NANONANO | OZONE GENERATOR| OZONE GENERATOR
Operator’s Manual
CONTACT
Address
10712-181 ST NW
Edmonton, Alberta, Canada
T5S1K8
Phone & Email
Ph: 780-486-3761
Toll Free: 1-800-488-8565
2
TABLE OF CONTENTS
Section 1 General Information
1A. Description
1B.Specications
1C. Accessories
1C.iOzoneGeneration
1C.ii Required Accessories
Section 2 Installation
2A.Location
2B.Electrical
2C. Plumbing
2D.GasConnections
2E. Remote Control
Section 3 Operation
3A.ControlPanelOverview
3B.SystemStart-Up
3C.SystemShutDown
3D.StandardOperatingProcedures
Section 4 Maintenance and Service
4A.PreventativeMaintenance
4B. Troubleshooting
Section 5 Ozone Overview and Safety Procedures
5A.OzoneUseandTechnologyOverview
5A.iRelativeStrengthofOzone
5A.iiMicro-FlocculationandOxidation
5B.GeneralSafetyInformation
5B.i Ozone Properties
5B.iiOzoneUses
4
5
6
6
7
7
20
20
20
20
21
21
21
10
10
10
10
11
11
13
13
15
16
16
17
17
17
3
TABLE OF CONTENTS
5C.Hazards
5C.iHealthHazardsDetection
5C.iiHealthHazardsEffectsonHumans
5C.iiiElectricalHazards
5C.ivFireHazards
5C.vChemicalAction
5D.PrecautionsforSafeHandlingandUse
5D.iOzoneMonitors
5D.iiVentilation
5D.iii Emergency Procedure
5D.ivRespirationProtection
5D.vEducationandTraining
5E.SystemOperationsandMaintenance
5E.iSafetyPrecautionsandEquipment
5E.iiMaintenanceRequirements
5F.MonitoringEquipmentandlocation
5G.FirstAidProcedures
5G.iGeneralInformation
5G.iiInhalation
5G.iiiEyeContact
5G.ivPrecautions
5G.vEmergencyInformationForm
Section 6 Ozone Limited Warranty
Section 7 Dimensions
22
22
22
23
23
23
27
27
27
27
28
28
24
24
24
24
24
25
26
26
26
26
29
31
4
SECTION 1 GENERAL INFORMATION
IMPORTANT SAFETY INSTRUCTIONS - PLEASE READ CAREFULLY
BELOW AND FOLLOW ALL INSTRUCTIONS
Read this manual completely before the operation of the NANO
ozone generator
WARNING: High voltage is present inside the enclosure
USE EXTREME CAUTION
• Operate the NANO with safe access to electrical power
• Connect to a GFCI type receptacle
• Follow all applicable electrical codes
• Do not bury chord
WARNING: To reduce the risk of electrical shock, please ensure to
replace the damaged electrical chord immediately
ELECTRICAL SHOCK HAZARD: Turn OFF all the power switches
and disconnect the power chord from the power source receptacle
before performing any service work. Failure to do so could result
in serious injury or death
5
SECTION 1 GENERAL INFORMATION
1A. Description
TheNANOisanozonegeneratorthatproduces15gramsofozone
perhourwithanozoneconcentrationofupto10%byweightoras
speciedintheperformancetestreportsuppliedwitheveryunit.
TheNANOozonegeneratorisdesignedtoproduceozoneforavari-
etyofapplicationssuchas:
• WaterDisinfectionforBottledWaterPlants,Medical&Pharma-
ceuticalFacilities,SwimmingPools,etc.
• IndustrialProcesses,ChemicalProductionandLaboratories,Elec-
tronicProduction,Mining
• AquaticLifeSupportSystemsforMarineMammals,FishHatcher
ies,LargeAquarium
• FoodProcessing,FoodProcessingFacilitiesDisinfection,Food
Preservation
• SoilRemediation,GroundWaterRemediation
• WineriesFacilitiesDisinfection,BarrelDisinfection
• CoolingTowersWaterTreatment,TechnologicalProcessesWater
Treatment
• PotableWaterDisinfectionforSmallCommunities
• WasteWaterTreatmentforIndustrialPlants,TechnologicalPro
ductionProcesses,CommercialFacilitiesWasteWaterTreatment,
DangerousChemicalandBacteriaTreatment,etc.
6
1B. Specications
Model NANO
Ozone Production 15g/h
Nominal Working Pressure (PSIG) 20 PSIG
Concentration (% by weight O3) 5%-10%
Power Requirements
120V ~ +/- 3% 50/60Hz, Single Phase 5.0A
220V ~ +/- 3% 50/60Hz, Single Phase 3.5A
Maximum Power Consumption
1C. Accessories
TheNANOcouldbeusedwithseveralaccessoriesandsafetydevices
toensurealongservicelifeoftheozonegenerator
1C.i Ozone Generation
• AirCompressor:Theaircompressorpumpsambientpressurizedair
intotheoxygengenerator/concentrator
• OxygenGenerator/Concentrator:separatesOxygenfromNitrogen
andsuppliesitdirectlyintotheozonegeneratingcellinsidethe
ozonegenerator
SECTION 1 GENERAL INFORMATION
7
SECTION 1 GENERAL INFORMATION
1C.i Ozone Generation
OzoneGeneratingCelldesignisbasedonproprietaryMicrouidic
Platformtechnology,constructedfromozoneresistantmaterials,and
offersextremelyhighperformanceandreliability.Theozonecellisde-
signedtobeabsolutelymaintenanceandservice-free,theanticipated
servicelifeis15-20years.
1C.ii Required Equipment and Accessories
• Oxygen Generator/Concentrator:Theoxygengeneratorusesa
PSA(pressureswingabsorption)molecularsievebedtoremove
dirt,moisture,nitrogenandothertracegases,producingoxygen
atgreaterthan90%purityandlessthan-60Cdewpoint.Theair
compressorpumpsambientairintotheoxygengeneratorinputand
thentheoxygengeneratoroutputsoxygen(O2)feedgasintothe
ozonegeneratorcellandenablestheozonegeneratortoproduce
ozoneeffectivelyatupto14%byweightozoneconcentration.In
ourexperience,oxygengeneratorsmanufacturedbyAirSepwork
verywellwithAbsoluteOzone®ozonegenerators.
• Oxygen Filter: To protect the Absolute Ozone®generatorfrom
sieveparticlesincaseofoxygengeneratorfailureormalfunction,
werecommendinstallinganoxygenlteraftertheoxygengenera-
torandbeforetheozonegenerator
8
1C.ii Required Equipment and Accessories
• Ozone Flow Control Valve (Flow Meter):Thisshouldbeinstalled
downstreamfrom(after)theozonegeneratortomaintainworking
pressureacrosstheozonecellasspecied20PSIGfortheNANO
foroptimalperformance
• ALD 2000 Flood Prevention Device:Werecommendinstalling
anALD2000witheveryozonesystemtreatingwatertoprevent
waterfreombackingupintotheozonegeneratoranddamaging
it-Non-return(checkvalves)donotprovide100%waterooding
protectiontotheozonegenerator-WE DO NOT RECOMMEND
installingtheozonegeneratorWITHOUT theALD2000device
whentreatingliquids
SECTION 1 GENERAL INFORMATION
9
SECTION 1 GENERAL INFORMATION
1C.ii Required Equipment and Accessories Continued
Ozone Injector for Water Treatment Applications (Venturi):Inletwa-
terowsthroughthepumpandthroughtheozoneinjector,creatinga
vacuumthatpullsozonegasfromtheozonegeneratorandinjectsthe
ozonegasintothewaterow.Theinjectorshouldbesizedtodissolve
aminimumof90%oftheozonegasintothewaterowcontinuously.
Ozone De-gas Chamber and Off-Gas Device: Ozoneen-richedwa-
terfromtheozoneinjectorowsintothede-gaschamberwherethe
counter-currentdesignforcesanyundissolvedozonegasthroughthe
oatvalve-protectedtopventtotheozonedestructor.
Ozone Destructor: Undissolvedozonegaspassesthroughtheheated
catalyticozonedestructorthatismadeupofnon-consumablemanga-
nesedioxide(heat-protectedfrommoisturefouling).Themanganese
dioxideandheatofferredundantozonedestructcapabilities.
10
SECTION 2 INSTALLATION
2A. Location
TheNANOozonegeneratorsaredesignedtobeinstalledonthewall.
Allowforaccesstoprotectedelectricalpowerandrequiredgascon-
nectionsandcoolingairtotheOzoneGenerator.DONOTOBSTRUCT
COOLINGAIRVENTSONTHEOZONEGENERATOR.
TheunitcanbeinstalledindoorsoroutdoorsIFprotectedfrom
weatherelements.Ambientworkingtemperaturefrom-10Cto+30C
2B. Electrical
MainPowerSupplyCircuit:TheNANOissuppliedwitha3-5feet
powercord.Connectthepowercordtoastandardgrounded15Amp
(10AmpInternational)powersource,accordingtoalocalelectrical
code only.
2C. Plumbing
WheninjectingOzoneintothewater,allmeasuresshouldbetaken
toprotecttheGeneratorCellfromwaterexposure,whichmaycause
internalcelldamage.Asmalltankwith/oranautomaticwaterdrain
system is recommended.
