Acer AR385 F1 specifications

Product overview

The Acer AR385 F1 is a dual socket 2U server for space-conscious users who demand highest

performance and utmost expansion capability. Offering high performance, latest technology, cost-effective

growth, and comprehensive management features, Acer AR385 F1 delivers optimized performance per

cost solution in enterprise environment deployments.

Internal view

1 2 x 720 W 80 PLUS

gold-level efficient easy-swap power supplies (1+1 redundant, hot-

pluggable)

2 2 x AMD Opteron

™

6200 / 6100 series processors

3 24 x DDR3 ECC registered / unbuffered DIMMs

4 N+1 redundant cooling fans

5 6 x PCIe expansion slots

6 1 x 5.25” media expansion bay

7 1 x slimline ODD bay

8 Up to 6 x 3.5” hot-swappable hard drive bays, or

Up to 16 x 2.5” hot-swappable hard drive bays

2 3

8 6

Acer AR385 F1 specifications

Front View

Rear View

Front I/O

1 2 x USB 2.0 ports

2 Video port

Note: Only one video port may be used at any given time

3 5.25” media drive bay

4 Network, hard drive, power, and system status indicators

Rear I/O

1 PS2 mouse and keyboard ports

2 2 x USB ports

3 4 x Gigabit LAN port (RJ-45)

Acer AR385 F1 specifications

4 Video port

Note: Only one video port may be used at any given time

5 Serial port

6 System ID LED

7 Management port (RJ-45)

What's New

•Next-gen AMD Opteron 6200 processor support

NOTE: 6200 support begins in Q4 2011

•Hot-pluggable/redundant power supply with 80 PLUS®gold-level efficiency

•Smart Server Manager v1.1 with improved management functionality

Product Specifications

Processors and Chipset

•Up to two AMD Opteron 6200 / 6100 series processors

•Chipset: AMD SR5690/SP5100

Memory

•Memory capacity:

•Registered DIMM: 2, 4, 8, 16 GB

•Unbuffered DIMM: 2, 4 GB

•Up to 384 GB registered DIMMs when fully populated with 3 DIMMs per channel in 24 slots

•Up to 64 GB unbuffered DIMMs when fully populated with 2 DIMMs per channel in 16 slots

Network Controllers

•2 x Integrated Intel® 82576EB Gigabit Ethernet Controller with dual ports

Storage

•Hard disk form factor: 2.5” or 3.5”

•Type: SAS / SATA with hot-plug capability

•3.5” Maximum capacity:

Up to 12 TB SATA HDD (2 TB 3.5" x 6 HDDs)

Up to 3.6 TB SAS (600 GB 3.5” x 6 HDDs)

•2.5” Maximum capacity:

Up to 16 TB SATA HDD (1 TB 2.5" x 16 HDDs)

Up to 14.4 TB SAS (900 GB 2.5” x 16 HDDs)

Storage Controllers

•Integrated AMD®SP5100 Chipset Serial ATA host controller with RAID 0, 1, 10 support

•Optional PCIe 4-/8-/16-port SAS RAID card

Expansion slots

•Three Full-hight PCIe®x16 slots ( x8 lanes; left-riser)

•One PCIe®x4 slot (x4 lanes, right-riser)

•Two PCIe®x4 slot (x1 lanes; right-riser)

Management

•Acer Smart Server Manager

•System ID LED buttons, System Health LED

Acer AR385 F1 specifications

•

Acer Smart Console for server management and KVM over IP remote management

Deployment/Serviceability

•Acer Smart Setup

•BIOS Update Tool

•IPMI Firmware Update Tool

Operating Systems

•Windows Server®2008

•Windows Server®2008 R2

•Windows Server®2003

•Red Hat®Enterprise Linux 5.4 (available with AMD Opteron 6100 series)

•Red Hat®Enterprise Linux 6.1 (new for AMD Opteron 6200 series)

•SUSE®Linux Enterprise Server 11 SP1 (available with AMD Opteron 6100 series)

•SUSE®Linux Enterprise Server 11 SP2 (new for AMD Opteron 6200 series)

•VMware ESXi™4 update 1 (available with AMD Opteron 6100 series)

•VMware ESX™4 update 1 (available with AMD Opteron 6100 series)

•VMware vSphere™5 with ESXi™5 (new for AMD Opteron 6200 series)

Input/output interface

Front

•2 x USB 2.0 ports

•Video port

•Network, hard drive and power, and system status indicators

Rear

•PS2 mouse and keyboard ports

•2 x USB ports

•4 x Gigabit LAN port (RJ-45)

•Video port

•Serial port

•System ID LED

•Management port (RJ-45)

Chassis/Form Factor

•2U rack optimized

Power Supply

•2 x 720 W 80 PLUS® gold-level efficient, easy-swap power supply (1+1 redundant, hot-pluggable)

Regulatory Compliant Standards

EMC

•FCC (Class A)

•CE (Class A)

•BSMI (Class A)

Safety

•UL/cUL

•CB

•Nemko/GS

Acer AR385 F1 specifications

Environmental Specifications

Dimensions 438.4 mm (W) x 705 mm (D) x 88.1 mm (H) ( 17.3 x 27.8 x 3.5 inches)

Weight Maximum 39 kg (88.1 lbs)

Minimum (includes a single HDD, CPU and

RAM, and PSU)

28.5 kg (62.8 lbs)

System inlet

temperature

Operating 10°- 35°C (50°- 95°F)

Non-operating -40°- 70°C (-40°- 158°F)

Relative

humidity

Operating 8 - 90 %

Non-operating 5 - 95 %

Acoustics Idle

LWAd 6.3 BA

LpAm 46.5 dBA

Operating

LWAd 6.4 BA

LpAm 51.2 dBA

Power Rated Steady –state power 720 W

BTU rating 2456.64 BTU/hr at 100 - 240 VAC

Acer AR385 F1 specifications

Technical specifications

PCIe®specifications

The primary I/O bus for the main board is PCIe Gen2. The following table lists the characteristics of the PCI-E

bus segments. Details about each bus segment follow the table.

NOTE: The signaling bit rate of PCI Express is 2.5Gbit/s one direction per lane for Gen 1 and 5.0Gbit/s one

direction per lane for Gen 2.

Expansion slot Number Type Bus

width1

Voltage Connector Location Length

PCIe x16 3 PCIe Gen2 x8 3.3V x16 Riser, left Full height

PCIe x4 1 PCIe Gen2 x4 3.3V x4 Riser, right Low profile

PCIe x4 2 PCIe Gen2 x1 3.3V x4 Riser, right Low profile,

half-length

NOTE:

1. Indicates the number of physical electrical lanes running to a PCIe® connector.

2. Default bus assignment (in decimal). Inserting cards with PCI™ bridges may alter the actual bus assignment

number.

3. Slots are enumerated differently based on the operating system. Microsoft® operating systems enumerate

Device ID by bus starting from the lowest bus to the highest.

Onboard storage specifications

Item Description

Controller AMD®SP5100 SATA controller

Simultaneous drive transfer channels 6 onboard SATA ports

Max throughput per channel 3 Gb/s

Data transfer method •Non-RAID mode

•RAID mode (Adaptec RAID driver)

Drive type supported Serial ATA

RAID levels support •RAID 0, 1, 10 (Adaptec software RAID)

RAID function support Supports multiple logical volumes

Setup through ROM based Array Configuration Utility

Installation scripting support

NOTE: This controller does not support LED functions

RAID OS support

•

Windows Server 2008

•Windows Server 2008 R2

•Windows Server 2003

•Red Hat Enterprise Linux 5.4

•SuSE Linux Enterprise Server 11

Additional features •NCQ (Native Command Queuing)

•AHCI (Advanced Host Controller Interface)

Acer AR385 F1 specifications

Onboard LAN specifications

Item Description

Controller 2 x Intel®82576EB Gigabit Ethernet Controller

(4 ports total)

Network interface 10Base-T / 100Base-TX / 1000Base-T

Compatibility standards •IEEE 802.3 Ethernet interface for 10BASE-T

•IEEE 802.3ab Ethernet interface for 1000BASE-T,

•IEEE 802.3u Ethernet interface for 100BASE-TX

Manageability •NC-SI, SMBus

•PXE, iSCSI boot

Virtualization acceleration Intel

I/O Acceleration Technology

Virtual Machine Device Queues (VMDq)

PCI-SIG SR-IOV implementation

Connector RJ-45

Supported cable type CAT 5e wire

Memory specifications and population

Item Description

Supported memory types •Registered DDR3 1066 / 1333 MHz

•Unbuffered DDR3 1066 / 1333 MHz

NOTE: Acer does not qualify mixed memory configurations of

memory type, capacity or make.

Population Acer’s validated memory populations are listed below.

NOTE: Support for 8 / 16 GB DIMMs may vary by regional

availability.

Single processor configuration

NOTE: Quad Rank DIMMs and Unbuffered DIMMs can only use a maximum of 4 slots per CPU

DIMM# 1C 1B 1A 2C 2B 2A 3C 3B 3A 4C 4B 4A

2 x x

4 x x x x

8 x x x x x x x x

12 x x x x x x x x x x x x

Acer AR385 F1 specifications

Dual processor configuration

NOTE: Quad Rank DIMMs and Unbuffered DIMMs can only use a maximum of 4 slots per CPU

CPU 1 CPU 2

DIMM#

1C 1B 1A 2C 2B 2A 3C 3B 3A 4C 4B 4A 1C 1B 1A 2C 2B 2A 3C 3B 3A 4C 4B 4A

4 x x x x

8 x x x x x x x x

16 x x x x x x x x x x x x x x x x

24 x x x x x x x x x x x x x x x x x x x x x x x x

On-Line Spare

On-line spare is a RAS mechanism that allows the system to reserve one rank of one logical DIMM to be used

as a spare rank. The spare rank must be greater than or equal to the size of all other ranks in the system. The

system can switch to the spare rank when system software determines that one of the ranks in the system is

no longer functioning properly and needs to be replaced.

Memory Identification

Generally, there are some memory information printed on the label of DIMM, but different vendor may have

different format. For example:

4GB 2Rx4 PC3-10600R xx xx xxx

1. Density

1GB, 2GB, 4GB, 8GB, 16GB

2. Rank

1R = Single Rank

2R = Dual Rank

4R = Quad Rank

Note: if any quad rank DIMM is used, maximum only 2 DIMM per channel can be supported

3. Bit Organization

This platform supports x4 and x8

Note: It’s not recommend to mix DIMM with different bit organization in one system

4. Speed

PC3 – 6400 => DDR3- 800

PC3 – 8500 => DDR3- 1066

PC3 – 10600 => DDR3- 1333

Acer AR385 F1 specifications

Power specifications

720W Power Supply

Operational Input

Voltage Range

(Vrms)

100 to 240

Frequency

Range (Nominal)

(Hz)

60/50

Nominal Input

Voltage (Vrms)

100 120 208 200 220 230 240

Max. Rated

Output Wattage

720 720 720 720 720 720 720

Nominal Input

Current (A rms)

8.46 6.97 3.80 3.87 3.74 3.5 3.29

Max. Rated Input

Wattage Rating

(Watts)

846.0 836.4 790.4 774.0 822.8 805.0 789.6

Max. Rated VA

(Volt-Amp)

837.54 828.03 774.59 758.52 806.34 788.9 773.81

Efficiency (%) at

Max. Rated

Output Wattage

88.12 89.49 90.95 90.74 91.51 91.92 92.27

Power Factor 0.99 0.99 0.98 0.98 0.98 0.98 0.98

Leakage Current

(mA)

0.17 0.19 0.29 0.31 0.35 0.37 0.41

Max. Inrush

Current (A peak)

17.24 19.41 18.52 16.88 16.48 20.47 22.54

Max. Inrush

Current Duration

(mS)

4.62 4.58 4.61 4.62 4.64 4.63 4.64

Max. British

Thermal Unit

Rating (BTU/hr)

2456.64 2456.64 2456.64 2456.64 2456.64 2456.64 2456.64

Acer AR385 F1 specifications

Acer server software utilities

Smart Setup 2.X

Easy deployment via the latest version of Acer’s Smart Setup. Smart Setup is

available both in box as a driver packed installation DVD or a downloadable file to be

put into a USB 2.0 device, and eases the deployment of Acer servers for any certified

OS. Through its unique interface, users may select to have all the correct drivers be

pre-deployed for the OS of their choosing, as well as setup hardware RAID devices,

BMC settings (where available), and even clone the pre-settings to a bootable USB

device to ease mass server deployments.

Smart Console

Web-based management utility to simplify system management with embedded

iBMC, system monitoring and alerting, event handling, remote power control and

KVM-over-IP. Smart Console is OS independent and offers virtual media through

floppy, ODD, and removable disk.

Smart Server

Manager v1.1

Offering 24-7 monitoring for system health and performance.

Delivers proactive event management features including system event logging,

event handling from e-mail and SNMP Trap (PET) alerting.

Monitors onboard hardware, operating systems and virtual machines

Allows remote control from KVM and Power control

Satisfies management in web-based UI, role-based administration, and automated

management scripts.

Otros manuales para AR385 F1

Otros manuales de Servidor de Acer

Acer

Acer AR180 F1 Series Manual de usuario

Acer

Acer Extensa 500 Manual de lista de piezas

Acer

Acer Altos R920 Series Manual de usuario

Acer

Acer AW2000ht-AW170ht F1 Manual de usuario

Acer

Acer Altos 350 Manual de usuario

Acer

Acer Altos R920 Series Manual de usuario

Acer

Acer Altos G320 Series Manual de usuario

Acer

Acer Altos R310 Manual de usuario

Acer

Acer Altos 19000PRO4 Manual de lista de piezas

Acer

Acer AT150 F1 Series Manual de usuario

Acer

Acer Altos G540 M2 Series Manual de usuario

Acer

Acer AB460 F1 Manual de usuario

Acer

Acer Network Device Altos R520 Manual de usuario

Acer

Acer Altos G300 Manual de usuario

Acer

Acer Altos S300 Manual de usuario

Acer

Acer AR360 F1 Series Manual de usuario

Acer

Acer Altos R720 Series Manual de usuario

Acer

Acer Veriton N2110G Manual de usuario

Acer

Acer AR380 F1 Series Manual de usuario

Acer

Acer G310 Altos Manual de usuario

Acer

Acer Altos G540 Series Manual de usuario

Acer

Acer Altos G700 series Manual de usuario

Acer

Acer Veriton 9100 Manual de usuario

Acer

Acer Altos G530 Series Guía de configuración

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

Dell

Dell PowerEdge R410 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

Dell

Dell PowerEdge XE9640 Manual

Dell

Dell PS4100 Instrucciones de montaje

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

Dell

Dell PowerEdge 3YPMN Manual de usuario

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario
