selecting individual lighting channels
•selecting pre-recorded memories and groups of channels
•operate playback submaster 1
•switching all channel sources off (Black-Out)
•re-playing pre-recorded macros
A user friendly software menu helps you to adjust and personalise specific operating
parameters
•password
•display back-lit on/off
•key operating mode (direct / command line)
•operation room id number
•product id number
•device auto sleep mode
A back-lit 4 x 16 character display on the hand-held terminal informs you about the
introduced key sequences in order to keep control over operations that can be
performed with 25 keys and over 40 different desk operate functions - and this during
an operating period of up to 12 hours with one battery charge cycle!
The GSM size hand-held system is very easy to handle and allows fast and intuitive
access to a huge variety of key desk functions to allow you to work efficiently on your
lightingshow.Afteraquickstarttourthatbrieflydescribeshowfasttoaccessthebasic
lighting functions, you will find in the following chapters how to access the whole range
of desk command functions and how to personalise the system to your specific needs.
Technical data and a trouble shooting summary should help you to safely install the
system.
2. Unpacking - Delivery
Upon delivery of your equipment, open the packing carefully and examine the material.
If you observe any damage, contact the shipping company immediately, and have your
complaint duly recorded. You may rest assured that your equipment left the factory in
perfect condition.
Check whether what you have received is in conformity with the delivery notice, and
whether the notice is in conformity with your order.
In the event of any error, contact your shipper immediately to clarify the situation and
receive full satisfaction.
Ifyoufindnothingwrong,replacethematerialinthepackingandstoreitinawarmplace,
away from dust and humidity, whilst awaiting final installation.
Never leave the material on the worksite under any circumstance
Page 5
Rev. : 002
HF - VISION 10 & PHOENIX
Lighting Technologies
3. Generalities - Safety
The equipment is built in accordance with European safety standards and requires
imperatively a safety earth connection in compliance with local regulations.
To prevent any risk of electric shock, do not remove any cover or part of the enclosure.
Access to internal parts is not required for normal operation.
Refer servicing to skilled and trained service personnel exclusively.
Disconnect from the power supply prior to opening for inspection or service.
Connectiontoanyinappropriatepowersourcemayirreversiblydamagetheequipment,
itistheuser's responsibility to usetheequipmentforits intended purpose andtocheck
the equipment connected to it.
To obtain full benefits of the safety measures, the equipment shall be installed and
serviced by skilled and trained personnel exclusively.
Don't make any modification to the equipment.
ADB shall not accept any liability for material damages or injuries which may result from
unauthorised modifications.
Important Notice for Power Cables
Power supply cables and connectors are an important part of your equipment and
contribute to its safety.
•always use original power supply adapters only! Using any other psu may cause
irreversible damage to the unit.
•always use an isolator, main circuit-breaker or main fuses to interrupt the link;
never pull on the cable
•do not damage the cable or the connectors in any way, check them at each
installation or at regular intervals in a permanent installation
•do not tie together power supply cables and signal cables
Page 6
Rev. : 002
HF - VISION 10 & PHOENIX
Lighting Technologies
4. Installation
4.1. Hardware
There are two different installation types:
1. single receiver - one ore more transmitters; operating range 50-80m
2. up to 4 receivers - one ore more transmitters; operating range >50-80m
4.1.1. Components
The HF remote control unit comprises the following items:
Simple Point-To-Point Communication (50 - 80m)
item code adb code number
Transmitter 734A EMHF/V 6382,01,400
SAT Receiver RS232 REHF1/V 6382,01,410
containing:
- ext. 9V psu
- RS232 cable RJ45-DB25, 6m
- DB25/DB9 adapter
- wall mounting kit
Battery Charger BCHF/V 6172,30,030
containing:
- ext. 9V psu
Multiple Communication (up to 4 receivers; >50 - 80m)
item code adb code number
Transmitter 734A EMHF/V 6382,01,400
SAT Receiver RS485 REHF2/V 6382,01,420
containing:
- ext. 9V psu
- t-connector box
- RS485 cable T-box - SAT, 6m
- wall mounting kit
Converter RS485/RS232 CONHF/V 6382,01,430
containing:
- ext. 9V psu
- RS232 cable RJ45-DB9, 2m
- T-BOX + cable to converter
- cable from T-box to converter,2m
Battery Charger BCHF/V 6172,30,030
- ext. 9V psu
Further needed:
item code adb code number
PC with two com ports PC1/V 6382,01,440
Windows NT WIN/NT 2820,00,200
Common Options
item code adb code number
Leather Holster LHHF/V 6382,01,470
Battery kit (4 p. rechargeable) BKHF/V 6172,30,020
Sysnet cable (per meter) CAHF/V 6104,01,010
Page 7
Rev. : 002
HF - VISION 10 & PHOENIX
Lighting Technologies
Sender HF communication Receiver VISION 10
50 - 80 m
RS232 data cable max. 20 m
Ext. Power Suppl
4.1.2. Installation with one HF Receiver
The point-to-point communication with one hand-held sender and one receiver is very
straight forward: just plug in the receiver’s RS232 data cable in VISION 10’s serial
communication port and connect the external power supply unit to the receiver’s
SUB-D connector. Power supply will be distributed over the cable from the serial line
connector to the HF receiver.
com port
4.1.3. Installation with more than one HF Receiver
This configuration permits to extend the operating range to more than 50-80 meters by
interconnectingupto4 HF receivers.Fortechnicalcommunication reasons, aseparate
standardPCwitha32bitWINDOWS„versionandaRS232/485protocolconverterhave
to be installed between the control desk and the HF receivers. The PC must have two
serialports andrunstheSatelliteControlCentersoftwareSCC.For adetailedoperation
manual for the software package refer to the special chapter “Satellite Control Center
software”.
Page 8
Rev. : 002
HF - VISION 10 & PHOENIX
Lighting Technologies
The different receivers are cabled via their T-connector boxes with a special SYSNET
cable.Noconnectorsareneeded asthecables directlyrunintotheT-boxes wherethey
can be screwed into terminal blocks.
ARS485/232converterallowsthereceiverstobeconnectedtoastandardserialRS232
communicationportofaPC.ThePCtakesoverallcommunicationbetweenthedifferent
devices, and sends the commands via an RS232 NULLMODEM cable to the lighting
desk.
Sender HF communication Receivers
(max. 4) Control desk
RS485 cable
RS485 cable
RS485 cable
RS485 cable
RS485 cable
(SYSNET)
T-box
w..psu
T-box
w..psu
T-box
w..psu
T-box
w..psu
RS485 cable
(SYSNET)
RS485 cable
(SYSNET)
RS485 cable
(SYSNET)
RS232/485
RS232 cable
max. 20m
RS232 cable
max. 20m
com port 1
Page 9
Rev. : 002
HF - VISION 10 & PHOENIX
Lighting Technologies
4.2. Software
The HF remote control system does not need a special and complicated configuration.
All you need to run the system on the control desk is
•adesk software version ≥2.62
•the remote control option (Infra Red) checked ( = ON) in the menu
CONFIGURATION, PERIPHERALS
Ifnothingelseis specified, yoursystemautomaticallyby the defaultfactorysettingsrunson
-RS232 serial communication port 1(normally located besides the floppy drive)
-Room ID 1 (see also: further explanations below)
-Product ID 1 (see also: further explanations below)
If these settings shall be changed on your control desk system, create a DOS file
hf.cfg in the path c:\vision10\
containing the following parameter settings:
Example: system connected to 2nd serial communication port, room number 2
and product identification number 1 (VISION 10)
ComPort= 2
RoomId = 2
ProductId= 2
The parameters
ComPort can contain the values 1 or 2
RoomId can contain 1 - 16
ProductId can contain 1 - 16
To obtain further information concerning the parameters ROOMID and PRODUCTID,
see in chapter MENU in the following.
Page 10
Rev. : 002
HF - VISION 10 & PHOENIX
Lighting Technologies
5. Quick Start
Power on: push MENU
The following desk functions are available:
No. Normal Display Normal Shift Display Shift
Key Function Abr. Functionality Function Abr. Functionality
1<- N.A. N.A. N.A. N.A. N.A.
2-> N.A. N.A. N.A. N.A. N.A.
3– UP increase value N.A. N.A. N.A.
4MENU N.A. activate menu N.A. N.A. N.A.
5¯ DN decrease value N.A. N.A. N.A.
6FFFFset ff intensity (100%) RET RET return to previous state
7DIM DIM operate dimmer LOAD LOAD load memory
8CLCLclear former operations N.A. N.A. N.A.
90000set 00 intensity (00%) GRP GRP select group of channels
10 <-> <-> through: select range of values MEM MEM select memory
11 SHIFT N.A. activate shift functions N.A. N.A. N.A.
12 7 7 value 7 M7 M7 call macro 7
13 8 8 value 8 M8 M8 call macro 8
14 9 9 value 9 M9 M9 call macro 9
15 4 4 value 4 GO GO1 start playback 1
16 5 5 value 5 BCK BCK1 go back in playback 1
17 6 6 value 6 CUT CUT1 cut transfer of playback 1
18 1 1 value 1 TST TST N.A.
19 2 2 value 2 SOL SOL N.A.
20 3 3 value 3 ALL ALL select all values
21 . . set decimal point ERA ERA erase parameter
22 0 0 value 0 COL COL select colour
23 AT% AT set percentage level B_O B_O activate/deactivate black-out
24 + + plus: add value or range - - minus: subtract value or range
25 SEND N.A. send key sequence to desk N.A. N.A. N.A.
Power off: push SHIFT and then LEFT-ARROW.
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Mando a distancia de ADB
