L'acoustique active
Installation guide
Vendôme
2/8ver. 2017/07/18
Installation guide - Vendôme
FR
FR
135mm
75mm
Ø
6.5mm
25mm 50mm 75mm
1x clé six pans creux 5mm
1x enceinte
1x connecteur phoenix 4 pts
1x enjoliveur 1x M8x35mm
1x M8x60mm
1x M8x85mm
1x
1x
1x
4x M4x8mm
1x bague 25mm
1x bague 75mm
1x bague 50mm
1. Diagramme de perçage 2. Visser le support au mur
Vis non-fournies
3 Visser l’enjoliveur au support mural 4. Placer la bague d’écartement adaptée
4x M4 x8mm PZ1
Matériel inclus dans l’emballage
Câble
3/8 ver. 2017/07/18
Installation guide - Vendôme
FRFR
7. Orienter l’enceinte 8. Retirer l’enceinte et serrer la bague
9. Câbler l’enceinte 10. Placer l’enceinte sur le support
5. Verrouiller la bague 6. Placer l’enceinte sur le support
Choisir la vis adaptée à la bague
Serrer légèrement
Passer le câble
4/8ver. 2017/07/18
Installation guide - Vendôme
FR
EN
135mm
75mm
Ø
6.5mm
25mm 50mm 75mm
1x hex key 5mm
1x loudspeaker
1x 4-pin phoenix connector
1x plate 1x M8x35mm
1x M8x60mm
1x M8x85mm
1x
1x
1x
4x M4x8mm
1x bushing 25mm
1x bushing 75mm
1x bushing 50mm
1. Drilling diagram 2. Fix wall bracket on the wall
Screws not included
3 Screw plate on the wall bracket 4. Place the right bushing
4x M4x8mm PZ1
Parts included in the package
Cable
5/8 ver. 2017/07/18
Installation guide - Vendôme
ENEN
7. Angle the loudspeaker 8. Bring out the loudspeaker
9. Wire the loudspeaker 10. Bring in the loudspeaker on its bracket
5. Lock the bushing on the wall bracket 6. Bring in the loudspeaker on its bracket
Choose the right screw
Tighten slightly
Feed the cable through the
wallbracket
We,
ACTIVE AUDIO SAS,
8 Rue Johannes Gutenberg 44340 Bouguenais, France,
Declares under our sole responsability
that the following products
Vendôme 5, Vendôme 8
complie with the council directive 2004/108/CE
Assessment of compliance is based on the following standards:
EMC: EN 55103-1:2009, EN 55103-2:2009
EN 61000-3-2:2006+A1+A2, EN 61000-3-3:2008
Safety: EN 60065:2002+A1+A11+A2+A12
RoHS II: Directive 2011/65/UE - 2011/08/06
Established on the 1st of June 2017
by Régis CAZIN, CEO.
Plus d’informations sur
For more information, please visit
vendome.activeaudio.fr
www.activeaudio.fr
Active Audio
8 Rue Johannes Gutenberg
44340 Bouguenais - F
DOP_1174_A
rance
Phone: +33 (0)2 404 666 64
