Active Vision SX-5100 Manual de usuario

DVR User Manual

For H.264 8/16-channel digital video recorder

DVR User Manual

CAUTION

Please read this user manual carefully to ensure that you can use the device correctly and safely.

We do not warrant all the content is correct. The contents of this manual are subject to change without notice.

This device should be operated only from the type of power source indicated on the marking label. The voltage of the power must be

verified before using the same. Kindly remove the cables from the power source if the device is not to be used for a long period of time.

Do not install this device near any heat sources such as radiators, heat registers, stoves or other devices that produce heat.

Do not install this device near water. Clean only with a dry cloth.

Do not block any ventilation openings and ensure proper ventilation around the machine.

Do not power off the DVR when the device is functioning. The correct operation to shut down the DVR is to stop recording first, use

“shut-down” button from the menu, and switch off the main power.

This machine is for indoor use only. Do not expose the machine in rain or moist environment. In case any solid or liquid get inside the

machine‟s case, please turn off the device immediately and get it checked by a qualified technician.

Do not try to repair the device by yourself without technical aid or approval.

When this product is in use, the relevant contents of Microsoft, Apple and Google will be involved in. The pictures and screenshots in

this manual are only used to explain the usage of our product. The ownerships of trademarks, logos and other intellectual properties related

to Microsoft, Apple and Google shall belong to the above-mentioned companies.

This manual is suitable for 8/16-channel digital video recorders. All examples and pictures used in the manual are from 16-channel DVR.

DVR User Manual

Table of Contents

1Introduction..................................................................................................................................................1

1.1 DVR Introduction...............................................................................................................................................................1

1.2 Main Features ....................................................................................................................................................................1

2Hardware Installation...................................................................................................................................4

2.1 Install Hard Drive &DVD Writer .........................................................................................................................................4

2.1.1 Install Hard Drive.......................................................................................................................................................................................4

2.1.2 Install DVD Writer .....................................................................................................................................................................................4

2.2 Front Panel Descriptions .....................................................................................................................................................5

2.3 Rear Panel Instructions........................................................................................................................................................6

2.4 Remote Controller..............................................................................................................................................................8

2.5 Control with Mouse..........................................................................................................................................................11

2.5.1 Connect Mouse........................................................................................................................................................................................11

2.5.2 Use Mouse ..............................................................................................................................................................................................11

3Basic Function Instruction..........................................................................................................................13

3.1 Startup & Shutdown..........................................................................................................................................................13

3.1.1 Startup....................................................................................................................................................................................................13

3.1.2 Shutdown................................................................................................................................................................................................13

3.2 Login ..............................................................................................................................................................................14

3.3 Live Preview....................................................................................................................................................................14

3.3.1 Live Playback..........................................................................................................................................................................................15

4Main Menu Setup Guide.............................................................................................................................16

4.1 Basic Configuration..........................................................................................................................................................17

4.1.1 System....................................................................................................................................................................................................17

4.1.2 Date & Time............................................................................................................................................................................................20

4.1.3 DST .......................................................................................................................................................................................................20

4.2 Live Configuration ...........................................................................................................................................................21

DVR User Manual

4.2.1 Live........................................................................................................................................................................................................21

4.2.2 Main Monitor ..........................................................................................................................................................................................21

4.2.3 Mask ......................................................................................................................................................................................................21

4.3 Record Configuration........................................................................................................................................................23

4.3.1 Enable ....................................................................................................................................................................................................23

4.3.2 Record Bitrate..........................................................................................................................................................................................23

4.3.3 Time.......................................................................................................................................................................................................24

4.3.4 Stamp .....................................................................................................................................................................................................25

4.3.5 Recycle Record........................................................................................................................................................................................25

4.3.6 Snap.......................................................................................................................................................................................................26

4.4 Schedule Configuration.....................................................................................................................................................26

4.4.1 Schedule .................................................................................................................................................................................................26

4.4.2 Motion....................................................................................................................................................................................................27

4.4.3 Sensor.....................................................................................................................................................................................................27

4.5 Alarm Configuration.........................................................................................................................................................27

4.5.1 Sensor.....................................................................................................................................................................................................28

4.5.2 Motion....................................................................................................................................................................................................29

4.5.3 Video Loss ..............................................................................................................................................................................................31

4.5.4 Other Alarm.............................................................................................................................................................................................31

4.5.5 Alarm Out ...............................................................................................................................................................................................31

4.6 Network Configuration .....................................................................................................................................................32

4.6.1 Network..................................................................................................................................................................................................32

4.6.2 Sub-stream ..............................................................................................................................................................................................33

4.6.3 Email......................................................................................................................................................................................................33

4.6.4 Server.....................................................................................................................................................................................................34

4.6.5 Other Settings..........................................................................................................................................................................................34

4.7 User Management Configuration........................................................................................................................................37

DVR User Manual

4.8 P.T.Z Configuration ..........................................................................................................................................................38

4.9 Advanced.........................................................................................................................................................................42

4.9.1 Reset ......................................................................................................................................................................................................42

4.9.2 Import/Export ..........................................................................................................................................................................................42

4.9.3 Block/Allow list.......................................................................................................................................................................................42

5Search，Playback & Backup ......................................................................................................................43

5.1 Time Search.....................................................................................................................................................................43

5.2 Event Search....................................................................................................................................................................44

5.3 File Management..............................................................................................................................................................45

5.4 Search by Image...............................................................................................................................................................46

5.5 Backup............................................................................................................................................................................47

6Manage DVR ..............................................................................................................................................48

6.1 Check System Information ................................................................................................................................................48

6.1.1 System Information ..................................................................................................................................................................................48

6.1.2 Event Information ....................................................................................................................................................................................48

6.1.3 Log Information.......................................................................................................................................................................................48

6.1.4 Network Information ................................................................................................................................................................................48

6.1.5 Online Information...................................................................................................................................................................................48

6.1.6 Record Information...................................................................................................................................................................................49

6.2 Manual Alarm..................................................................................................................................................................49

6.3 Disk Management.............................................................................................................................................................49

6.4 Upgrade...........................................................................................................................................................................49

6.5 Logoff.............................................................................................................................................................................50

6.6 IE Remote Surveillance.....................................................................................................................................................50

6.6.1 On LAN..................................................................................................................................................................................................50

6.6.2 On WAN.................................................................................................................................................................................................50

6.7 Remote Surveillance throughApple PC ..............................................................................................................................52

DVR User Manual

6.7.1 On LAN..................................................................................................................................................................................................53

6.7.2 On WAN.................................................................................................................................................................................................55

6.8 Remote Preview...............................................................................................................................................................56

6.9 Remote Playback & Backup ..............................................................................................................................................59

6.9.1 Remote Playback......................................................................................................................................................................................59

6.9.2 Remote Backup........................................................................................................................................................................................64

6.10 Remote System Configuration..........................................................................................................................................64

6.11 Tools.............................................................................................................................................................................65

6.12 Remote Information........................................................................................................................................................65

7Mobile Surveillance.....................................................................................................................................67

7.1 By Phones with Windows Mobile OS .................................................................................................................................67

7.2 By Phones with Symbian OS.............................................................................................................................................68

7.3 By Phones with Iphone OS................................................................................................................................................70

7.4 By Phones with Android OS ..............................................................................................................................................78

7.5 By Phones with Blackberry OS..........................................................................................................................................84

AppendixA FAQ...........................................................................................................................................89

Appendix B Calculate Recording Capacity....................................................................................................95

Appendix C Compatible Devices ...................................................................................................................96

Appendix D 8-CH Specifications ...................................................................................................................98

Appendix E 16-CH Specifications..................................................................................................................99

DVR User Manual

1Introduction

1.1 DVR Introduction

This model DVR (Digital Video Recorder) is designed especially for CCTV system. It adopts high performance video processing chips and

embedded Linux system. Meanwhile, it utilizes many most advanced technologies, such as standard H.264 with low bit rate, Dual stream,

SATA interface, VGA output mouse supported, IE browser supported with full remote control, mobile view(by phones), etc., which ensure

its powerful functions and high stability. Due to these distinctive characteristics, it is widely used in banks, telecommunication,

transportation, factories, warehouse, and irrigation and so on.

1.2 Main Features

COMPRESSION FORMAT

Standard H.264 compression with low bit rate and better image quality

LIVE SURVEILLANCE

Support VGA /CVBS/HDMI output

Support 8/16-ch SDI video inputs

Support channel security by hiding live display

Display the local record state and basic information

Support USB to make full control

RECORD MEDIA

Support eight SATA HDD to record for a longer time without any limitation

BACKUP

Support USB 2.0 devices to backup

Support built-in SATA DVD writer to backup

DVR User Manual

Support saving recorded files with AVI standard format to a remote computer through internet

RECORD & PLAYBACK

Record modes: Manual, Schedule, Motion detection and Sensor alarm recording

Support recycle after HDD full

Resolution, frame rate and picture quality are adjustable

8/16 audio channels available

Two record search mode: time search and event search

Support 8 screen playback simultaneously

Support deleting and locking the recorded files one by one

Support remote playback in Network Client through LAN or internet

ALARM

4 channel alarm output and 8/16 channel alarm input available

Support schedule for motion detection and sensor alarm

Support pre-recording and post recording

Support linked channels recording once motion or alarm triggered on certain channel

Support linked PTZ preset, auto cruise and track of the corresponding channel

PTZ CONTROL

Support various PTZ protocols

Support 128 PTZ presets and 8 auto cruise tracks

Support remote PTZ control through internet

SECURITY

Customize user right: log search, system setup, two way audio, file management, disk management, remote login, live view, manual

record, playback, PTZ control and remote live view

Support 1 administrator and 63 users.

DVR User Manual

Support event log recording and checking, events unlimited

NETWORK

Support TCP/IP, DHCP, PPPoE, DDNS protocol

Support IE browser to do remote view

Support setup client connection amount

Support dual stream. Network stream is adjustable independently to fit the network bandwidth and environment.

Support picture snap in remote live

Support remote time and event search, and channel playback with picture snap

Support remote PTZ control with preset and auto cruise

Support remote full menu setup, changing all the DVR parameters remotely

Support mobile surveillance by smart phones , Symbian, Windows phone, Iphone or Gphone, 3G network available

Support CMS to manage multi devices on internet

DVR User Manual

2Hardware Installation

Notice: Check the unit and the accessories after getting the DVR.

Please don‟t power up the unit till the physical installation is complete.

2.1 Install Hard Drive &DVD Writer

2.1.1 Install Hard Drive

Notice: 1. This series supports eight SATA hard drives. Please use the hard drive the manufacturers recommend specially for security and

safe field.

2. Please calculate HDD capacity according to the recording setting. Please refer to “Appendix B Calculate Recording Capacity”.

Step1: Unscrew and Open the top cover

Step2: Connect the power and data cables. Place the HDD onto the bottom case as Fig 2-1.

Step3: Screw the HDD.

Note: For the convenience to install, please connect the power and data cables firstly, and then screw to fix.

Fig 2-1 Connect HDD

2.1.2 Install DVD Writer

Notice: 1. The writers must be the compatible devices we recommend. Please refer to “Appendix C Compatible Devices”.

2. This device is only for backup.

Step1: Unscrew and Open the top cover.

Tabla de contenidos

Otros manuales de DVR de Active Vision

Active Vision

Active Vision SX-360 Manual de usuario

Active Vision

Active Vision SX-1400 Series Guía del usuario

Active Vision

Active Vision SX-460 Manual de usuario

Active Vision

Active Vision SX-460 Manual de usuario

Active Vision

Active Vision SX-420 Manual de usuario

Active Vision

Active Vision SX-412-16 Manual de usuario

Manuales populares de DVR de otras marcas

FLIR

FLIR M3100E Series Manual de usuario

VTRACKPRO

VTRACKPRO FPRO300 Manual de usuario

Swann

Swann NVR-7085 models Manual de usuario

XtendLan

XtendLan DVR-1670C Manual de usuario

urmet domus

urmet domus 1093/004AHD Manual de usuario

Holux

Holux M1 Manual de usuario

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manual de usuario

Whistler

Whistler D16VRS Manual de usuario

Defender Security

Defender Security 82-20235 Manual de usuario

MISUMI

MISUMI MP-WF100M Manual de usuario

Speco

Speco D8HU Manual de usuario

UST

UST DDR-E04AA Instrucciones de uso

Consolidated

Consolidated Digital Video Recorder Manual de usuario

Mace

Mace DVR0404RW Guía de inicio rápido

RCA

RCA RTD315W Manual de usuario

FSM

FSM Colibri Grande PRO Manual de usuario

Hauppauge

Hauppauge HD PVR 2 Manual de usuario

Identivision

Identivision ICR-PH161i PIONEER Manual de usuario
