9CH H.264 MOBILE SVR
INSTRUCTION MANUAL
9CH Mobile SVR Manual
1
Introduction
The 9-channel mobile Network Video Recorder offers a standalone solution for managing IP
cameras and systems. It uses high quality H.264 decoders to deliver 1080P/720P/D1/VGA/CIF IP
camera streams. Each channel can be individually configured to SD and/or HD resolution to
optimize storage space.
Embedded HDMI(VGA) engines offer 3D intellectual motion adoptive refinement, providing a
maximum resolution of 1080P. The TV wall design allows the SVR to be cascaded via TCP/IP
network for easy cabling. The SVR has an IP scan facility, (WS Discovery) which locates all the
cameras on the network and imports a preview thumbnail of each channel. This is an
automated installation wizard that speeds up commissioning. The self-diagnostic feature
monitors the internal temperature, cooling fan, HDD I/O speed, network status and information
can be accessed via the health check report.
The SVR can be controlled via multiple input methods; remote control, touch screen monitor,
or USB mouse. When connected to a touch screen monitor, Smartphone style features like
‘pinch and zoom’ can be used to navigate the system.
The SVR provides various export methods including USB DVD/RW, USB flash disk, and HTTP
download playable via Backup Manager. Extensive support for iPhone, iPad, BlackBerry and
Android allows for remote viewing of the connected cameras at high frame rates. Browser
based remote live monitoring and video playback features are also supported.
Then SVR is designed to deal with the harsh vibration and shock of mobile environments.
Features
•
Standalone mobile SVR.
• Touch screen interface.
• 1080P at 25FPS with up to 45Mbps network throughput.
• Full HD 1920*1080P HDMI and VGA output.
• One removeable SATA 2.5-inch HDD tray with HDD or SSD.
• Can support USB GPS receiver, record GPS information.
• IP scan utility.
• Wide range of working temperature.
• Designed to withstand the vibration and shock of mobile environments.
•
AiM 3.0 software supported.
9CH Mobile SVR Manual
2
Trademarks and registered trademarks
• Microsoft, Windows 2000, Windows XP, Internet Explorer are registered trademarks of
Microsoft Corporation in the U.S and/or other countries.
• Adobe and Adobe PDF are registered trademarks of Adobe Systems Incorporated in
the U.S and/or other countries.
• JavaScript and all Java-based trademarks and logos are trademarks or registered
trademarks of Sun Microsystems, Inc. in the U.S and/or other countries.
• Linux, Macintosh, Mozilla, and Netscape Navigator are registered trademarks of the
respective holders.
• Other names of companies and their products mentioned in this manual may be
trademarks or registered trademarks of their respective owners.
Caution
• Do not drop or strike the equipment
• Do not install the equipment near naked flames or heat sources
• Do not expose this unit to rain, moisture, smoke or dusty environments
• Do not cover the opening of the cabinet with cloth or plastic or install this unit in a
ventilated place. Allow 10cm between this unit and its surroundings
• Do not continue to operate the unit under abnormal conditions such as detection of
smoke, strange smell or no display on screen whilst power is turned on
• Do not touch the power connection with wet hands
• Do not damage the power cord or leave it under pressure
• To avoid unnecessary magnetic interference, do not operate this unit near magnets,
speaker system, etc.
• All connection cables must be grounded properly
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
9CH Mobile SVR Manual
3
Contents page
User Guide.................................................................................................................................... 5
Chapter 1: Basic Operation............................................................................................................ 5
1.1 9CH-Mobile Front Panel................................................................................................. 5
1.2 Remote control .............................................................................................................. 5
1.3 Touch screen................................................................................................................. 7
1.4 Mouse operations.......................................................................................................... 7
1.5 Menu symbols................................................................................................................ 8
Chapter 2: Camera selection.......................................................................................................... 9
Chapter 3: Digital zoom.................................................................................................................. 9
Chapter 4: Freeze ........................................................................................................................ 10
Chapter 5: PTZ............................................................................................................................. 10
Chapter 6: Audio.......................................................................................................................... 11
Chapter 7: Playback..................................................................................................................... 11
7.1 Accessing playback ..................................................................................................... 11
7.2 Select time and date for playback................................................................................ 11
7.3 Playback controls......................................................................................................... 12
Chapter 8: Alarm Management..................................................................................................... 14
Chapter 9: Backup / Export........................................................................................................... 15
Chapter 10: Event ........................................................................................................................ 17
Chapter 11: Basic web-based browser viewing ............................................................................ 18
11.1 Web-based browser playback.................................................................................... 18
11.2 Web-based browser backup....................................................................................... 19
11.3 Web-based browser export (backup file download).................................................... 19
Chapter 12: Backup Manager....................................................................................................... 20
12.1 Playback exported files.............................................................................................. 20
12.2 FTP Download........................................................................................................... 20
12.3 Convert already downloaded files............................................................................... 22
Quick Installation Guide ............................................................................................................ 23
Chapter 1: Rear Panel.................................................................................................................. 23
Chapter 2: Hard Drive(s) .............................................................................................................. 23
2.1 Adding hard drive(s)..................................................................................................... 23
2.2 Formatting Hard Drive(s).............................................................................................. 24
Chapter 3: Time and Date Settings............................................................................................... 24
Chapter 4: Network Settings......................................................................................................... 25
Chapter 5: Adding Cameras......................................................................................................... 26
9CH Mobile SVR Manual 4
Menu configuration.................................................................................................................... 27
Chapter 1: Setup Menu................................................................................................................ 27
1.1 Camera setup.............................................................................................................. 27
1.2 Monitor Setup.............................................................................................................. 31
1.3 Record setup............................................................................................................... 32
1.4 Alarm setup ................................................................................................................. 35
1.5 Network setup.............................................................................................................. 37
1.6 System setup............................................................................................................... 39
1.7 PTZ setup.................................................................................................................... 43
Chapter 2: Web-based Viewing/Setup.......................................................................................... 45
2.1 Before using Internet browser...................................................................................... 45
2.2 Logon .......................................................................................................................... 45
2.3 Configuring the SVR via web page .............................................................................. 46
Appendix A Alarm I/Os、Audio and RS-232 Connector............................................................... 52
Appendix B Power Connector ..................................................................................................... 53
Appendix C M12 Network Connector .......................................................................................... 53
Appendix D Hard Drive Support List ........................................................................................... 53
Appendix E Support USB-DVD/RW and DVD Disk ..................................................................... 53
Appendix F Supported USB Flash Disk ...................................................................................... 54
Appendix G Supported USB GPS Receiver ................................................................................ 54
Appendix H Touch Screen Monitor Support List ......................................................................... 54
Appendix I Hard Disk Recording Table ....................................................................................... 55
Appendix J Troubleshooting & FAQ ............................................................................................ 55
Specification sheet......................................................................................................................57
9CH Mobile SVR Manual
5
User Guide
Chapter 1: Basic Operation
1.1 9CH-Mobile Front Panel
1. POWER LED (Yellow)
SVR power on/off indicator
4. Alarm LED (Red blinking)
Indicates motion or alarm triggers
2. LAN LED (Green)
LAN link light
5. Extra IR receiver
Ensure turn off the power before install
3. HDD LED (Green blinking)
HDD recording indicator
6. IR receiver
1.2 Remote control
The remote control is a small wireless handheld device with an array of buttons for
adjusting settings. The buttons are separated in regions based on their features including
SVR operational keys, Pan, Tilt, and Zoom (PTZ) and numerical keys.
9CH Mobile SVR Manual
6
SVR remote control operational keys
MENU Setup menu
ESC Escape/exit/stop
SHIFT Split and full screen switch
ZOOM Digital video zooming
REC Record/stop recording
FREEZE Live video freeze
Pause
Playback
Stop
Fast forward
Fast rewind
Next single channel
Previous single channel
4 split display
8 split display
9 split display
AUDIO Audio/mute
BACKUP Video backup
DVR/SVR Addressable SVR control
LANGUAGE Language selection
BACKSPACE Delete character
Auto Pan Perform auto pan feature Move up/tilt up
Zoom in Zoom in Move down/tilt down
Zoom out Zoom out Move left/pan left
Preset Call preset Move right/pan right
0 to 9 Numerical keys Enter/set
9CH Mobile SVR Manual
7
1.3 Touch screen
Pinch and zoom:
Pinch the area on the touch screen where you want to zoom. To zoom in move your fingers
outwards, and to zoom out move your fingers inwards
Scroll screen: Swipe the screen left and right to navigate through the menus
Single tap: Tap icons to select
Double tap: Double tap in camera view to return to previous menu
1.4 Mouse operations
The SVR has a USB mouse interface
General mouse operations can be used to navigate the device
Pinch Zoom Out Swipe
Right mouse click
Mouse scroll
Left mouse click
Note: The SVR Touch can be controlled via multiple methods; a) IR remote control, b) touch screen
monitor or c) USB mouse. For the purpose of this manual, USB mouse and touch screen will be referred
to as one operation where applicable, “Touch screen monitor/mouse” hereinafter. For specific
operations, “Touch screen” or “Mouse” will be referred to separately.
9CH Mobile SVR Manual
8
1.5 Menu symbols
Home short cut keys:
Menu
Pause
Alarm
Playback/Backup
Main menu keys:
PTZ
Screen view
Shut down
Alarm manager
Live display
Configuration menu
Playback/Backup
Event
Additional menu keys:
– Return to previous screen – Return to live mode
9CH Mobile SVR Manual
9
Chapter 2: Camera selection
a. Via remote control
To select multiple screen views press
To select a single full screen view, enter the numerical value of the camera, e.g. for camera 3,
press ‘03’.
b. Via touch screen monitor / mouse
To select multiple screen views, press
Chose your required view by selecting or or and
Select
To revert back to multi screen view, click anywhere on the image screen
Chapter 3: Digital zoom
The SVR provides 64x digital zoom capability for live monitoring and video playback modes.
To digitally zoom, follow the steps below:
a. Via remote control
Select desired channel
To zoom in and out, press ‘zoom’ button to activate
Use directional keys to move around the screen
To return to live view, press depending on required view
b. Via touch screen monitor
Select desired channel
To zoom in and out, use pinch and zoom technique
Swipe touch screen monitor to move around the screen
To return to live view, tap once anywhere on the image
c. Via mouse
Select desired channel
To zoom in and out use mouse wheel
To move around the screen press right or left mouse button, drag and release
To return to live view click once anywhere on the image
Note: When the camera title is yellow, you have control over that camera.
Tabla de contenidos
Otros manuales de DVR de Acumen
