ACU-RITE 6027 Manual de usuario

Instruction Manual

CONTENTS

Unpacking Instructions ........... 2

Package Contents .................. 2

Product Registration ............... 2

Features & Benets................. 3

Display Setup ........................ 7

Placement Guidelines ............. 8

Expand the System................. 9

Using the Weather Station.....10

Troubleshooting ....................15

Care & Maintenance.............16

Specications........................17

FCC Information ...................17

Customer Support .................18

Warranty..............................18

High Resolution

Weather Station Display

model 06027

SAVE THIS MANUAL FOR FUTURE REFERENCE.

Questions? Contact Customer Support at

(877) 221-1252 or visit www.AcuRite.com.

This product requires at least one AcuRite Monitor or Sensor

(sold separately) to be operational.

Congratulations on your new AcuRite product. To ensure the best

possible product performance, please read this manual in its entirety

and retain it for future reference.

Unpacking Instructions

Remove the protective lm that is applied to the LED screen prior to using this

product. Locate the tab and peel off to remove.

Package Contents

1. Weather Station Display

2. Power Adapter

3. Mounting Bracket

4. Tabletop Display Stand

5. Instruction Manual

PRODUCT REGISTRATION

to receive 1 year

warranty protection

www.AcuRite.com

IMPORTANT PRODUCT MUST BE REGISTERED

TO RECEIVE WARRANTY SERVICE

►

Features & Benets

Weather Overview Dashboard

1. Alarm ON Indicator

Indicates alarm is activated to emit an

audible alert when conditions exceed

your presets (see page 10).

2. Indoor Conditions or

How-to-Dress Character

Select viewing preference during setup

(see page 12).

3. Clock

4. Current Outdoor Humidity

Arrow icon indicates direction

humidity is trending.

5. Weather Forecast and Indoor

Humidity Messages

Text readout of weather forecast.

Displays humidity alerts when indoor

conditions are too high or low

(see page 13).

6. Day Of The Week

7. Date

8. Weather Forecast and

Current Conditions

Self-Calibrating Forecasting pulls data

from your sensor to generate your

personal forecast. Illustrates

current conditions and automatically

adjusts based on time of day and

season.

9. Current Indoor Temperature

Arrow indicates direction

temperature is trending.

10. Messages

Weather information and alert

messages (See page 13).

11. Outdoor Sensor Signal Strength

65 74

1. Humidity Level Indicator

Indicates a high, low or ideal

humidity comfort level (see page 14).

2. Daily High & Low

Temperature Records

Lowest and highest temperature

recorded since midnight.

3. Current Indoor Humidity

Arrow indicates direction humidity

is trending.

4. Daily High & Low

Humidity Records

Lowest and highest humidity recorded

since midnight.

5. Recommendations

Indoor comfort recommendations

based on outdoor conditions

(see page 14).

6. Current Indoor Temperature

Arrow indicates direction temperature

is trending.

Features & Benets

Indoor Overview Dashboard

weather overview

12:35 pm TUE 10/25

indoor

indoor comfort:

high humidity!

open windows

it’s mild outside

7368

ºF

indoor overview

Features & Benets

All Locations Dashboard

1. Wireless Signal Strength

Signal strength detected for the

external Monitor or Sensor (sold

separately) that is reporting data for

the location.

2. Low Battery Indicator

For the product that is reporting data

for the corresponding location.

3. Alarm ON Indicator

Indicates alarm is activated to emit an

audible alert when conditions exceed

your presets (see page 10).

4. Water Detector Reading

Indicates Water Detector (sold

separately) data.

5. Wired Sensor Indicator

Indicates a Wired Sensor (sold

separately) is reporting data to the

display.

6. Humidity Reading

Humidity reading reported by the

product that is installed in the location

indicated.

7. Temperature Reading

Temperature reading reported by

the product that is installed in the

location indicated.

8. Location Name

Label your data readings by location

name (see page 11).

12:35 pm TUE 10/25

All Locations

press for multi-sensor setup

46ºF

Outdoor

72ºF

Display

sensor:

68ºF

Baby’s Room

sensor: No Water Detected

58ºF

Basement

87º 23%

DISPLAY BACK

1. Plug-in for Power Adapter

2. Display Stand

Snaps in for tabletop use.

3. Mounting Bracket

For easy wall mounting.

DISPLAY FRONT

4. Button

For menu access and setup

preferences.

Button

For setup preferences and cycling

through messages on the Weather

Overview dashboard.

Button

Press to view a different dashboard.

Button

For setup preferences and cycling

through messages on the Weather

Overview dashboard.

8. ü Button

For setup preferences.

45 6 7 8

Features & Benets

Display

Display Setup

SETUP

1Install External Monitor or

Sensor Batteries

BEFORE powering on the display,

install batteries for all external

Monitors and/or Sensors (sold

separately) that you would like to

synchronize with the display.

Note: If pairing more than

one Temperature & Humidity

Sensor (model 06002RM) with

the display, the A-B-C switch

positions must differ between

each sensor. Verify that each

sensor has a different channel

selected by checking the switch

position, located in the battery

compartment.

Plug Power Adapter into

Electrical Outlet

Install Batteries

2 AA Batteries

2Plug in

Power Adapter

Settings

After powering on for the rst time, the display will automatically enter setup

mode. Follow the on-screen instructions to set up the display.

To adjust the currently selected item, press and release the “T” or “

“

buttons (press and HOLD to fast adjust).

To save your adjustments, press and release the “ü” button again to adjust the

next preference. The preference set order is as follows:

TIME ZONE (PST, MST, CST, EST, AST, HAST, AKST)

AUTO DST (Daylight Saving Time YES or NO)*

CLOCK HOUR

CLOCK MINUTE

MONTH

DATE

YEAR

PRESSURE UNITS (inHg or hPa)

TEMPERATURE UNITS (ºF or ºC)

AUTO DIM (YES or NO)**

AUTO CYCLE (OFF, 10 sec., 30 sec., 60 sec., 2 min.)

INDOOR READINGS or HOW-TO-DRESS CHARACTER***

ALERT VOLUME

*If you live in an area that observes daylight saving time, DST should be set to YES,

even if it is not currently Daylight Saving Time.

**For more information see page 11, under “Display”.

***For more information see page 12, under “How-to-Dress Character”.

Enter setup mode at any time by pressing the “ ” button to access the menu,

then navigate to “Setup” and press and release the “ü” button.

Placement for Maximum Accuracy

AcuRite products are sensitive to surrounding environmental conditions. Proper

placement is critical for accuracy and performance.

Display Placement

Place the display in a dry area free of dirt and dust. Display stands

upright for tabletop use and is wall-mountable.

Important Placement Guidelines

• To ensure accurate temperature measurement, place product out of direct

sunlight and away from any heat sources or vents.

• Display and add-on Monitors/Sensors must be within 330 feet (100 m) of

each other.

• To maximize wireless range, place product away from large metallic items, thick

walls, metal surfaces, or other objects that may limit wireless communication.

• To prevent wireless interference, place product at least 3 feet (.9 m) away from

electronic devices (TV, computer, microwave, radio, etc.).

Expand the System

The display features built-in sensors for measuring temperature and humidity

at its location. The display can be expanded to track additional conditions by

using compatible Monitors and Sensors (optional; sold separately). Add up

to 3 Monitors and Sensors to observe conditions in additional locations within

330 ft (100 m).

Compatible Monitors and Sensors are available at: www.AcuRite.com

Compatible Monitors Perfect for:

• Outdoor applications

• Indoor applications

• Indoor and outdoor applications

Temperature &

Humidity Sensor

Model 06002RM

Temperature &

Humidity Monitor

Model 00275RM

Room Monitor

Model 00276RM

Monitor + Wired Sensor Perfect for:

• Basement ooding

• Roof leaks

• Leaky appliances

• Sump pump failure

• Track high or low water level

• Indoor pool, spa, pond or fountain

temperature

• Prevent frozen pipes

• Seeding, potting and gardening

• Monitor conditions in hard to reach places

(attic, basement, etc.)

• Pet areas

• Evaluate heating and cooling efciency and

coverage in your home

• Monitor conditions in nursery or child’s room

Water Detector

Model 06010RM

Liquid & Soil

Temperature

Sensor

Model 06011RM

Spot Check

Temperature &

Humidity Sensor

Model 06012RM

Using the Weather Station

OPERATION

Records

Display

Monitors

Setup

Factory Reset

Units

Alarms

Calibrate

press to exit menu

4 8

Navigate to the main menu at any time by pressing the “ ” button. From the

main menu, you can view records, set alarms, setup additional monitors and more.

1. Records

Access the “Records” sub-menu to view high and low values recorded for

each location by date and view trends for each of the monitor’s readings on

a graphic chart.

2. Alarms

Access the “Alarms” sub-menu to set and edit alarm values.

3. Setup

Access the “Setup” sub-menu to enter the initial setup process.

Tabla de contenidos

Otros manuales de Estación meteorológica de ACU-RITE

ACU-RITE

ACU-RITE 02001 Manual de usuario

ACU-RITE

ACU-RITE 06005RM Manual de usuario

ACU-RITE

ACU-RITE 01602BPDIA2 Manual de usuario

ACU-RITE

ACU-RITE 02001 Manual de usuario

ACU-RITE

ACU-RITE 01120M Manual de usuario

ACU-RITE

ACU-RITE 13230 Manual de instrucciones

ACU-RITE

ACU-RITE 02007/06035RM Manual de usuario

ACU-RITE

ACU-RITE 1605 Manual de usuario

ACU-RITE

ACU-RITE 838 Manual de usuario

ACU-RITE

ACU-RITE 01201 Manual de usuario

ACU-RITE

ACU-RITE 436 Manual de usuario

ACU-RITE

ACU-RITE 1528 Manual de usuario

ACU-RITE

ACU-RITE 992 Manual de usuario

ACU-RITE

ACU-RITE 02045W Manual de usuario

ACU-RITE

ACU-RITE 972 Manual de usuario

ACU-RITE

ACU-RITE 2030 Manual de usuario

ACU-RITE

ACU-RITE 06035RM Manual de usuario

ACU-RITE

ACU-RITE 01129 Manual de usuario

ACU-RITE

ACU-RITE 309 Manual de usuario

ACU-RITE

ACU-RITE 02036WB Manual de usuario

ACU-RITE

ACU-RITE 01010 Manual de usuario

ACU-RITE

ACU-RITE 00613 Manual de usuario

ACU-RITE

ACU-RITE Weather Forecaster 00821 Manual de usuario

ACU-RITE

ACU-RITE 06034RM Manual de usuario

Manuales populares de Estación meteorológica de otras marcas

Auriol

Auriol AHFL 433 A1 Manual de usuario

NexSens

NexSens G2-HYDROMET Manual de usuario

Hyundai

Hyundai WS 2202 Manual de usuario

IROX

IROX HBVR761 UV-X Manual de usuario

La Crosse Technology

La Crosse Technology C86371 Manual de usuario

ADE

ADE WS 1711 Manual de usuario

Auriol

Auriol z29592 Manual de usuario

Auriol

Auriol 296289 Manual de usuario

Hyundai

Hyundai WS 2266 Manual de usuario

La Crosse Technology

La Crosse Technology WS-2210 Manual de usuario

La Crosse Technology

La Crosse Technology WS-811561 Manual de usuario

Ventus

Ventus W177 Manual de usuario

National Geographic

National Geographic VA Colour RC Manual de usuario

Renkforce

Renkforce 1208067 Manual de usuario

Levenhuk

Levenhuk Discovery Report WA40 Manual de usuario

Instant Transmission

Instant Transmission MA 10410 Manual de usuario

Lutron Electronics

Lutron Electronics PHB-318 Manual de usuario

WAREMA

WAREMA EWFS Weather station eco Manual de usuario
