Acer PL111 Manual de usuario

Changes may be made periodically to the information in this publication without obligation

to notify any person of such revision or changes. Such changes will be incorporated in new

editions of this manual or supplementary documents and publications. This company makes

no representations or warranties, either expressed or implied, with respect to the contents

hereof and specifically disclaims the implied warranties of merchantability or fitness for a

particular purpose.

Record the model number, serial number, purchase date, and place of purchase information in

the space provided below. The serial number and model number are recorded on the label

affixed to your projector. All correspondence concerning your unit should include the serial

number, model number, and purchase information.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in

any form or by any means, electronic, mechanical, photocopy, recording, or otherwise,

without the prior written permission of Acer Incorporated.

Model number :____________________________________

Serial number: _____________________________________

Purchase date: _____________________________________

Place of purchase: __________________________________

Acer is a registered trademark of Acer Incorporated. All other trademarks and registered

trademarks are the properties of their respective companies.

Downloaded From projector-manual.com Acer Manuals

FCC Notice

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in residential installation. This equipment generates, uses

and can radiate radio frequency energy and if not installed and used in

accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception,

detectable by turning the equipment in question off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

•Reorient or relocate the receiving antenna

•Increase the distance between the equipment and the receiver

•Connect the equipment to an outlet on a different circuit than

that which the receiver is connected to

•Or consult the dealer or an experienced radio/TV technician for

help.

This device complies with Part 15 of the FCC Rules. Operation is subject

to following two conditions:

1 This device may not cause harmful interference, and

2 This device must accept any interference that may cause undesired

operation.

Downloaded From projector-manual.com Acer Manuals

iii

Precautions

Safety Instructions

1 Check that the operating voltage of your unit is identical with the

voltage of your local power supply.

2 Should any liquid or solid object fall into the cabinet, unplug the

unit and have it checked by the qualified personnel before

operating it further.

3 Do not place the projector on an unstable stand or table.

4 Unplug the unit from the wall socket if it is not to be used for

several days.To disconnect the cord, pull it out by the plug. Never

pull the cord itself.

5 The wall socket should be near the unit and easily accessible.

6 Do not place the projector where the cord can be stepped on as

this may result in fraying or damage to the lead or the plug. Be

alert to tripping hazards.

7 Never look into the projector lens when the lamp is switched on as

the bright light can damage your eyes. Never let children look into

the lens when it is on.

8 Do not place your hand or objects near the ventilation holes. The

air coming out is hot.

9 Never open any covers on the projector except the lamp cover.

Dangerous electrical voltages inside the projector can cause severe

injury. Except as specifically directed in this Instruction Manual, do

not attempt to service this product yourself. Refer all servicing to

qualified service personnel.

10 Unplug the projector from the wall socket before cleaning. Use a

damp cloth for cleaning the projector housing. Do not use liquid

or aerosol cleaners.

11 Keep the plastic packing materials (from the projector, accessories

and optional parts) out of the reach of children as these bags may

result in death by suffocation. Be particularly careful around the

small children.

Downloaded From projector-manual.com Acer Manuals

Cautions: The projector is equipped with ventilation holes

(intake) and ventilation holes (exhaust). Do not block or place

anything near these slots, or internal heat build-up may occur,

causing picture degradation or damage to the projector.

Cautions: When you replace the projector lamp, never touch the

new bulb with your bare hands. The invisible residue left by the oil

on your hands may be shorten the bulb life. Use lintfree gloves or

finger cots are recommended.

Preventing Internal Heat Build-Up

After you turn off the power with the Power button, do not disconnect

the unit from the wall outlet while the cooling fan is still running.

Repacking

Save the original shipping carton and packing material; they will come

in handy if you ever to ship your unit. For maximum protection, repack

your unit as it was originally packed at the factory.

Downloaded From projector-manual.com Acer Manuals

Contents

Projector features and controls 1

Projector 1

Control panel 2

Remote controller 4

Getting the most out of your projector 6

Remote Controller 6

Auto Off Mode 6

Control Panel 6

Setup 7

Unpacking the Projector 7

Setting Up the Projector 9

Connecting to a Computer 10

Connecting to a Video Source 11

Using the Projector 12

Turning the Audio/Visual (A/V) Equipment On and Off 12

Turning the Projector On and Off 12

Focusing and Positioning the Screen Image 13

Operational Indicator (LED) 14

Projector control menus 15

Changing a Menu Setting 15

Menu Options 16

Input Menu 17

Picture Menu 17

Color Menu 19

Audio Menu 20

MISC Menu 21

Option Menu 22

Language Menu 24

Reset Menu 24

Other Related OSD Menus 25

Video Input Signal 25

Video Menu 25

Other OSD Menus 27

No Input Signal 28

Maintenance 29

Cleaning the Lens 29

Cleaning the Projector Housing 29

Cleaning the Air Filter 29

Replacing the Lamp 30

Technical specifications 32

Appendix A 34

Preset Signals 34

HDTV Preset Signals 35

Downloaded From projector-manual.com Acer Manuals

Projector features and controls

Projector

#Item #Item

1. Zoom ring 13. Control port

2. Focus ring 14. Computer IN (D-SUB) connector

3. Lens 15. Monitor OUT

4. Ventilation holes (intake) 16. S-Video input

5. Ventilation holes (exhaust) 17. Y connector

6. Adjuster button 18. Cb connector

7. Front IR remote controller

sensor

19. Cr connector

8. Speakers 20. Audio input jacks (L & R)

9. Control Panel including

Power button

21. Composite Video input jack

10. AC power socket 22. Lamp cover

11. Rear IR remote controller

sensor

23. Air filter

12. Security lock receptacle

Downloaded From projector-manual.com Acer Manuals

Control panel

LED

Button Function

Key Description

POWER Power LED indicator - indicates power to projector.

LAMP Lamp LED indicator - indicates lamp power.

Button Function

Turns the projector and lamp ON and OFF.

INPUT Manually selects an input source.

AUTO Automatically adjusts frequency and phase.

MENU Displays (or hides) the on-screen control menus.

(+) Increases the volume of the projector's speakers.

(-) Decreases the volume of the projector's speakers.

Downloaded From projector-manual.com Acer Manuals

Cursor Controller

()

It can be used as a navigation controller to navigate the

projector menus.

- Scrolls up through the menu choices.

- Scrolls down through the menu choices.

- Increases the value setting on the selected sub-menus,

or confirms a menu selection.

- Decreases the value setting on the selected sub-menus.

Button Function

Downloaded From projector-manual.com Acer Manuals

Remote controller

Button Function

Power Turns the projector and lamp ON and OFF.

Menu Displays (or hides) the on-screen display menus.

Scrolls up through the menu choices.

Scrolls down through the menu choices.

Increases the value setting on the selected sub-menus, or

confirms a menu selection.

Decreases the value setting on the selected sub-menus.

Auto Automatically adjusts frequency and phase.

Source Manually selects an input source.

Auto

Keystone

This model doesn't support this function.

Volume Adjusts the volume of the projector's speakers.

Zoom Digitally zooms the current image window.

Downloaded From projector-manual.com Acer Manuals

Note: Press the KEYSTONE button to select the trapezoidal

distortion. To adjust the trapezoidal distortion of the projection,

press the or button.

Cautions: When replacing batteries on the Remote Controller,

take the following precautions:

Do not recharge used batteries or expose batteries to fire or

water.

Replace batteries as soon as they run down. If the batteries leak,

wipe away the fluid with a soft cloth. If battery fluid gets on your

hands, wash them immediately. Remove the batteries if you will

not be using the remote controller for a long period of time.

Keystone Selects vertical trapezoidal distortion.

Mute Cuts off the sound temporarily.

Freeze Freezes the current graphics and video image on the

screen.

Blank Cuts off the screen temporarily.

Button Function

Downloaded From projector-manual.com Acer Manuals
