Acute TravelScope Series Manual de usuario

Acute Technology Inc.

TravelScope DSO Manual

Publish:2018/08

Acute Technology Inc.

Installation Procedures ----------------------------------------------------------------------------------- 4

Probe calibration------------------------------------------------------------------------------------------- 9

DS-1000 series Calibration----------------------------------------------------------------------------- 11

Window----------------------------------------------------------------------------------------------------- 13

Operation--------------------------------------------------------------------------------------------------- 14

Channel Switch Button ----------------------------------------------------------------------------------------------14

VOLTS/DIV Knob ---------------------------------------------------------------------------------------------------14

TIME/DIV Knob------------------------------------------------------------------------------------------------------14

Threshold --------------------------------------------------------------------------------------------------------------15

Channel-----------------------------------------------------------------------------------------------------------------15

Trigger Position-------------------------------------------------------------------------------------------------------15

Scroll Bar --------------------------------------------------------------------------------------------------------------16

Panel Sizing Knob----------------------------------------------------------------------------------------------------16

Zoom(TravelScope only)--------------------------------------------------------------------------------------------16

Waveform operation--------------------------------------------------------------------------------------------------17

Run/Stop ---------------------------------------------------------------------------------------------------------------18

FORCE TRIGGER---------------------------------------------------------------------------------------------------18

SET LEVEL TO 50%------------------------------------------------------------------------------------------------18

HARDCOPY----------------------------------------------------------------------------------------------------------18

TRIGGER--------------------------------------------------------------------------------------------------------------19

Acute Technology Inc.

DISPLAY --------------------------------------------------------------------------------------------------------------30

CURSOR---------------------------------------------------------------------------------------------------------------38

MEASURE ------------------------------------------------------------------------------------------------------------39

UTILITY---------------------------------------------------------------------------------------------------------------41

SAVE/RECALL ------------------------------------------------------------------------------------------------------47

ACQUIRE -------------------------------------------------------------------------------------------------------------49

AUTOSET-------------------------------------------------------------------------------------------------------------52

How to stack multiple DSOs--------------------------------------------------------------------------- 54

APPENDIX------------------------------------------------------------------------------------------------ 57

Probe Specification---------------------------------------------------------------------------------------------------57

Acute Technology Inc.

Safety Information

Please review the following safety information to avoid injury and prevent damage to the

DSO or any products connected to it.

Symbol definitions:

This symbol indicates that the manual should be referred to.

WARNING

“WARNING” denotes that, if not correctly performed or adhered to,

could result in injury or loss of life. Do not proceed beyond a warning

until the indicated conditions are fully understood and met.

CAUTION

“CAUTION” denotes that, if not correctly performed or adhered to,

could result in damage to or destruction of DSO. Do not proceed

beyond a caution sign until the indicated conditions are fully

understood and met.

NOTE

“NOTE” denotes that refer to the manual, which provides operational

information of which the user should be aware.

WARNING

Do not operate without cover(s).

Do not operate the DSO with any cover(s) removed. This may result in electric shock or

fire hazard if any part(s) inside is touched.

Use USB2.0 power only

The DSO should be powered by the PC’s USB2.0 port. Use only the DSO USB cable to

connect to the PC’s USB2.0 port.

Do not operate in wet or damp conditions.

Do not modify or operate the DSO if there was any suspected damage, have it

Acute Technology Inc.

inspected by qualified service personnel.

Connect the Probe Properly

Connect the ground lead of the probe to earth ground only. Do not connect the ground

lead to an elevated voltage.

Do not connect or disconnect probes or test leads while they are probed to a voltage

source.

CAUTION

ObserveALLTerminal Ratings.

To avoid fire or shock hazard, observe all ratings and markings on the product. Consult

the product manual for further ratings information before making connections to the

product.

Do not operate in the following installation location

In direct sunlight.

In extremely hot and/or humidity areas.

With always mechanical vibrations.

Around areas with strong lines of magnetic forces or impulse voltage.

Remove the USB cable from the DSO if it is not being used.

The temperature of the DSO increases after being used for a while.

Use original USB cable.

Acute Technology Inc.

Installation

Acute Technology Inc.

Installation Procedures

Driver Installation for Windows XP

Insert the installation CD and connect the DSO with your PC.

Enter the hardware wizard when the Windows OS find an USB device (Figure 1) and check

“yes. This time only”.

Figure 1 Figure 2

Choose “Install the software automatically” (Recommended) to find the proper driver

automatically (Figure 2). Click “Next”.

Click “Next” when a driver is found.

Figure 3 Figure 4

You will see the “Acute USB 2.0 Interface” in the Device Manager (Figure 6). Please check

our FAQ at www.acute.com.tw or e-mail us at [email protected] if there is any

installation problem.

Acute Technology Inc.

Figure 5 Figure 6

Acute Technology Inc.

Install the driver manually

Insert the installation CD and connect the DSO with your PC. Choose “Add Device” in the

Control panel (Figure 1).

Figure 1 Figure 2

Choose “Install from a list or specific location (Advanced)” (Figure 2) and click “Next”.

Choose “Search for the best driver in these locations”(Figure 3); select the DSO directory

and click “Next”.

Figure 3 Figure 4

Click “Continue Anyway” (Figure 4) to continue the installation procedure.

Click “Finish” (Figure 5) after the DSO driver is installed. You may see the “Acute USB 2.0

Interface” in Device Manager (Figure 6).

Acute Technology Inc.

Figure 5 Figure 6

You will see the “Acute USB 2.0 Interface” in the Device Manager (Figure 6). Please check

our FAQ at www.acute.com.tw or e-mail us at [email protected] if there is any

installation problem.
