SERVICE MANUAL

SI : TSE: Check: Approved:

Date Revise Version Description

2007.08.27 V1.0 Initial Issue

2008.07.09 V2.0 Add X1160 Refresh/X1260 Refresh

2008.08.25 V3.0 Add X1160Z/X1160Z Refresh

2008.10.10 V4.0 Add X1260K Refresh

X1160 Series/X1260 Series

X1160Z Series/X1260K Refresh

X1160 Series/X1260 Series/X1160Z Series/X1260K Refresh Condential

PARTS X1160 X1160refresh X1160Zrefresh X1160Z X1260 X1260refresh X1260Krefresh

LOGO

MYLAR

35.88T02G001 35.88T03G001 35.89B02G001

IO MYLAR 35.88T01G001 35.89B01G001

THERMAL

SWITCH

N/A 43.89T17G001

DMD 48.87K01G001 48.87M01G001 48.89B01G001

SPEAKER N/A 49.89B01G001

BLOW-

ER1

49.88T01G001

BLOW-

ER2

N/A 49.86E02G001

ZOOM

RING

N/A 51.89B04G001 51.89B04G001

FRONT IR

CAP

N/A 51.88T24G001 N/A 51.88T24G001

FRONT

COVER

51.88T03G001 51.88T27G001 75.89B02G001 75.89B01G001 75.89B02G001

IR SEN-

SOR BD

N/A 80.87Y05G001 N/A 80.87Y05G001

COLOR

WHEEL

70.88T11GR01 70.88T35GR01 70.88T11GR01 70.88T11GR01 70.88T35GR01

ENGINE 70.88T12GR01 70.88T37GR01 70.88T20GR01 70.89B10GR01 70.89B28GR01

MAIN BD 70.88T13GR01 70.88T36GR01 70.88T38GR01 70.88T21GR01 70.89B07GR01 70.89B27GR01 70.89B43GR01

LAMP

DRIVER

70.88T22GR01 70.88T34GR01 70.88T22GR01 70.88T22GR01 70.88T34GR01

LVPS 75.88T01G101 75.88T08G001 75.88T01G101 75.88T08G001 75.8BE01G001

X1160 Series/X1260 Series/X1160Z Series/X1260K Refresh Condential

Preface

This manual is applied to X1160 Series/X1260 Series/X1160Z Series/X1260K Refresh

projection system. The manual gives you a brief description of basic technical information

to help in service and maintain the product.

Your customers will appreciate the quick response time when you immediately identify

problems that occur with our products. We expect your customers will appreciate the

service that you offer them.

This manual is for technicians and people who have an electronic background. Please

send the product back to the distributor for repairing and do not attempt to do anything that

is complex or is not mentioned in the troubleshooting.

Notice:

The information found in this manual is subject to change without prior notice. Any

subsequent changes made to the data herein will be incorporated in future edition.

X1160 Series/X1260 Series/X1160Z Series/X1260K Refresh Service Manual

Manual Version 4.0

X1160 Series/X1260 Series/X1160Z Series/X1260K Refresh Condential

Table of Content

Chapter 1 Introduction

Highlight 1-1

Compatible Mode 1-3

Product Overview 1-5

Chapter 2 Disassembly Process

Equipment Needed & Product Overview 2-1

Disassemble Lamp Cover Module 2-2

Disassemble Lamp Module 2-2

Disassemble Top Cover Module 2-3

Disassemble Top Shielding 2-4

Disassemble Front Cover Module 2-4

Disassemble Main Board Module & Back Cover Module 2-6

Disassemble Color Wheel Module 2-8

Disassemble Engine Module 2-9

Disassemble DMD Board and DMD Chip 2-10

Disassemble Speaker Module(For X1260 Refresh/X1260 only)

2-11

Disassemble Fan Module 2-12

Disassemble Interrupt Switch Module 2-13

Disassemble Lamp Driver Module 2-14

Disassemble LVPS Module 2-15

Disassemble Bottom Cover Module 2-16

Rod Adjustment 2-17

Re-write Lamp Usage Hour 2-18

Assemble Bottom Cover Module 2-19

X1160 Series/X1260 Series/X1160Z Series/X1260K Refresh Condential

Assemble LVPS Module 2-20

Assemble Lamp Driver Module 2-21

Assemble Interrupt Switch Module 2-22

Assemble Fan Module 2-23

Assemble Speaker Module(For X1260 Refresh/X1260 only)

2-24

Assemble DMD Board and DMD Chip 2-25

Assemble Engine Module 2-26

Assemble Color Wheel Module 2-27

Assemble Main Board Module & Back Cover Module 2-28

Assemble Front Cover Module 2-30

Assemble Top Shielding 2-31

Assemble Top Cover Module 2-32

Assemble Lamp Module 2-33

Chapter 3 Troubleshooting

LED Lighting Message 3-1

Main Procedure 3-2

Beep Sound 3-3

Chapter 4 Function Test & Alignment Procedure

Test Equipment Needed 4-1

Service Mode 4-1

OSD Reset 4-1

Test Condition 4-2

Test Inspection Procedure 4-3

PC Mode 4-3

Calibration 4-7

Video Performance 4-9

X1160 Series/X1260 Series/X1160Z Series/X1260K Refresh Condential

Optical Performance Measure 4-11

Other 4-12

Chapter 5 Firmware Upgrade

Equipment Needed 5-1

DLP Composer Lite Setup Procedure 5-2

USB Driver Upgrade Procedure 5-4

Firmware Upgrade Procedure 5-5

Waveform Download 5-8

Chapter 6 EDID Upgrade

EDID Introduction 6-1

Equipment Needed 6-2

Setup Procedure 6-3

EDID Key-In Procedure 6-4

Default Language Reset 6-5

Appendix A

Exploaded Overview

Appendix B

  SerialNumberSystemDenition    XXIV

PCBACodeDenition     XXV

Appendix C

RS232 function command summary table I

X1160 Series/X1260 Series/X1160Z Series/X1260K Refresh Condential 1-1

Chapter 1

Introduction

1-1 Highlight

No Item Description

1Dimensions (LxWxH) - 267 mm x 187 mm x 80 mm

2Weight - <5 lbs

3Tilt Angle

- 7 degree with elevator mechanism

(for X1160/X1260/ X1160Z)

- 3 degree with elevator mechanism

(for X1160 refresh /X1260 refresh/X1160Z refresh/X1260K

refresh)

4Power Supply

- Universal AC 100 – 240 V ~ 50-60 Hz with PFC input

- 160W for Osram E20.6 Lamp @ normal operation

(for x1160 series/x1260 series/x1160z series)

- 180W for Osram E20.6 Lamp @ normal operation

(only for x1260k refresh)

- Variant FAN speed control (Depends on temperature

variance)

5Keystone correction - +/- 40 degree (80 degree)

6Cooling system

- Advanced Air Flow

- One fan with system acoustic noise level 36 dB(A) (typical)

- Temperature control circuits with adaptive fan rotational

speeds

- Maximum touch temperature follow UL60950-1

7 Brightness

Engineering Spec:

- 1700 ANSI Lumens (Typical) (for X1160/X1260/X1160Z)

- 1445 ANSI Lumens (Minimum) (for X1160/X1260/X1160Z)

- 1800 ANSI Lumens (Typical)

( for X1160 refresh/X1260 refresh/X1160Z refresh/X1260K

refresh)

- 1600 ANSI Lumens (Minimum)

(for X1160 refresh /X1260 refresh/X1160Z refresh/X1260K

refresh)

Marketing Spec:

- 2000 ANSI Lumens

X1160 Series/X1260 Series/X1160Z Series/X1260K Refresh Condential 1-2

No Item Description

8Contrast

Engineering Spec:

- 1500 : 1 Full White and Black (Minimum; Full power mode)

(for X1160/X1260/X1160Z)

- 1800 : 1 Full White and Black (Typical; Full power mode)

(for X1160/X1260/X1160Z)

- 1400 : 1 Full White and Black (Minimum; Full power mode)

(for X1160 refresh/X1260 refresh/X1160Z refresh)

- 1800 : 1 Full White and Black (Typical; Full power mode)

(for X1160 refresh/X1260 refresh/X1160Z refresh)

- 400 : 1 Full White and Black (Minimum; Full power mode)

- 600 : 1 Full White and Black (Typical; Full power mode)

(only for X1260K refresh)

Marketing Spec:

- 2000:1

9 Uniformity

Engineering Spec:

- 65% Japan standard (Minimum; Full power mode)

- 80% Japan standard (Typical; Full power mode)

Marketing Spec:

- 85%

10 Throw ratio

- 1.95:1 distance/width @60”(For X1160 refresh /X1160)

- 1.95 – 2.15:1 distance/width @60” (For X1260 refresh /

X1260/X1160Z/X1160Z refresh/X1260K refresh)

11 Lamp door protection - Lamp Power Supply shut off automatically when lamp

cover open

12 Projection lens

- F# 2.41 ,f = 21.79mm, Fix lens (For X1160 refresh /X1160)

- F# 2.41~2.55, f = 21.79~23.99 mm, 1.10X Mechanical

Zoom Lens (For X1260 refresh/X1260/X1160Z/X1160Z

refresh/X1260K refresh)

13 Lamp life - 3500 hours min, 50% survival rate

14 System controller - TI DDP2230

15 Terminal

For X1160 refresh/X1160

- One D-sub VGA input

- One Composite input

- One S-Video input(4 pin Mini din)

- One USB port (Type B Female)

For X1260 refresh/X1260/X1260K refresh

- One D-sub VGA input

- One D-sub VGA output

- One Composite input

- One S-Video input(4 pin Mini din)

- One audio input (2.5m phone jack)

- One USB port (Type B Female)

- One RS-232 (3 pin Mini din)

X1160 Series/X1260 Series/X1160Z Series/X1260K Refresh Condential 1-3

No Item Description

16 Number of active dots

- Number of active dots : 800(H) x 600(V) (for X1160/

X1160 refresh/1160Z/X1160Z refresh)

- Number of active dots : 1024(H) x 768(V) (for

X1260/X1260 refresh/X1260K refresh)

17 Input signal spec.

- Hsync Frequency 31 ~ 69 kHz (for X1160 refresh/X1160/

X1160Z/X1160Z refresh)

- Hsync Frequency 31 ~ 80 kHz (for X1260 refresh/X1260K

refresh)

- Vsync Frequency 50 ~ 85 Hz

- Video Signal RGB (PC)

● Analog RGB 0.7Vp-p, 75 ohm, Separate TTL H,V Sync

● Analog RGB 1Vp-p, 75 ohm, Sync. On Green signal

● Analog RGB 0.7Vp-p, 75 ohm, Composite TTL Sync

- Video

● Composite video 1Vp-p,75 ohm

● S-video Luminance 0.714Vp-p, 75 ohm,Chrominance

0.286Vp-p, 75 ohm

● Component Video 1Vp-p, 75 ohm

18 TI DMD

- TI DMD 0.55” 12° 2xLVDS Type-X SVGA Digital Mirror

Device (for X1160/X1160 refresh/X1160Z/X1160Z refresh)

- TI DMD 0.55” 12° 2xLVDS Type-X XGA Digital Mirror De

vice (for X1260 refresh/X1260/X1260K refresh)

19 Video compatibility

- Standards :

● NTSC (3.58/4.43)

● PAL (B/D/G/H/I/M/N)

● SECAM (B/D/G/K/K1/L)

● HDTV - 480i, 576i, 480p, 576p, 720p, 1080i

20 Power consumption

- 225W Max

- Standby < 8W at AC 110V (for X1160/X1260/X1160Z)

- Standby < 5W at AC 110V

(for X1160 refresh/X1260 refresh/X1160Z refresh)

- 250W Max.

- Standby < 5W at AC 110V

(only for X1260K refresh)

21 Color wheel

- 6 segments (R90/Y28/G90/C28/W42/B82)

- 7200 rpm

- 9000 rpm @ CW 3X, PAL 50Hz

(for X1160 refresh/X1260 refresh/X1160Z refresh/X1260K

refresh)

22 Lamp

- 160 Watt OSRAM (for X1160 Series/X1260 Series/X1160Z

Series)

- 180 Watt OSRAM (only for X1260K refresh)

23 Temperature - Operating: 5°C -- 35°C

- Storage: -20°C -- 60°C

X1160 Series/X1260 Series/X1160Z Series/X1260K Refresh Condential 1-4

Compatibility Resolution V-Sync [Hz] H-Sync [KHz]

VGA

640x480 60 31.50

640x480 72 37.90

640x480 75 37.50

640x480 85 43.30

720x400 70 31.50

720x400 85 37.90

SVGA

800x600 56 35.10

800x600 60 37.90

800x600 72 48.10

800x600 75 46.90

800x600 85 53.70

832x624 75 49.70

XGA

1024x768 60 48.40

1024x768 70 56.50

1024x768 75 60.00

1024x768 85 68.70

SXGA

1152x864 70 63.80

1152x864 75 67.50

1280x1024 60 64.00

1152x864

(For X1260/X1260 re-

fresh/X1260K refresh)

85 77.10

1280x1024

(For X1260/X1260 re-

fresh/X1260K refresh)

72 77.00

1280x1024

(For X1260/X1260 re-

fresh/X1260K refresh)

75 80.00

QuadVGA

1280x960 60 60.00

1280x960

(For X1260/X1260 re-

fresh/X1260K refresh)

75 75.20

1-2 Compatible Mode

VGA Analog - PC Signal

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Proyector de Acer

Acer

Acer X1525C Manual de usuario

Acer

Acer 1080p Series Manual de usuario

Acer

Acer K520/H112/PH-X01 Series Manual de usuario

Acer

Acer S5201M Series Manual de usuario

Acer

Acer K330 Manual de usuario

Acer

Acer S1210 Series Manual de usuario

Acer

Acer P5260E Series Manual del sistema

Acer

Acer K750 Series Manual de usuario

Acer

Acer C250i Manual de usuario

Acer

Acer LK-W300 Series Manual de usuario

Acer

Acer 7763PA - PalmPro SVGA DLP Projector Manual de usuario

Acer

Acer P5281 Series Manual de usuario

Acer

Acer H7530 Series Manual de usuario

Acer

Acer V7850 Manual de usuario

Acer

Acer S1110 Series Manual de usuario

Acer

Acer P7270 Series Manual de usuario

Acer

Acer P1303W Series Manual de usuario

Acer

Acer S1270Hn Series Manual de usuario

Acer

Acer X111 Series Manual de usuario

Acer

Acer K138STi Series Manual de usuario

Acer

Acer H7532BD Manual de usuario

Acer

Acer PD321 Manual técnico

Acer

Acer F7200 Series Manual de usuario

Acer

Acer X1161 Series Manual de usuario

Manuales populares de Proyector de otras marcas

iEmmet

iEmmet MP-312 Manual de usuario

Epson

Epson VS400 Manual de usuario

Sony

Sony VPL-HS10 Marketing Specifications & Features Manual de usuario

Sony

Sony VPL-HW65ES Manual de servicio

Toshiba

Toshiba TLP-791U Manual de usuario

Philips

Philips LC1341 Guía de referencia

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manual de usuario

NEC

NEC NP600S EDU Manual de usuario

BenQ

BenQ SH753P Manual de usuario

Eiki

Eiki EK-623U series Manual de usuario

Epson

Epson PowerLite Pro Cinema 6020UB Manual de usuario

Epson

Epson PowerLite Home Cinema 705HD Manual de usuario

Christie

Christie LHD700 Manual de usuario

Navitar

Navitar FX Manual de usuario

InFocus

InFocus LitePro 560 Manual de usuario

Sony

Sony SRX-R815P Manual de usuario

Vivitar

Vivitar DP1500 X Manual de usuario

Asus

Asus ZenBeam Latte Manual de usuario
