Active AC 642 Guía

Safety and operation instruction

AC 842

AC 642

- 2 -

- 3 -

1. USE OF THE MANUAL...................................................................... page 4

2. NOTICE ON THE MACHINE...............................................................page 5

3. TECHNICAL DATA............................................................................page 8

4. LIFTING AND TRANSPORTATION.....................................................page 9

5. MAIN PARTS OF THE MACHINE........................................................page 10

6. CONTROLS AND ADJUSTMENTS.....................................................page 12

7. ASSEMBLY INSTRUCTIONS FOR THE HANDLEBARS AND

FRONT SUPPORT WITH WHEELS....................................................page 14

8. SAFETY INFORMATION

A) GENERAL INSTRUCITONS...........................................................page 15

B) TRAINING.....................................................................................page 15

C) PREPARATION..............................................................................page 15

D) WORKING USE.............................................................................page 16

E) AFTER WORK.............................................................................. page 17

9. TRANSPORTATION OF THE MACHINE..............................................page 18

10. SAFETY SYSTEMS AND GUARDS.....................................................page 19

11. OPERATIONS TO BE CARRIED OUT BEFORE SWITCHING ON....... page 19

12. STARTING AND DRIVING THE FLAIL MOWER................................. page 20

13. CUTTING TIPS...................................................................................page 22

14. CHECKS

A) TYRE PRESSURE.........................................................................page 22

B) CABLE CONTROL ADJUSTMENT................................................page 23

C) BRAKES ADJUSTMENT.................................................................page 25

D) BELT REPLACEMENT AND ADJUSTMENT...................................page 26

E) CHECKING AND REPLACING THE FLAILS..................................page 29

F) SHARPENING THE FLAILS...........................................................page 30

G) CHECKING AND REPLACING THE TRANSMISSION OIL.................. page 31

15. MAINTENANCE AND STORAGE.........................................................page 32

16. CLEANING THE MACHINE.................................................................page 33

17. SEASONAL LONG-TERM STORAGE PERIODS................................. page 33

18. DECOMMISSIONING AND SCRAPPING.............................................page 34

19. TECHNICAL ASSISTANCE................................................................page 34

20. WARRANTY......................................................................................page 34

21. CE MARKING....................................................................................page 35

22. TROUBLESHOOTING.........................................................................page 36

Enclosure 1. NOTES

Enclosure 2. Declaration of Conformity

- FLAIL MOWER MANUAL -

CONTENTS

FLAIL MOWER MOD. AC 642 - AC 842

- 5 -

2. NOTICE ON THE MACHINE

The symbols affixed to the machine serving to warn of danger during its use and

maintenance are as follows:

THE USER MUST READ THE INSTRUCTION MANUAL PROVIDED

DANGER OF FOREIGN OBJECTS BEING THROWN

OUTWARDS. KEEP A SAFE DISTANCE

ALWAYS DISCONNECT THE CABLE FROM THE ENGINE SPARK PLUG.

DANGER OF HAND INJURY. SWITCH OFF THE ENGINE

- 6 -

DANGER OF CRUSHING. KEEP A SAFE DISTANCE

DANGER OF INJURY TO BOTH UPPER AND LOWER LIMBS.

DO NOT PUT HANDS OR FEET INSIDE THE CUTTING

ELEMENT WHILE IN MOTION

DANGER OF GETTING CAUGHT UP IN ROTATING PARTS.

DO NOT PUT HANDS IN THE ROTATING PARTS

DANGER OF FOREIGN OBJECTS BEING THROWN OUTWARDS.

SAFETY GOGGLES MUST BE WORN

- 7 -

EAR MUFFS MUST BE WORN.

DO NOT ALLOW CHILDREN NEAR THE MACHINE

WHEN IN OPERATION.

CAUTION: HOT PARTS. DANGER OF BURNS. FIRE HAZARD

The symbols affixed to the machine serve to warn of danger during its use and maintenance.

It is vitally important to understand the meaning of the danger notices and all messages

should be kept in legible condition. In the instance of wear these no-tices should be

replaced and use of the machine suspended while without such notices.

The operator is advised to observe the warnings given on the affixed notices.

173

168

- 9 -

ALTITUDE

The altitude of the place in which the machine is to be used must not exceed 1500 m

above sea level.

TEMPERATURE

Minimum ambient temperature: -5°C

Maximum ambient temperature: +50°C

ATMOSPHERIC CONDITIONS

The electrical equipment will function correctly in atmospheric conditions with a relative

humidity up to 50% at a temperature of 40°C and at 90% with a temperature up to 20°C

(without condensate).

ATMOSPHERE WITH RISK OF EXPLOSION AND/OR FIRE

The standard machine herein described is not designed to work in explosive atmospheres

or in those with risk of fire.

4. LIFTING AND TRANSPORTATION

All material is carefully checked by the manufacturer before shipping. The flail mower is

delivered in a wooden crate or cardboard box with the handlebars and front support with

wheels disassembled.

Upon receipt of the machine make sure that it has not been damaged during transit and

that the packaging has not been tampered or any parts removed. Report any damage or

missing parts immediately to the driver and the manufacturer with photographic

documentation.

After assembling the handlebars, the front support with wheels and the safety bar as per

the instructions given in paragraph 7 of this manual, the machine may be moved on its

own wheels.

The manufacturer is not liable for any damage caused by transportation of the machine

after its delivery.

WARNING

Extreme care must be taken during handling to prevent overturning. Avoid steep gradi-

ents to prevent loss of control. Make sure that there are no persons present within the

danger area.

- 10 -

5. MAIN PARTS OF THE MACHINE

The machine consists of the following main parts:

A - FORWARD CLUTCH CONTROL LEVER

B - ACCELERATOR CONTROL LEVER

C - PINS TO BLOCK/RELEASE THE FRONT WHEELS

D - FLAIL ROTOR CLUTCH CONTROL LEVER

E - RIGHT WHEEL RELEASE LEVER

E1 - LEFT WHEEL RELEASE LEVER

F - ENGINE

G - FRONT WHEELS

H - FRONT GUARD

I - CUTTING HEIGHT ADJUSTMENT LEVER

M - ON/OFF SWITCH (1/0)

N - GEAR SELECTOR LEVER
