Acer Power SP Manual de usuario
Power SP
Service Guide
PRINTED IN TAIWAN
P/N: VD.PSPVF.001
Service guide files and updates are available
on the AIPG/CSD web; for more information,
please refer to http://csd.acer.com.tw
II
Revision History
Please refer to the table below for the updates made on Acer Power SP service guide.
Date Chapter Updates
III
Copyright
Copyright © 2003 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in
any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without
the prior written permission of Acer Incorporated.
Disclaimer
The information in this guide is subject to change without notice.
Acer Incorporated makes no representations or warranties, either expressed or implied, with respect to the
contents hereof and specifically disclaims any warranties of merchantability or fitness for any particular
purpose. Any Acer Incorporated software described in this manual is sold or licensed "as is". Should the
programs prove defective following their purchase, the buyer (and not Acer Incorporated, its distributor, or its
dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential
damages resulting from any defect in the software.
Acer is a registered trademark of Acer Corporation.
Intel is a registered trademark of Intel Corporation.
Pentium and Pentium II/III are trademarks of Intel Corporation.
Other brand and product names are trademarks and/or registered trademarks of their respective holders.
IV
Conventions
The following conventions are used in this manual:
Screen messages Denotes actual messages that appear
on screen.
NOTE Gives bits and pieces of additional
information related to the current
topic.
WARNING Alerts you to any damage that might
result from doing or not doing specific
actions.
CAUTION Gives precautionary measures to
avoid possible hardware or software
problems.
IMPORTANT Reminds you to do specific actions
relevant to the accomplishment of
procedures.
V
Preface
Before using this information and the product it supports, please read the following general information.
1. This Service Guide provides you with all technical information relating to the BASIC CONFIGURATION
decided for Acer's "global" product offering. To better fit local market requirements and enhance product
competitiveness, your regional office MAY have decided to extend the functionality of a machine (e.g.
add-on card, modem, or extra memory capability). These LOCALIZED FEATURES will NOT be covered
in this generic service guide. In such cases, please contact your regional offices or the responsible
personnel/channel to provide you with further technical details.
2. Please note WHEN ORDERING FRU PARTS, that you should check the most up-to-date information
available on your regional web or channel. If, for whatever reason, a part number change is made, it will
not be noted in the printed Service Guide. For ACER-AUTHORIZED SERVICE PROVIDERS, your Acer
office may have a DIFFERENT part number code to those given in the FRU list of this printed Service
Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and
service of customer machines.
VI
Chapter 1 1
Overview
Acer Power SP supports Intel Pentium 4 Northwood based micro-ATX, IBM PC/AT compatible system with
PCI/AGP bus.
NOTE: CPU frequency: up to 2.6GHz.
System Specifications
Chapter 1
2Chapter 1
Features & Specifications
CPU
TIntel Pentium 4 Willamette/Northwood, Celeron
TFront Side Bus: 400MHz
TFrequency: up to 2.6GHz
Chipset
TBrookdale-GL
TICH: Intel ICH4.
TSST 49LF002 FWH (2MB)
Memory
TTwo DIMM sockets
TDDR 200/266
TCapacity: 128MB ~ 1GB (please refer to the AVL list for compatibility).
BIOS
TWinbond 49V002FAP FWH (2MB)
TAward BIOS code
TACPI supported, default S3
Super I/O
TWinbond W83627HF LPC super I/O with Hardware monitor supported
RTC
TICH4
IDE
TDual PCI Bus master enhanced IDE
TUltra DMA 33/66/100 supported
FDD
T1.44/2.88 MB FDD
Graphics
TOn-die VGA
Audio
TOn-board (RealTek ALC201A AC’97 CODEC)
LAN
TRealTek RTL8100BL integrated LAN with support WOL
USB
TUSB 2.0 Host Controller
Chapter 1 3
Expansion slots
T3 PCI slot (PCI 2.2)
Board size
TMicro-ATX, 4 Layers
Industrial Standard
TWindows Hardware Compatibility Labs
TACPI 1.0b
TPCI 2.2
TPC2001 compliance
TWired for Management 2.0
TSuspend to RAM
4Chapter 1
Front Panel
The computer’s front panel consists of the following:
Label Description
1 Optical Drive‘
2 Floppy Drive
3 Power Button
4 USB Ports
5 Microphone Jack
6 Speaker/Headphone Jack
1
2
3
4
5
6
