user manual BT Laser Mouse MODEL:MT1BF
Page 1
1 Introduction
1-1
Product Briefing
MT1BF is designed for using acer Picasso E/II/M tablet ke boards mouse with in
Bluetooth Wireless technolog and Li-ion rechargeable batter . The main proposal is
for mobilit and eas to carr with Android s stem tablet to build into one leather case.
Ke board is using a notebook scissors design.
1-2
Main Feature
Broadcom 20730, Bluetooth 3.0 compliant , class 2
The distance of RF data transfer can reach 10M.
Bluetooth technolog .
Alkaline batteryAAA*2.
ADNS-7530 laser sensor.
3 keys(L,M,R)+wheel.
One switch for power on/off.
A pairing button for pairing.
1 Blue LED for paring indicator, 1 Red LED for Low batter /paring.
user manual BT Laser Mouse MODEL:MT1BF
Page 2
1. Install the batteries(AAA x2), switch on the power. The Blue LED will flash in 1sec.
LED
Timing 500ms 500ms
2. Press the Pairing button(Gre ), the LED starts flashing in blue and red.
LED
…
Timing 500ms 500ms 500ms 500ms … 500ms 500ms
user manual BT Laser Mouse MODEL:MT1BF
Page 3
3. Switch on the Bluetooth function of Host
4. Move the cursor on the Bluetooth icon, press the right ke of the mouse
5. Click “Add a Bluetooth Device”, Choose ”Add a device”. The host will start searching the
Bluetooth device.
user manual BT Laser Mouse MODEL:MT1BF
Page 4
6. Searched “Acer Bluetooth Mouse”, then click.
The pairing process will be starting.
7. During the pairing process, the LED will be flashing in blue 5 times. The screen will show
Acer Bluetooth Mouse installed.
LED
Timing 100ms
100ms
100ms
100ms
100ms
100ms
100ms
100ms
100ms
100ms
8. Pairing Successfull
user manual BT Laser Mouse MODEL:MT1BF
Page 5
FCC ID:O62MT1BF
FCC Statement:
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
●
Reorient or relocate the receiving antenna.
●
Increase the separation between the equipment and receiver.
●
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
●
Consult the dealer or an experienced radio/TV technician for help.
user manual BT Laser Mouse MODEL:MT1BF
Page 6
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This device and its antenna(s) must not be co-located or operation in conjunction with any
other antenna or transmitter.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
user manual BT Laser Mouse MODEL:MT1BF
Page 7
IC:4356A-MT1BF
IC Statement:
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B conforme á la norme NMB-003 du Canada.
This device complies with Industry Canada license-exempt RSS standard(s). Operation
is subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de
brouilla e, et (2) l'utilisateur de l'appareil doit accepter tout brouilla e radioélectrique subi, même si le
brouilla e est susceptible d'en compromettre le fonctionnement.
This device and its antenna(s) must not be co-located or operation in conjunction with any
other antenna or transmitter.
Cet appareil et son antenne (s) ne doit pas être co-localisés ou fonctionnement en association avec une
autre antenne ou transmetteur.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
Declaración de exposición a la radiación de Canada:
Este equipo cumple con los límites de exposición a la radiación de la IC establecidos para un ambiente no
controlado.
Este equipo se debe instalar y operar con una distancia mínima de 20 cm entre el radiador y su cuerpo.
user manual BT Laser Mouse MODEL:MT1BF
Page 8
Anatel Statement:
This equipment operates as secondary functionality, that is not entitled to protection from
harmful interference, even for stations of the same type, and cannot cause interference to
systems operating as primary functionality.
