Ability Research AbilitySpeaker Manual
AbilitySpeaker™
Private Speaker System
User Manual and Instructions
Ability Research, Inc.
Minnetonka, MN
What is the AbilitySpeaker?
The AbilitySpeaker system allows auditory scanning users to hear “prompts” on a
private pillow speaker and play the messages publicly on a separate loudspeaker. The
system includes both the pillow speaker and the separate loudspeaker. It is intended to
be used with the ActionVoice-2A (model ACTV-2A).
NOTEWhen the AbilitySpeaker is connected to the ActionVoice, the ActionVoice’s
built-in speaker is disabled.
NOTEThe Ability Speaker automatically uses Output #2 to switch between the pillow
speaker and AbilitySpeaker for prompts and messages. Therefore, Output #2 features
are disabled when the AbilitySpeaker is being used.
Unpacking the AbilitySpeaker
Inspect the shipping box for any obvious signs of physical damage. If there are obvious
signs of damage, contact the shipping company for instructions. Carefully remove the
AbilitySpeaker from its box and plastic shipping bag. Check it for any obvious signs of
damage. Contact the shipping company or Ability Research immediately if there is
damage.
Make sure the following are present: ( Figure 1 )
• The AbilitySpeaker (small case with built-in speaker and black cord)
• The pillow speaker (thin case with light colored cord)
Ability Speaker Instructions 1
NOTE Be Sure to read and save this intruction booklet.
Connecting the AbilitySpeaker to the ActionVoice-2A
****** IMPORTANT *****
NOTEThe AbilitySpeaker MUST BE USED WITH an ActionVoice-2A (Model number
ACTV-2A). The label on the bottom of the ActionVoice shows the model number. If
you have any other model or if you are not sure, contact Ability Research for more
information or about having your unit upgraded to that model.
Connect the AbilitySpeaker to the ActionVoice-2A as described below and shown in
Figure 1.
1.Connect the plug labeled “Connect to Speaker/Phones” to the Speaker/Phones
jack on the ActionVoice.
2.Connect the plug labeled “To Switch Closure Output 2” to the Switch Closure
Output 2 jack on the ActionVoice.
3. Plug the pillow speaker into the AbilitySpeaker.
NOTEHandle the connectors and not the cords when connecting or disconneting. Never
pull on the cords or use them as handles.
2Ability Speaker Instructions
Connect to
ActionVoice "Switch
Closure Output 2"
Jack
Figure 1. Connecting The AbilitySpeaker
Connect to
ActionVoice
"Speaker/Phones"
Jack
Plug Pillow Speaker
in Here
Speaker/Phones Switch
Closure
Output 2
Switch
Closure
Output 1
Pillow
Speaker
Ability Speaker Instructions 3
4Ability Speaker Instructions
Setting the ActionVoice -2A to use the Ability Speaker
Note: The Ability Speaker is for use with Auditory Scanning. Please refer to the
ActionVoice instruction manual for information on programming and recording/playing
prompts and messages while in Auditory Mode.
Here is a quick summary diagram of setup modes used with the Ability Speaker:
ActionVoice Ability
Scanning
Input Auditory
Mode
Keypad
Input
Option 2
Use the following steps to set up the AbilitySpeaker system:
STEP 1: First, enter Setup Mode by pressing and HOLDING the “Record/Setup” key
on the ActionVoice for at least 2 seconds. (The Setup light on the key will light steadily
when you are in setup mode.)
Ability Speaker Instructions 5
STEP 2: Set Option 2. Make sure Scanning and Auditory Mode are also set. (When
Auditory Mode is set, messages and prompts will play through BOTH the pillow
speaker and the AbilitySpeaker, while ONLY messages will play through the
AbilitySpeaker.)
STEP 3: To get out of setup mode, press the “Record/Setup” key again. The
AbilitySpeaker system is now ready for use.
Refer to the ActionVoice manual for more details on programming and setup
mode.
Operation of the AbilitySpeaker
Once the ActionVoice is set up, recorded with messages and prompts and the
AbilitySpeaker and pillow speaker are connected, the system is ready for use.
Message and prompt loudness are adjusted by the volume control on the bottom of the
ActionVoice. This is the primary way to control the public (message) volume level.
Prompt loudness is then separately set using the volume control built into the pillow
speaker.
HINTIt is best to set the ActionVoice (Message) volume control first. This sets the
maximum loudess for prompts. Then use the pillow speaker volume control to reduce
level as necessary for comfort of the user.
TIPThe pillow speaker maximum volume level is less than the AbilitySpeaker. It is
6Ability Speaker Instructions
intended that the speaker be placed near enough to the user’s ear to easily hear prompts
while keeping the volume level low enough to avoid others hearing or being distracted
by the prompts.
NOTEOutput 2 functions for the ActionVoice are not available when the AbilitySpeaker
is plugged in and Option 2 is enabled.
Ability Speaker Instructions 7
Location and Mounting of the AbilitySpeaker and Pillow
Speaker
The pillow speaker should be located conveniently for the user to hear quitely played
prompts. It should be mounted (using velcro™ or a similar product) to the back of the
enclosure rather than using the cord to suspend it. It should be located so as to avoid
being bumped by the user, headgear, supports, etc.
The AbilitySpeaker enclosure should be located so that listeners can hear the messages
well when played.
Both speakers and the ActionVoice should be located to avoid tangled or strained
cords. Cords etc should be located to avoid pulling one of the speakers or the
ActionVoice off the tray or table when the user or others move. The idea is to keep
them out of the way as much as possible.
Excess cord length should be taped out of the way to avoid tangling etc.
Velcro or dual-lock can be used to secure the enclosures or the ActionVoice in place.
APPENDIX A. AbilitySpeaker Specifications*
Built-in Speaker 8 ohm
Pillow speaker 8 ohm with built-in volume control
Compatibility ActionVoice model ACTV-2A only
Size 3.8" x 2.4" x 1.1"
8APPENDICES
Weight (with pillow speaker) 4 to 5 Oz
Operating Temperature 50oF to 90oF
*Subject to change without notice
APPENDIX B. In Case of Difficulty
THERE ARE NO USER-SERVICEABLE PARTS INSIDE DO NOT OPEN THE
CASE OR ATTEMPT SERVICE.
CONTACT ABILITY RESEARCH, INC FOR SERVICE AT (612) 939-0121
s1.No Sound out at all and the ActionVoice plays messages and prompts with the
AbilitySpeaker unplugged. Make sure the connectors on the cable from the
AbilitySpeaker are plugged into the proper connectors on the ActionVoice. Make sure
the volume control on the ActionVoice is turned up. Make sure that the pillow speaker
supplied with the AbilitySpeaker is plugged into the AbilitySpeaker.
2. No sound from the pillow speaker and there IS sound from the AbilitySpeaker.
Make sure the Pillow speaker is plugged into the AbilitySpeaker correctly. Make sure
the pillow speaker volume control is turned up. Make sure there are prompts recorded.
Make sure the connectors on the cable from the AbilitySpeaker are plugged into the
proper connectors on the ActionVoice. Make sure you have an ActionVoice-2A and
that it is setup with OPTION 2 and AUDITORY MODE on.
APPENDICES 9
