Aaeon FWS-7200 Manual de usuario
Network Appliance FWS-7200
FWS-7200
1U Rackmount
Network Appliance Platform
3.5” SATA HDD x 1
or 2.5” SATA HDD x 2
CF SATA Socket
6 LAN Ports
2 USB2.0, 1 COM for Console
1 Mini PCI
FWS-7200 Manual 2nd Ed.
March 2013
Network Appliance FWS-7200
Copyright Notice
This document is copyrighted, 2013. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
i
Network Appliance FWS-7200
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
Intel®and Atomare trademarks of Intel®Corporation.
AMI is a trademark of American Megatrends Inc.
CompactFlash™ is a trademark of the Compact Flash
Association.
Microsoft Windows®is a registered trademark of Microsoft Corp.
All other product names or trademarks are properties of their
respective owners.
ii
Network Appliance FWS-7200
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
FWS-7200
CD-ROM for manual (in PDF format) and drivers
Ear Bracket x 1 set
Screw Accessories
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.
Note:
VGA Cable is an optional accessory. Please purchase those
cables according to the following item numbers.
1700160253 VGA Cable
iii
Network Appliance FWS-7200
Contents
Chapter 1 General Information
1.1 Introduction..........................................................1-2
1.2 Features..............................................................1-3
1.3 Specifications......................................................1-4
1.4 General System Information ...............................1-7
Chapter 2 Quick Installation Guide
2.1 Safety Precautions..............................................2-2
2.2 Location of Connectors of Main Board................2-3
2.3 Mechanical Drawing of Main Board ....................2-4
2.4 List of Jumpers....................................................2-5
2.5 List of Connectors ...............................................2-5
2.6 Setting Jumpers ..................................................2-7
2.7 CMOS Setting Selection (JP3)............................2-8
2.8 Auto PWRBTN Selection (JP6)...........................2-8
2.9 24-pin ATX Power Connector (ATX2).................2-8
2.10 Front Panel Connector (FP1)............................2-9
2.11 Pin Header (USB2)............................................2-9
2.12 RS-232 Box Header (COM2)............................2-9
2.13 SATA Connector (SATA 1, SATA 2).................2-10
2.14 CF-SATA Connector (CFD1) ............................2-10
2.15 Software Programmable Button (RSW1)..........2-11
2.16 Analog Display (VGA1) .....................................2-12
iv
Network Appliance FWS-7200
2.17 Installing the 2.5” Hard Disk Drive.....................2-14
2.18 Installing the 3.5” Hard Disk Drive.....................2-19
2.19 Installing the Expansion Card ...........................2-23
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization .............................3-2
3.2 AMI BIOS Setup..................................................3-3
Chapter 4 Driver Installation
4.1 Installation...........................................................4-3
Appendix A Programming the Watchdog Timer
A.1 Programming ..................................................A-2
A.2 W83627DHG Watchdog Timer Initial ProgramA-6
Appendix B I/O Information
B.1 I/O Address Map.............................................B-2
B.2 Memory Address Map.....................................B-4
B.3 IRQ Mapping Chart.........................................B-5
B.4 DMA Channel Assignments............................B-8
Appendix C Standard Firewall Platform Setting
C.1 Standard Firewall Platform Setting.................C-2
C.2 Status LED Sample Code...............................C-4
C.3 LAN Bypass Mode Sample Code...................C-7
C.4 Console Redirection .....................................C-11
v
Network Appliance FWS-7200
vi
Appendix D AHCI Settings
D.1 Setting AHCI...................................................D-2
Network Appliance FWS-7200
Chapter 1 General Information 1- 1
General
Chapter
1
Information
Network Appliance FWS-7200
1.1 Introduction
FWS-7200 adopts the Intel®Dual Core Atom™ D525 Processor
and equips with Intel®Atom™ D525 + ICH8M chipset. The system
memory features two 204-pin single channel DDR3 800MHz
SODIMM slots up to 4GB. It deploys six Gigabit Ethernet LAN
ports with one pair (optional two pairs) LAN bypass function. The
condensed appearance of FWS-7200 features 1U form factor that
fits nicely into a space- limited environment.
This compact FWS-7200 can be equipped with a 3.5” SATA HDD or
two 2.5” SATA HDD and CF-SATA socket. In addition, it offers
flexible expansion with network products and features one Mini-PCI
and two PCI expansion slots, two USB2.0 ports and one RS-232
console port on the front panel. The console port deploys console
re-direction that increases the network security via remote control.
Moreover, the front panel supports LCM with keypad control for
easy access and operation. All of these designs provide for a
more user-friendly solution.
Chapter 1 General Information 1- 2
Network Appliance FWS-7200
1.2 Features
1U Rackmount 6 LAN ports Network Appliance
Onboard Intel®Dual-Core Atom™ D525 processor
Intel®Atom™D525 + ICH8M
Two 204-pin Single Channel DDR3 800MHz SODIMM Up to
4GB
10/100/1000Base-TX Ethernet Port x 6 With One Pair
(Optional Two Pairs) LAN Bypass Function
3.5” SATA HDD x 1 or 2.5” SATA HDD x 2 and CF-SATA
Socket
One Parallel LCM with Keypad
RS-232 Console x 2 (Front Panel x 1, optional Pin Header x 1),
USB2.0 x 2 (Type A Connector x 2 and optional Pin Header x
2)
AC Power Input Requirement
Mini PCI Slot x 1, Expansion PCI Slot x 2
Parallel LCM With Keypad On The Front Panel
Chapter 1 General Information 1- 3
