Adaptec 2410SA - Serial ATA RAID Controller Manual
ADAPTEC SERIAL ATA RAID 2410SA
ENCLOSURE
HARDWARE
INSTALLATION GUIDE
2410SA Enclosure Kit HIG.fm Page 0 Thursday, October 23, 2003 1:20 PM
1
In this Guide...
This Hardware Installation Guide explains how to set up the 4-bay
hot-swappable drive chassis included in the Adaptec®2410SA
Enclosure kit. It also describes how to install and hot-swap hard
disk drives.
Before You Begin
Ensure you have these items from the Adaptec 2410SA Enclosure
kit before beginning the installation:
■Adaptec 2410SA Enclosure drive chassis
■Four drive carriers
■Four SATA cables
■SATA LED cable
■Bag of screws and labels
You will also need a screwdriver during installation.
Before You Begin 1
Installing the Drive Carriers 2
Labelling the Drive Carriers 3
About the Drive LEDs 3
Installing the Drive Chassis 3
Hot-swapping Disk Drives 6
Technical Specifications 7
2410SA Enclosure Kit HIG.fm Page 1 Thursday, October 23, 2003 1:20 PM
2
Installing the Drive Carriers
To install a drive carrier:
1Mount a hard disk drive in a drive carrier and secure it with
screws, as shown.
2Insert the drive carrier into the drive slot and push firmly but
gently until you can press the carrier handle down and click the
release button into place.
3Repeat until all four drive carriers are installed.
Release button
2410SA Enclosure Kit HIG.fm Page 2 Thursday, October 23, 2003 1:20 PM
3
Labelling the Drive Carriers
The four drives are designated slightly differently by the Adaptec
2410SA controller, the drive chassis, and the Adaptec Storage
Manager software. This Table shows the different designations:
The Adaptec 2410SA Enclosure kit contains labels that you can use
to label the drive carriers as desired.
About the Drive LEDs
Each drive carrier has an Activity LED, which illuminates or
flashes to indicate status.
When the LED is illuminated, there is I/O activity on that disk drive.
When the LED is blinking, that disk drive has failed and should be
hot-swapped immediately. (The LED blinks at a steady rate when
the drive has failed—it illuminates for half a second, and then goes
off for half a second.)
When the LED is dark, there is no activity on that disk drive.
Installing the Drive Chassis
To install the drive chassis:
1Turn off your computer, disconnect the power cord, and ground
yourself by touching the computer chassis. Then remove the
computer cabinet, following the manufacturer’s instructions.
Drive Chassis 2410SA Controller Adaptec Storage Manager
Channel #1 J1/P0 P0 (Port 0)
Channel #2 J2/P1 P1
Channel #3 J3/P2 P2
Channel #4 J4/P3 P3
2410SA Enclosure Kit HIG.fm Page 3 Thursday, October 23, 2003 1:20 PM
4
2Turn the drive chassis so that you can access the connectors on
the rear panel.
3Using the Figure as a guideline, connect the cables. Use gentle
but firm pressure to fit the connectors together.
Caution: The connectors are keyed to fit together one way
only. Do not try to force a cable onto a connector. If the
cable does not slide on easily, try reversing it.
aConnect the LED cable to the LED connector, marked on the
backplane as JP26.
bConnect a SATA cable to channel connector #1, rotating the
end of the cable until it fits properly onto the connector. Both
ends of the SATA cable are identical, but are keyed to fit the
connectors one way only.
Continue by connecting SATA cables to channel connectors
#2 – #4.
c
Connect two power supply cables to power supply connectors.
The connectors are shown in
detail in the next Figure.
!
Channel Connectors #1 – #4
(see the Table on page 3)
Power
Connectors
LED Connector
2410SA Enclosure Kit HIG.fm Page 4 Thursday, October 23, 2003 1:20 PM
5
4Install the drive chassis into the computer cabinet, using the
screws provided in the Adaptec 2410SA Enclosure kit. (Your
computer cabinet may not look exactly the same as the one
shown in the example below.)
5Install the Adaptec Serial ATA RAID 2410SA controller, if you
haven’t already. Refer to the printed Adaptec Serial ATA RAID
2410SA Quick Installation Guide, included in the kit, for detailed
instructions.
6Connect the SATA cables to the controller, following the
instructions provided in the Adaptec Serial ATA RAID 2410SA
Quick Installation Guide.
7Connect the LED cable to the LED cable connector on the
controller. The connector and cable are keyed to fit together one
way only, as shown:
8Close the computer cabinet and reattach the power cord.
2410SA Enclosure Kit HIG.fm Page 5 Thursday, October 23, 2003 1:20 PM
6
9Power on your computer and install the device driver for the
Adaptec Serial ATA RAID 2410SA controller, if you haven’t
already. Refer to the Adaptec Serial ATA RAID 2410SA Quick
Installation Guide, included in the kit, for detailed instructions.
Refer to the Adaptec Serial ATA RAID 2410SA Installation and User’s
Guide for detailed information about using your Adaptec 2410SA
Enclosure Kit.
Hot-swapping Disk Drives
To hot-swap a disk drive:
1On the drive chassis, push the drive carrier’s release button and
pull the handle up to release the drive carrier, as shown.
2Pull out the drive carrier. You can remove multiple disk drives
at the same time, if required.
Release button
2410SA Enclosure Kit HIG.fm Page 6 Thursday, October 23, 2003 1:20 PM
7
3Mount a new drive in a drive carrier and secure it with screws,
as shown in Step 1 on page 2.
4Insert the drive carrier into the drive slot and push firmly but
gently until you can press the carrier handle down and click the
release button into place, as shown in Step 2 on page 2.
Technical Specifications
Occupancy Three 5.25" drive bays
Capacity Four (4) 1" Host Receptacle Connectors, SATA
hot-swap hard drives
Cooling
Subsystem
One 90 mm exhaust fan
System
Monitoring
■Fan Fail Detection LED and Alarm
■Overheat LED indication
Dimensions
(W x H x D)
147 mm x 129 mm x 230 mm
(5.8 in x 5.0 in x 9.1 in)
Weight Gross: 6.8 lb (3.4 kg)
2410SA Enclosure Kit HIG.fm Page 7 Thursday, October 23, 2003 1:20 PM
8
Copyright
©2003 Adaptec, Inc. All rights reserved. No part of this publication may be
reproduced, stored in a retrieval system, or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording or otherwise, without the
prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.
Trademarks
Adaptec and the Adaptec logo are trademarks of Adaptec, Inc., which may be
registered in some jurisdictions.
All other trademarks are the property of their respective owners.
Changes
The material in this document is for information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, Adaptec, Inc. assumes no liability resulting from
errors or omissions in this document, or from the use of the information contained
herein.
Adaptec reserves the right to make changes in the product design without
reservation and without notification to its users.
Disclaimer
IF THIS PRODUCT DIRECTS YOU TO COPY MATERIALS, YOU MUST HAVE
PERMISSION FROM THE COPYRIGHT OWNER OF THE MATERIALS TO AVOID
VIOLATING THE LAW WHICH COULD RESULT IN DAMAGES OR OTHER
REMEDIES.
2410SA Enclosure Kit HIG.fm Page 8 Thursday, October 23, 2003 1:20 PM
9
Adaptec Customer Support
If you have questions about installing or using your Adaptec product, check this
document first—you will find answers to most of your questions here. If you need
further assistance, use the support options listed below.
Technical Support Identification (TSID) Number
■Before contacting Technical Support, you need your unique 12-digit TSID
number. The TSID number identifies your product and support status.
■The TSID number is included on two white, bar-coded labels, like the example
below.
■If you register by mail, affix one copy of the TSID label to the registration card,
which may be contained on the CD. Also affix a copy of the TSID label to the CD
jacket so that you don’t lose it.
Support Options
■Search the Adaptec Support Knowledgebase (ASK) at ask.adaptec.com for
articles, troubleshooting tips, and frequently asked questions for your product.
■For support via e-mail, submit your question to Adaptec’s Technical Support
Specialists at ask.adaptec.com.
North America
■Visit our Web site at www.adaptec.com.
■For information about Adaptec’s support options, call +1 408-957-2550,
24 hours per day, 7 days per week. To speak with a Technical Support Specialist,
■For Hardware products call +1 408-934-7274,
Monday to Friday, 3:00 A.M. to 5:00 P.M., Pacific Time.
■For RAID and Fibre Channel products call +1 321-207-2000,
Monday to Friday, 3:00 A.M. to 5:00 P.M., Pacific Time.
To expedite your service, have your computer in front of you.
■
To order Adaptec products, including accessories and cables, call +1 408-957-7274.
Or, you can order cables online at www.adaptec.com/buy-cables.
2410SA Enclosure Kit HIG.fm Page 9 Thursday, October 23, 2003 1:20 PM
