ACME GA06 Manual de usuario
action
game
pad
Model: GA06
www.acme.eu
3
4 GB User’s manual 82 Warranty card
10 LT Vartotojo gidas 83 Garantinis lapas
16 LV Lietošanas instrukcija 84 Garantijas lapa
22 EE Kasutusjuhend 85 Garantiileht
28 PL Instrukcja obsługi 86 Karta gwarancyjna
34 DE Bedienungsanleitung 87 Garantieblatt
40 RO Manual de utilizare 88 Fişa de garanţie
46 BG Ръководство за употреба 89 Гаранционен лист
52 RU Инструкция пользователя 90 Гарантийный талон
58 UA Інструкція 91 Гарантійний лист
64 ES Manual de usuario 92 Hoja de garantía
70 FR Manuel de l’utilisateur 93 Document de garantie
76 PT Manual do usuário 94 Folha de garantia
4
GB
Introduction
Thank you for choosing the PC Gamepad and congratulations on this decision. We are certain that
product will provide much playing pleasure for years to come. These instructions contain valuable
information on operating and conguring the gamepad. Keep these instructions and the software
CD in a safe location for future reference.
Product features
• Double vibration for better gaming experience
• 6 re buttons
• 4 shoulder buttons
• Two 360°mini-joysticks with digital buttons underneath
• Eight-way direction pad (D-Pad)
• Analog and digital modes supported
• USB connection
• Compatible with Windows XP / VISTA/ 7™
Waste Electrical and Electronic Equipment (WEEE) Symbol
The use of the WEEE symbol indicates that this product may not be treated as household waste.
By ensuring this product is disposed of correctly, you will help protect the environment. For more
detailed information about the recycling of this product, please contact your local authority, your
household waste disposal service provider or the shop where you purchased the product.
5
GB
General description
1
6 easy-to-
reach (“Fire”)
buttons
2
3
4
Select (9)
Start (10)
11 L3 button / Mini Left Stick
12 R3 button / Mini Right Stick
13 Analog / Digital mode changing button
14 Analogue / Digital mode indicator
15 8-way D-pad
16 „TURBO“ button
17 „CLEAR“ button
5 / L1
4 fast-action
shoulder
buttons
6 / R1
7 / L2
8 / R2
6
GB How to use analog mode
On analog mode LED (14) will shine.
In Analog mode, the left stick supports X, Y axis and right stick supports Z, Rz axis. It is 8 way function
mode for D-pad. Please note that when you push the center of analog stick, it turns on L3 button
function (left stick) and R3 button function (right stick).
How to use digital mode
If you want to use Digital mode, you need to press MODE button (13). In Digital mode, the left stick
supports D-pad function with X, Y axis.
Usage of“Turbo” button
“Turbo” mode allows to automatically repeat its function without limit by pressing a button which
has been assigned as a“Turbo”button.“Turbo”mode is available for buttons from 1 to 12 (see table).
The button can be assigned by pressing the “Turbo” button and pressing the chosen button from 1
to 12. To turn o the“Turbo”function of the programmed button hold“Clear”and press the assigned
button.
Important safety instructions
When using electrical appliance, especially when children are present, basic safety precautions
should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING.
WARNING – To reduce the risk of burns, electrocution, re, or injury to persons:
7
GB
1. Do not expose the controller to high temperature, high humidity or direct sunlight. (Use in an
environment between 5 – 35 ºC / 41 – 95 ºF).
2. Do not allow liquid or small particles to get into the controller.
3. Do not put any heavy objects on the controller.
4. Never disassemble or modify the controller.
5. Do not twist the cable or pull it forcibly.
6. Do not bend, throw or drop the controller or subject it to strong physical shock. Do not touch
the metal parts or insert foreign objects in the controller.
7. Do not attempt to service or repair the device in question. Leave service work to qualied
experts.
8. Do not modify the device in any way. Doing so voids the warranty.
Installation
Installing the software
1. Place enclosed driver CD into the CD-ROM drive.
2. The installation program will start automatically.
3. If this does not happen, proceed as follows:
a. Go to“My Computer”
b. Select your CD-ROM driver and double click it.
c. Double click the setup.exe le.
4. Follow the steps in the installation program.
5. Restart your PC.
Installing the Hardware:
1. Your operating system may prompt you to insert your Windows CD to install the new hardware
8
GB components.
2. To congure the device, click:
Start—> Settings—> Control panel—> Game controllers
3. Select the required device.
4. Now click“Properties”to test and calibrate all functions in the menu, including Force Feedback.
Functions
Vibration function
The Gamepad has two internal motors which work only in games supporting “Force Feedback”
function and when supplied drivers have been installed. See the manual of your game on whether
the game supports vibration or not. If problems persist, check whether vibration support was
activated in the game options.
Notes:
• Ensure that your game software supports game controllers.
• In order to use the vibration function, your game’s software must support Force Vibration/Force
Feedback.
• If some buttons do not work, check key settings in the game’s options menu.
Cleaning
To clean the Game Pad, wipe with a mildly damp cloth.
• Never immerse into water, as the unit contains sensitive electronic components that may be
destroyed, voiding your warranty.
9
GB
• Do not use any harsh cleaners or disinfectants on your Game Pad.
• A damp cloth with a dab of dish-washing detergent or “Computer Case and Monitor” cleaning
solution available at any computer store will be sucient.
Storage
• When not in use, store your Game Pad in a dust-free area, preferably in its original packaging.
• Keep all the Game Pad components away from sources of major heat (baseboard heaters, car
dashboard, etc.).
• Keep the Game Pad away from any major magnetic sources.
Troubleshooting
My game pad doesn’t work
• Check the USB port to which it is connected. It is possible that USB port is dead. Try to connect
another appliance to this port to nd out.
• The power cord of the game pad can by damaged. Unplug the USB port from power socket and
check it carefully. If it is damaged, you must give it to replace by authorized service.
My game pad drivers can’t be installed
• Check if your OS is supported for this device. Supported OS list is on your game pad package.
10
LT
Įžanga
Dėkojame, kad pasirinkote asmeninio kompiuterio žaidimų pultą, džiaugiamės jūsų sprendimu.
Esame įsitikinę, kad gaminys metų metus jums teiks daug malonumo žaidžiant. Šioje instrukcijoje
pateikiama vertinga informacija apie žaidimų pulto funkcijas ir kongūravimą. Laikykite šią
instrukciją ir programinės įrangos kompaktinį diską saugioje vietoje, nes ateityje jų gali prireikti.
Savybės
• Dviguba vibracija, sustiprinanti pojūčius žaidžiant
• 6„re“ mygtukai
• 4 briaunų mygtukai
• Dvi 360° mini svirtelės su skaitmeniniais mygtukais apačioje
• Aštuonių padėčių kryptinis pultas (D-pad)
• Palaikomi analoginis ir skaitmeninis režimai
• USB jungtis
• Veikia su Windows XP / VISTA/ 7™ operacinėmis sistemomis
Elektroninių atliekų ir elektroninės įrangos (WEEE) ženklas
WEEE ženklu nurodoma, kad gaminys gali būti panaudotas kaip namų apyvokos atlieka.
Užtikrindami, kad šis gaminys būtų išmestas pagal taisykles, Jūs padėsite aplinkai. Norėdami
sužinoti daugiau informacijos apie šio gaminio perdirbimą, susisiekite su savo vietinės valdžios
institucija, Jūsų namų ūkiui priklausančiu atliekų paslaugų teikėju arba parduotuve, iš kurios
pirkote šį gaminį.
