User Manual
ACT550
Dual-zone AV Media Player
ACT550 USER MANUAL
480258EN-1.0 29/06/2016 Page 1 of 34
POL.
C/ CALIDAD, 66
28906 GETAFE
Tel: +34 91 665 26 26
Fax: +34 91 665 23 24
N.I.F. ES-A-28905065
ER-
1482/1999
TABLE OF CONTENTS
1. Before Use ............................................................................................................................................... 2
2. The ACT550 Equipment ......................................................................................................................... 3
3. Basic Operation ...................................................................................................................................... 6
4. AM/FM Radio ........................................................................................................................................... 9
5. USB / SD Card ....................................................................................................................................... 14
6. Hands-Free and Wireless Audio ......................................................................................................... 18
7. Aux ......................................................................................................................................................... 21
8. Microphone ........................................................................................................................................... 22
9. Audio Settings (Any Source) ............................................................................................................... 23
10.General Settings ................................................................................................................................... 24
11.Maintenance .......................................................................................................................................... 25
12.Troubleshooting ................................................................................................................................... 26
13.Technical Specifications ..................................................................................................................... 27
14.Package Contents ................................................................................................................................ 33
15.Installation and Connection ................................................................................................................ 34
ACT550 USER MANUAL
480258EN-1.0 29/06/2016 Page 2 of 34
POL.
C/ CALIDAD, 66
28906 GETAFE
Tel: +34 91 665 26 26
Fax: +34 91 665 23 24
N.I.F. ES-A-28905065
ER-
1482/1999
1. Before Use
WARNING
Avoid using this product if it might hinder driving safety.
Do not operate any function that takes your attention away from safe driving.
CAUTION
General:
Keep this manual handy as a reference for operating procedures and precautions.
Protect the equipment from moisture.
Volume setting:
Always keep the volume low enough so you can hear sounds outside of the vehicle.
Remote control:
PULL OUT THE INSULATION SHEET BEFORE THE FIRST USE.
Remove the battery if the remote control is not used for a month or longer.
Do not recharge, disassemble, heat or dispose of the battery on a fire.
Do not store the battery with metallic materials.
In the event of battery leakage, wipe the remote control completely clean and install a new battery.
Comply with the environmental regulations that apply in your country/area regarding batteries
disposal.
When replacing the battery, make sure that the position of the new one is correct (with positive
(+)
and negative (-) poles facing the proper directions).
How to read this manual
Operations explained mainly using buttons of the faceplate.
[XX] indicates the selected items (buttons).
ACT550 USER MANUAL
480258EN-1.0 29/06/2016 Page 3 of 34
POL.
C/ CALIDAD, 66
28906 GETAFE
Tel: +34 91 665 26 26
Fax: +34 91 665 23 24
N.I.F. ES-A-28905065
ER-
1482/1999
2. The ACT550 Equipment
The ACT550 Equipment plays different audio and video sources independently in the driver and
passenger areas (Dual-Zone). For this, it has controls on the front panel, remote control and external
control via CAN bus (if the vehicle has the necessary equipment).
Main characteristics:
Dual-Zone.
Radio AM/FM RDS.
Digital audio and video playing from USB devices and SD Cards.
Audio playing from iPhone, iPod and iPad devices through the USB connection.
Microphone inputs for driver and guide.
IR remote control.
Hands-free function compatible with Bluetooth devices.
Audio playing from Bluetooth devices.
External control by CAN bus.
Auxiliary audio and video inputs and outputs.
Radio line output.
Integrated audio amplifier 20W per loudspeaker.
Note!
Each zone, driver (DRV) or passenger (PSG) has its
own volume control and source selection
key (SRC). The rest of controls are common for both areas.
DIVX
This DivX Certified® device has passed rigorous testing to ensure it plays DivX® video.
To play purchased DivX movies, first register your device at vod.divx.com. Find your registration
code in the DivX® VOD section of your device USB/SD Car Settings menu.
Covered by one or more of the following U.S. patents:
7,295,673; 7,460,668; 7,515,710; 8,656,183; 8,731,369; RE45,052.
ACT550 USER MANUAL
480258EN-1.0 29/06/2016 Page 4 of 34
POL.
C/ CALIDAD, 66
28906 GETAFE
Tel: +34 91 665 26 26
Fax: +34 91 665 23 24
N.I.F. ES-A-28905065
ER-
1482/1999
Figure 1 ACT550 Front Panel
Figure 2 Remote Control
Note!
Before the first use:
Pull out the battery insulation sheet
protruding from the bottom of the
remote control.
Press the key [550]
to link the
remote control to the
Equipment
ACT550.
USB PORT
LCD SCREEN
SD CARD SLOT
POWER
DRIVER ZONE VOLUME
AND SOURCE SELECTIO
N
CONTROLS (DRV)
PASSENGER
ZONE VOLUME
AND SOURCE SELECTION
CONTROLS (PSG)
LINK THE REMOTE
CONTROL TO THE
EQUIPMENT ACT550
DRV
VOLUME
KNOB
POWER
DRV SOURCE
SELECTOR
PSG SOURCE
SELECTOR
PSG
VOLUME
KNOB
RESET
BUTTON
DRIVER ZONE (DRV) PASSENGER ZONE (PSG)
ACT550 USER MANUAL
480258EN-1.0 29/06/2016 Page 5 of 34
POL.
C/ CALIDAD, 66
28906 GETAFE
Tel: +34 91 665 26 26
Fax: +34 91 665 23 24
N.I.F. ES-A-28905065
ER-
1482/1999
2.1. Replacement of the Battery of the Remote Control
To replace the remote control battery:
1. On the back of the remote control, press the tab on the side of the battery cover
2. Slide and remove the cover
3. Install a battery type CR2025 with positive (+) and negative (-) poles facing the proper position
4. Push the cover into place. Make sure it is fully seated.
Figure 3 Replacement of the Battery of the Remote Control
ACT550 USER MANUAL
480258EN-1.0 29/06/2016 Page 6 of 34
POL.
C/ CALIDAD, 66
28906 GETAFE
Tel: +34 91 665 26 26
Fax: +34 91 665 23 24
N.I.F. ES-A-28905065
ER-
1482/1999
3. Basic Operation
Figure 4 Basic Controls
Table 1 Basic Controls
TO ACTION
Turn on/off the equipment 1. Put the vehicle ignition to ACC
2. Press [ ] to turn on the equipment
3. Press and hold [ ] to turn off the equipment.
Adjust the volume Turn the [VOLUME] knob or press the [VOLUME] keys on the remote
control.
Select a zone Press the [VOLUME] knob or the [SEL] key on the remote control, for the
concerned zone (driver or passenger).
The icons (Driver) o (Passenger) on the LCD screen indicate the
active zone at all times.
Select a source Press [SRC] repeatedly for the concerned zone until select the desired
source:
Radio AM/FM.
USB Player.
SD Card Player.
AV AUX (Auxiliary Input).
Wireless Audio (only available in the driver zone).
Silence the speakers Press [MUTE].
To release:
Press [MUTE] again to return to previous volume.
Reduce the volume and then increase it to unlock the silence.
Turn on the passenger
screens
Press [DISP] to turn on/off manually the passenger screens.
the LCD screen indicates that the passenger screens are ON.
Note!
For the remote control works with the ACT550 equipment, link the remote control with the
equipment by pressing [550].
ACT550 USER MANUAL
480258EN-1.0 29/06/2016 Page 7 of 34
POL.
C/ CALIDAD, 66
28906 GETAFE
Tel: +34 91 665 26 26
Fax: +34 91 665 23 24
N.I.F. ES-A-28905065
ER-
1482/1999
Note!
Some controls may not be available in the vehicle controls.
3.1. Restore the Factory Settings
To restore the values of the factory settings:
1. Switch off the equipment
2. Press and hold [DISP] while switching on the equipment [ ].
3.2. Reset of the Equipment
Note!
Perform a reset only if the equipment no longer responds to user controls.
To perform a reset, press the button [RESET] located on the left of the front panel (refer to Figure 1).
3.3. Reset and Restore the Factory Settings
Note!
Perform a reset and restore the factory settings only if the equipment no longer responds
to user
controls.
1. Press [RESET] + [DISP] simultaneously for 5 seconds
2. Release the button [RESET] while holding the key [DISP] until 3 beeps are heard.
3.4. Equipment Firmware Version
To display the equipment firmware version:
1. Select a source other than Radio
2. to Section 10)
3. Press and hold the key [1]. The firmware version is displayed in the LCD screen.
ACT550 USER MANUAL
480258EN-1.0 29/06/2016 Page 8 of 34
POL.
C/ CALIDAD, 66
28906 GETAFE
Tel: +34 91 665 26 26
Fax: +34 91 665 23 24
N.I.F. ES-A-28905065
ER-
1482/1999
3.5. Media Player Firmware Version
1.
2. 10)
3. To display the firmware version of the USB player:
press and hold the key [2] to display the firmware type BE
press and hold the key [3] to display the firmware type FE
4. To display the firmware version of the SD Card player:
press and hold the key [4] to display the firmware type BE
press and hold the key [5] to display the firmware type FE
5. When finished, press [VOLUME]
ACT550 USER MANUAL
480258EN-1.0 29/06/2016 Page 9 of 34
POL.
C/ CALIDAD, 66
28906 GETAFE
Tel: +34 91 665 26 26
Fax: +34 91 665 23 24
N.I.F. ES-A-28905065
ER-
1482/1999
4. AM/FM Radio
Figure 5 Radio Controls
4.1. Select a Frequency Band
With the Radio source selected, press [ ] / [BAND] repeatedly to select a frequency band: FM1, FM2,
FM3, AM1 or AM2.
Note!
Each frequency band has associated 6 memory positions.
4.2. Tune a Radio Station
With the Radio source selected:
Auto tuning (SEEK): press [ / ] to tune automatically to the next or previous station to the
current frequency.
Manual tuning (TUNE): press and hold [ / ] to activate the manual tuning. Press [ / ] repeatedly
(or press [ / ] on the remote control) to adjust the tuning frequency.
4.3. Radio Stations Continuous Scan
With the Radio source selected:
1. Press and hold [ ] / [BAND] to start the continous scan
When the equipment finds a valid radio station, the scan stops for a few seconds.
2. Press [ ] / [BAND] to stop the scan.
Note!
If the TA function is activated, the radio will only stop at those stations broadcasting traffic
news
and information.
