Acer ICONIA Manual de usuario
Acer ICONIA Tab
Quick Guide
Acer recommends...
Productivity Software
Work Great with Microsoft
®
Office 2010
- Express your ideas, solve problems and simplify everyday projects
with Office 2010.
Photo editing
- Easily edit and print your photos with Windows Live Photo Gallery. Then share them on
Facebook, YouTube or Windows Live.
Search & Decide with Bing
-- Find and organize the answers you need using Bing™, so you can make faster,
more informed decisions.
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
© 2011 All Rights Reserved.
Acer ICONIA Tab Quick Guide
Original Issue: 02/2011
iii
First things first
We would like to thank you for making an Acer notebook your choice for
meeting your mobile computing needs.
Your guides
To help you use your Acer notebook, we have designed a set of guides:
First off, the setup poster helps you get started with setting up your computer.
The Iconia Tab Generic User Guide contains useful information applying to all
models in the Iconia Tab product series. It covers basic topics such as using the
keyboard and audio, etc. Please understand that due to its nature, the Generic
User Guide will occasionally refer to functions or features which are only
contained in certain models of the series, but not necessarily in the model you
purchased. Such instances are marked in the text with language such as "only
for certain models".
The Quick Guide introduces you to the basic features and functions of your new
computer. For more on how your computer can help you to be more productive,
please refer to the Iconia Tab Generic User Guide. This guide contains detailed
information on such subjects as system utilities, data recovery, expansion
options and troubleshooting. In addition it contains warranty information and
the general regulations and safety notices for your notebook. It is available in
Portable Document Format (PDF) and comes preloaded on your notebook.
Follow these steps to access it:
1 Click on Start > All Programs > Documentation.
2 Click on Iconia Tab Generic User Guide.
Note: Viewing the file requires Adobe Reader. If Adobe Reader is not
installed on your computer, clicking on Iconia Tab Generic User Guide will
run the Adobe Reader setup program first. Follow the instructions on the
screen to complete the installation. For instructions on how to use Adobe
Reader, access the Help and Support menu.
iv
First things first iii
Your guides iii
Your Acer tablet PC tour 1
Connect the tablet to the docking station / keyboard 1
Tablet PC 2
Front view 2
Back view 3
Top view 3
Bottom view 4
Left view 4
Right view 5
Booting your tablet 5
Key functions for boot menus 5
Docking station / keyboard 6
Top view 6
Front view 7
Left view 7
Right view 8
Environment 8
Acer Ring 9
Sync function 10
Clean Disk function 10
TouchBrowser 11
Adding a page to your Favorites 13
My Journal 14
Editing pages 15
Web Clip 15
Acer clear.fi 18
Media content types 18
DMS (Digital Media Server) devices 18
Display media content 18
Send media content 19
Search media 19
Block and unblock devices 19
Media sharing settings 19
Device Control 20
SocialJogger 22
Sharing content 24
Settings 25
Acer Backup Manager 26
Contents
English
Connect the tablet to the docking station / keyboard 1
Your Acer tablet PC tour
After setting up your computer as illustrated in the setup poster, let us show
you around your new Acer computer.
You can enter information into you new computer via the touchscreen or with
the docking station / keyboard.
Note: The docking station / keyboard is optional.
Connect the tablet to the docking station /
keyboard
Align the two arrows printed beneath the screen with the two pins on the
docking station / keyboard. Press the tablet down.
Your Acer tablet PC tour2
English
Tablet PC
Your new computer has two components, the tablet and the docking station /
keyboard. The following set of images will show you the Tablet PC. The views
are labeled as if you are holding the Tablet with the screen towards you and the
cameras at the top.
Front view
No. Item Description
1 Latch Secures the tablet to the docking station / keyboard
when closed.
2 Integrated
webcam
Web camera for video communication.
3 Windows key /
power status
indicator
Press once to open the Start menu.
Press once while holding the power button to perform
the <Ctrl> + < Alt> +<Del> function.
Status indicator color Power status
Blue System turned on.
Slow flash: Orange System in Standby mode.
Flashing: Orange System entering Hibernate mode.
Off System in Hibernate mode or turned off.
1
2
3
English
Tablet PC 3
Back view
Top view
No. Item Description
1 Integrated webcam Web camera for video communication.
2 SIM card slot Accepts a 3G SIM card.
3 Speaker Delivers audio output.
No. Item Description
1 Ventilation slot Provides adequate air flow to maintain a safe
operating temperature.
1
23
1
Your Acer tablet PC tour4
English
Bottom view
Left view
No. Icon Item Description
1 USB 2.0 port Connect to USB 2.0 devices (e.g., USB
mouse, USB camera).
2 Lock switch Locks the screen orientation.
3 Dock connector Connects to the supplied keyboard /
docking station. USB port may also be
used as a standard USB port.
4 SIM card slot Accepts a 3G SIM card.
No. Icon Item Description
1 Headphone jack Connect to USB 2.0 devices (e.g., USB
mouse, USB camera).
2 Battery LED Indicates the computer's battery status.
1. Charging: Amber.
2. Fully charged: Blue when plugged in.
3 Power button Press to turn the tablet on; press again to
place the tablet in Sleep mode. Press and
hold to turn the tablet off.
4 Volume key Press to increase or decrease volume.
5 Ventilation slot Provides adequate air flow to maintain a
safe operating temperature.
6 2-in-1 card reader Accepts Secure Digital (SD),
MultiMediaCard (MMC).
Note: Push to remove/install the card.
Only one card can operate at any time.
12 3 4
12 43567
