PC2120

All-in-One 12.1” TFT LCD

Panel PC

User’s Manual

Disclaimers

The information in this manual has been carefully checked and is

believed to be accurate. ACNODES assumes no

responsibility for any infringements of patents or other rights of third

parties hich may result from its use.

ACNODES assumes no responsibility for any inaccuracies that may be

contained in this document. ACNODES makes no commitment to update or to

keep current the information contained in this manual.

ACNODES reserves the right to make improvements to this document and/or

product at any time and ithout notice.

No part of this document may be reproduced, stored in a retrieval system, or

transmitted, in any form or by any means, electronic, mechanical,

photocopying, recording, or other ise, ithout the prior ritten permission of

ACNODES



Copyri ht 2004 by ACNODES

All ri hts reserved.

September 2004, Version A1

Printed in Taiw an

Safety Approvals



CE Marking



FCC Class A

FCC Compliance

This equipment has been tested and complies ith the limits for a

Class A digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. If not installed and used in

accordance ith proper instructions, this equipment might generate or

radiate radio frequency energy and cause harmful interference to

radio communications. Ho ever, there is no guarantee that

interference ill not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, hich

can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

follo ing measurers:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and

receiver.

Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician

for help.

Shielded interface cables must be used in order to comply ith

emission limits.

iii

Safety Precautions

Before getting started, read the follo ing important cautions.

1. The PC 2120 series does not come equipped with an

operating system. An operating system must be loaded

first before installing any software into the computer.

2. Be sure to ground yourself to pre ent static charge when

installing the internal components. Use a grounding wrist

strap and place all electronic components in any

static-shielded de ices. Most electronic components are

sensiti e to static electrical charge.

3. Disconnect the power cord from the PC 2120 series before

making any installation. Be sure both the system and the

external de ices are turned OFF. Sudden surge of power

could ruin sensiti e components. Make sure the PC 2120

series is properly grounded.

4. The brightness of the flat panel display decreases with

usage. Howe er, hours of use ary depending on the

application en ironment.

5. Turn OFF the system power before cleaning. Clean the

system using a cloth only. Do not spray any liquid cleaner

directly onto the screen. The PC 2120 series may come

with or w/o a touchscreen. Although the touchscreen is

chemical resistant, it is recommended that you spray the

liquid cleaner on a cloth first before wiping the screen. In

case your system comes without the touchscreen, you

must follow the same procedure and not spray any

cleaner on the flat panel directly.

6. A oid using sharp objects to operate the touchscreen.

Scratches on the touchscreen may cause malfunction or

internal failure to the touchscreen.

7. The flat panel display is not susceptible to shock or

ibration. When assembling the PC 2120 series, make

sure it is securely installed.

8. Do not open the system’s back co er. If opening the

co er for maintenance is a must, only a trained

technician is allowed to do so. Integrated circuits on

computer boards are sensiti e to static electricity. To

a oid damaging chips from electrostatic discharge,

obser e the following precautions:

Before handling a board or integrated circuit, touch an

unpainted portion of the system unit chassis for a few

seconds. This will help to discharge any static electricity on

your body.

When handling boards and components, wear a

wrist-grounding strap, a ailable from most electronic

component stores.

Trademarks Acknowled ments

ACNODES is a trademark of ACNODES ALi

is a trademark of Acer Laboratories, Inc.

AMD is a trademark of Advanced Micro Devices, Inc.

AMI is a trademark of American Megatrends, Inc.

Cyrix is a trademark of Cyrix Corporation.

IBM, PC/AT, PS/2, VGA are trademarks of International Business

Machines Corporation.

Intel and Pentium are trademarks of Intel Corporation.

MS-DOS, Microsoft C and QuickBASIC are trademarks of Microsoft

Corporation.

SMC is a trademark of Standard Microsystems Corporation.

C&T is a trademark of Chips and Technologies, Inc.

SST is a trademark of Silicon Storage Technology, Inc.

UMC is a trademark of United Microelectronics Corporation.

VIA is a trademark of VIA Technologies, Inc.

Other brand names and trademarks are the properties of their

respective o ners.

Table of Contents

Chapter 1 Introduction.....................................................1

1.1 General

Description

................................................1

1.2 Specifications..........................................................2

1.2.1 Core System for PC 2120 series system with

SBC85610VE ........................................................................ 2

1.2.2 System I/O outlet .................................................... 2

1.2.3 Built in Peripherals .................................................. 3

1.2.4 Net Weight ............................................................... 3

1.2.5 12.1" TFT LCD Specification..................................... 4

1.2.6 Environmental ......................................................... 4

1.2.7 Dimension (main body size) .................................. 4

1.3 Utilities

Supported

..................................................4

1.4 Dimensions..............................................................5

1.5 I/O

Outlets

................................................................6

Chapter 2 System Configuration ...................................9

2.1 Pedestal

Versatility

.................................................9

2.1.1 Desktop Standing.................................................. 10

2.1.2 Vertical Wall Mounting ......................................... 11

2.1.3 Wall Mounting ....................................................... 12

2.1.4 30

Table Standing ................................................ 14

Chapter 3 Hardware Installation .................................15

3.1 CPU

......................................................................16

3.2 DRAM

.....................................................................16

3.3 HDD

......................................................................16

3.4 Three

Serial

Ports

.................................................18

3.5 Parallel

Port

...........................................................18

3.6 VGA

......................................................................19

3.7 Ethernet..................................................................19

3.8

Cash Drawer (PC 2120-610e only)

........................20

3.9 Keyboard

and

Mouse............................................20

3.10 Expansion

Slot

....................................................21

3.11

USB and Dallas Key Installation

........................22

3.12

System O/S and Software Installation...............22

Appendi A Power Supply Specifications ................23

Appendi B System Configuration Limitation Notice

...............................................................................................25

vii

This pa e does not contain any information.

viii

PC 2120 All-in-One 12.1” TFT LCD Panel PC User’s Manual

C h a p t e r 1

Introduction

This chapter contains the general information and detailed

specifications of PC 2120 series. Chapter 1 includes the follo ing

sections:

General Description

System Specification

Utilities Supported

Dimensions

I/O Outlets

1.1 General

Description

The PC 2120 series super slim industrial panel PCs are mainly

designed for industrial automation and some space-constricted

embedded applications. For some space-concerned industries, a

traditional PC ith a separate main system, display monitor and

keyboard is simply not integrated enough.

Ruggedly designed, the PC 2120 series is 100% IBM PC/AT

compatible and it integrates super I/Os, 12.1” TFT touch screen,

Ethernet, and packs special industrial features like atchdog timer all

in a single system. The full PC functionality coupled ith its

industrial-grade construction easily tailors the system for any

embedded applications -- allo ing the system to endure continuous

operation in any hostile industrial environments here stability and

reliability is a must.

The PC 2120 series feature a versatile stand suited for a ide variety

of applications. With the pedestal kit assembled to the main unit, both

can transform into different positions such as desktop free standing,

table standing, panel mount and all mounting. Its cable

management device also trims the operation environment. The NEMA

4/12 ater/dust-proof front panel is specially designed for the

continuous operation in outdoor environments. Common applications

of these PANEL PCs include POS, POI terminals, Hospitality.

Introduction 1

PC 2120 All-in-One 12.1” TFT LCD Panel PC User’s Manual

are virtually the ultimate one-step solution for your space-limited

applications.

1.2 Specifications

1.2.1 Core System for PC 2120 series system with

SBC85610VE

CPU:

Soc et370 for Intel Celeron/Pentium III and VIA C3

processor

System Chipset:

VIA VT8601T, VT82C686B with integrated real-time cloc

BIOS:

Phoenix-Award BIOS, 4Mbit with RPL/PXE LAN Boot ROM

System Memory:

Two 168-pin DIMM Soc et Maximum of 1GB SDRAM

Watchdo Timer:

Generates a system reset or NMI by jumper selectable;

software programmable Time interval; 64 levels, 0.5~8 /

5~80 / 50~800 / 100~1600 seconds

1.2.2 System I/O outlet

Standard I/O:

„

3 x serial ports with power; 2 x RS-232(COM1,4 , 1 x

RS-232/422/485(COM2 jum

per selectable

„

1 x parallel port, SPP/EPP/ECP

„

1 x VGA port

„

1 x keyboard interface

„

1 x PS/2 mouse interface

2 Introduction

Otros manuales para PC 2120

Tabla de contenidos

Otros manuales de Panel táctil de Acnodes

Acnodes

Acnodes PC 2120 Manual de usuario

Acnodes

Acnodes PC 1150 Manual de usuario

Acnodes

Acnodes PCW81 Series Manual de usuario

Acnodes

Acnodes FPC 8121 Manual de usuario

Acnodes

Acnodes FPC 7161 Manual de usuario

Acnodes

Acnodes PC 1080 Manual de usuario

Acnodes

Acnodes PC 8153 Manual de usuario

Acnodes

Acnodes PC6152 Manual de usuario

Acnodes

Acnodes PC 8153 Manual de usuario

Acnodes

Acnodes PC 5150 Manual de usuario

Acnodes

Acnodes FPC 8059 Manual de usuario

Acnodes

Acnodes PC 5151 Manual de usuario

Acnodes

Acnodes 17" TFT Expandable Intel Core 2 Duo Industrial Panel PC with 2 PCI PC... Manual de usuario

Acnodes

Acnodes PANEL PC 1000 Manual de usuario

Acnodes

Acnodes PANEL PC 1000 Manual de usuario

Acnodes

Acnodes PCM8010 Manual de usuario

Acnodes

Acnodes FPC 8077 Manual de usuario

Acnodes

Acnodes PC 1150 Manual de usuario

Acnodes

Acnodes PC 5171 Manual de usuario

Acnodes

Acnodes PC 8150 Manual de usuario

Acnodes

Acnodes PC 5150 Manual de usuario

Acnodes

Acnodes PANEL PC 1000 Manual de usuario

Acnodes

Acnodes PC 8150 Manual de usuario

Acnodes

Acnodes PC 5170 Manual de usuario

Manuales populares de Panel táctil de otras marcas

FlowLine

FlowLine Data loop Manual de usuario

ALPEX

ALPEX AEx-8 P Series Manual de usuario

Ltech

Ltech E5S Manual de usuario

Harman

Harman AMX MODERO S MSD-701-L2 Manual de usuario

AIS

AIS IP10IA99 series Manual de usuario

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manual de usuario

YASKAWA

YASKAWA TP 610C Manual de usuario

B&R

B&R Power Panel C Series Manual de usuario

Beijer Electronics

Beijer Electronics X2 control Manual de usuario

AXIOMTEK

AXIOMTEK GOT321W-521 Manual de usuario

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manual de usuario

Qomo

Qomo QIT1386 Manual de usuario

DFI

DFI KS104-CD Manual de usuario

AMX

AMX AXP-PPC Guía

Sartorius

Sartorius X3 PR 5410 Manual de usuario

AMX

AMX Modero X Series Manual de usuario

Advantech

Advantech TPC-30 Series Manual de usuario

B&R Industries

B&R Industries MAPPC900-ENG Manual de usuario
