Acer Aspire M3710 Manual de usuario

Aspire M3710

Aspire M5711

Aspire M7711

Service Guide

Service guide files and updates are

available on the AIPG/CSD web; for

more information please refer to

http://csd.acer.com.tw

PRINTED IN TAIWAN

Revision History

Please refer to the table below for the updates made on Aspire M3710/Aspire

M5711/ Aspire M7711 service guide.

Date Chapter Updates

III

publication may be reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language or computer language, in any form or

by any means, electronic, mechanical, magnetic, optical, chemical, manual or

otherwise, without the prior written permission of Acer Incorporated.

Disclaimer

The information in this guide is subject to change without notice.

Acer Incorporated makes no representations or warranties, either expressed

or implied, with respect to the contents hereof and specifically disclaims any

warranties of merchantability or fitness for any particular purpose. Any Acer

Incorporated software described in this manual is sold or licensed "as is".

Should the programs prove defective following their purchase, the buyer (and

not Acer Incorporated, its distributor, or its dealer) assumes the entire cost of

all necessary servicing, repair, and any incidental or consequential damages

resulting from any defect in the software.

Acer is a registered trademark of Acer Corporation.

Intel is a registered trademark of Intel Corporation.

Pentium 4 and Celeron are trademarks of Intel Corporation.

Other brand and product names are trademarks and/or registered trademarks

of their respective holders.

Conventions

The following conventions are used in this manual:

SCREEN

MESSAGES

Denotes actual messages that appear on screen.

NOTE Gives bits and pieces of additional information

related to the current topic.

WARNING Alerts you to any damage that might result from

doing or not doing specific actions.

CAUTION Gives precautionary measures to avoid possible

hardware or software problems.

IMPORTANT Remind

ou to do s

ecific actions relevant to the

accomplishment of procedures.

Preface

Before using this information and the product it supports, please read the

following general information.

1. This Service Guide provides you with all technical information relating to

the BASIC CONFIGURATION decided for Acer's "global" product offering.

To better fit local market requirements and enhance product

competitiveness, your regional office MAY have decided to extend the

functionality of a machine (e.g. add-on card, modem, or extra memory

capability). These LOCALIZED FEATURES will NOT be covered in this

generic service guide. In such cases, please contact your regional offices or

the responsible personnel/channel to provide you with further technical

details.

2. Please note WHEN ORDERING FRU PARTS, that you should check the

most up-to-date information available on your regional web or channel. If,

for whatever reason, a part number change is made, it will not be noted in

the printed Service Guide. For ACER-AUTHORIZED SERVICE

PROVIDERS, your Acer office may have a DIFFERENT part number code

to those given in the FRU list of this printed Service Guide. You MUST use

the list provided by your regional Acer office to order FRU parts for repair

and service of customer machines.

Cha

ter 1 S

stem S

ecifications 1

Features……………………………………………………………………………………………... 1

Main board Placement…………………………………………………….……..……………..6

Block Diagram…………………………………………………………..………………...………..8

Aspire M3710 Front Panel.........................……………….……………..…….………..…..……....9

Aspire M3710 Rear Panel………………………………………..…………………..…………………10

Aspire M5711 Front Panel.........................……………….……………..…….………..…..……....11

Aspire M5711 Rear Panel………………………………………..…………………..…………………12

Aspire M7711 Front Panel.........................……………….……………..…….………..…..……....13

Aspire M7711 Rear Panel………………………………………..…………………..…………………14

Hardware Specifications and Configurations………………….…….……..15

Power Management Function (ACPI support function)…………………………..…...20

Chapter 2 System Utilities 21

Entering Setup…………………………………………………………………………..22

Product Information………………………………………………………..24

Standard CMOS Setup………………………….…….……………………………………25

Advanced BIOS Features………………………………………..……………………26

Advanced Chipset Setup………………………...…………………………………………..27

Integrated Peripherals…………………………...…………………………………………..28

Power Management…………………………………………………………30

PC Health Status……………………………………………………………...31

Frequency/Voltage Control……………..………………………….…….32

BIOS Security Features…………..…………………………….…….33

Load Default Settings………………………………………………..……. 34

Save & Exit Setup………………………………………………….…………35

Exit Without Saving………………………………………………….……..36

Chapter 3 Machine Disassembly and Replacement 37

General Information………………………………………………………. 38

Disassembly Procedure……………………………………………………39

VeritonM670G/M670/S670G/S670 Disassembly Procedure……………40

Chapter 4 Troubleshooting 56

Chapter 5 Jumper and Connector Information 57

Jumper Setting…………………………………………………..………………..57

Chapter 6 FRU (Field Replaceable Unit) List 58

Exploded Diagram………………………………………………………….59

System Specifications

Features

Operating System

Microsoft Windows Vista (Home Basic, Home Premium, Business)

Processor

Socket Type: Intel® Socket T LGA 775 pin

Processor Type:

Intel Pentium Dual Core / Core 2 Duo / Core2 Quad (up to 95W CPUs

FSB 1066/1333 MHz CPUs

Chipset

NV MCP7A-O (Aspire M3710) / MCP7A-D (Aspire M7711/M5711)

PCB

Form Factor: Micro ATX

Dimension/Layer: 244mm x244mm

Memory

Memory Type: DDR2 800

Support single channel 64 bit mode with maximum memory size up to 8GB

Support un-buffered DIMM (NV MCP7A-O/ MCP7A-D )

DIMM Slot: 4

Memory Max: 512MB to 8GB DDR2 memory technologies

Capacity: Up to 2GB per DIMM with maximum memory size up to 8GB

PCI

PCI Express Slot Type: x16

PCI Express x16 Slot Quantity: 1

PCI Express Slot Type: x1

PCI Express x1 Slot Quantity: 1

PCI Slot Type: PCI 2.3 5V slots

PCI Slot Quantity: 2

FDD

Slot Quantity: 1

Design Criteria:

Should support 1.44MB/3 mode 3.5” Devices

SATA

Slot Type: SATA slot

Slot Quantity: 6

Storage Type support:

HDD/CD-ROM/CD-RW/DVD-ROM/DVD-RW/DVD+RW/DVD

Dual/DVD SuperMultiPlus/Blu-Ray ODD

Audio

Audio Type: HD audio codec

Audio Channel: 7.1 channel

Audio Controller /Codec: ALC888S HD codec 7.1

Connectors support:

Rear 6 jack follow HD audio definition, example as below

Audio jacks color coding: should meet Microsoft Windows Logo

Program Device Requirements: Audio-0002

1 S/PDIF-out header (1*4)

1 front panel audio header (2*5)

Add HD de-pop CKT (the attachment is the reference, please propose

your solution)

S/N ratio: 90 dB at rear output jack

LAN

MAC Controller: (NV MCP7A)

Should be worked under 10/100/1000Mbs environment

PHY: Realtek 8211CL Gigabit Ethernet Phy.

USB

Controller Type: (NV MCP7A)

Ports Quantity: 10

4 back panel ports

On-board: 3 2*5 headers

4 ports for front daughter board

4 ports for rear I/O

2 ports for internal card reader.

Connector Pin: standard Intel FPIO pin definition

Data transfer rate support:

USB 2.0/1.1

1394

Controller: VIA 1394a controller

Connector Quantity: 2

1 rear 6pin IEEE1394 port

1 2x5pin onboard jumper

BIOS

BIOS Type: Phoenix Award or AMI Kernel with Acer skin

Size: 4Mb

Note:

Boot ROM should be included (PXE function should be built in with

default and RPL function is optional by service BIOS)

BIOS shall auto detect FDD to avoid checksum error when boot

I/O Connector

Controller: Super I/O ITE 8718/JX (F stepping or after; must full support

Intel platform)

Rear I/O Connector

1 PS/2 Keyboard port,

1 PS/2 Mouse port,

1 COM port

1 HDMI port (Aspire M3710 series only),

1 D-Sub port, (Aspire M3710 series only) 1 RJ45 LAN port,

1 IEEE 1394 port (6 pin) (Aspire sku only)

4 USB ports

7.1 channel phone jack (6 audio jacks)

On-board connectors

1 CPU socket

4 DDR-2 memory sockets

1 PCI Express x16 slot

1 PCI Express x 1 slot

2 PCI slots

1 FDD slot

6 SATA connectors

3 2*5 pin Intel FPIO specification USB pin connectors (follow Intel

FPIO standard Specification)

1 2*5 pin IEEE1394 jumper (reserve header on all SKU)

1 2*5 pin Intel FPIO spec. Microphone In/ Headphone Out pin

connectors

1 serial port 2*5 pin connector

1 1*4 S/PDIF out header

1 4 pin CPU Fan connector

1 3 pin System FAN connector with linear circuit

1 24pin + 4pin ATX interface PS3/PS2 SPS connector
