Aaeon PER-C30F Manual de usuario
Mini PCI Module PER-C30F
PER-C30F Quick Installation Guide 1
PER-C30F
Quick Installation Guide
Part No. 2007C30F12 Printed in Taiwan Apr. 2007
Mini PCI Module PER-C30F
PER-C30F Quick Installation Guide 2
Content
A Message to the Customer.............................................................4
Product Warranty..............................................................................5
Ordering Information.........................................................................7
Packing List ......................................................................................7
1.1 Features......................................................................................8
1.2 Specifications..............................................................................8
1.3 Mechanical Drawing and Connector Locations..........................9
1.4 PER-C30F Connector List........................................................ 11
1.5 PER-T010 Daughter Board Connector List..............................13
Mini PCI Module PER-C30F
PER-C30F Quick Installation Guide 3
Notice
This guide is designed for experienced users to setup the system in
the shortest time.
Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working
on it. Do not make connections while the
power is on, because a sudden rush of power
can damage sensitive electronic
components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap
at all times. Place all electronic components
on a static-dissipative surface or in a
static-shielded bag when they are not in the
chassis
Mini PCI Module PER-C30F
PER-C30F Quick Installation Guide 4
A Message to the Customer
Fist of all, thank you for purchasing PER-C30F Mini PCI module.
This Quick Installation Guide will help you on the process of the
installation. Please read it thoroughly before you start to install it.
The product comes with a two year limited warranty except for
improper use. Therefore, we strongly suggest that you read and
refer to the Quick Installation Guide before any installation. You
may visit AAEON website for the latest version of the instruction
guide. Please refer to Http://www.aaeon.com
Mini PCI Module PER-C30F
PER-C30F Quick Installation Guide 5
Product Warranty
AAEON Customer Services
All products in AAEON are designed according to the strictest
specifications to ensure that these products will retain reliable
performance in typical industrial environments. Whether your
purchase from AAEON is made for use in the laboratory or the
factory facility, you can be assured that every purchase in AAEON
will provide reliability and stability of operation.
Your satisfaction is our primary concern. Here is a guide for
AAEON's customer services. To ensure you get full benefits of our
services, please follow the instructions below step by step.
Technical Support
We want you to get the maximum performance from your products. If
you run into technical difficulties, we will always be here for you. For
the most frequently asked questions, you can easily find solutions in
your product documentation. The guide is specific in detail so please
refer to it first. Therefore, we suggest strongly that you can read it
before asking for customer service over the phone. If you still cannot
find the answer, gather all questions you can think of and have the
product at hand before giving a call to your dealer. All dealers of
AAEON are well-trained and ready to provide you as much supports
as they can. Based on the customer service problems we have
encountered, most of them are minor and able to be easily solved
Mini PCI Module PER-C30F
PER-C30F Quick Installation Guide 6
over the phone. In addition, free technical support is available from
AAEON engineers during office hours. We are always pleased to
give advice regarding any installation and operation for AAEON
products.
Mini PCI Module PER-C30F
PER-C30F Quick Installation Guide 7
Ordering Information
PER-C30F-A10
Mini PCI 3-Port IEEE1394a Module
Packing List
PER-C30F
PER-T010 daughter board
Quick Installation Guide
Mini PCI Module PER-C30F
PER-C30F Quick Installation Guide 8
1.1 Features
• Supports three IEEE1394a ports up to 400Mbps
• TI single chip for IEEE1394a solution
1.2 Specifications
• Form factor Mini PCI Type IIIA
( 50.8mm x 59.6mm )
• IEEE1394a Chipset TI TSB43AB23
• Power Request +3.3V, +5V, +12V
• Operation Temp. 0°C ~ 60°C
Mini PCI Module PER-C30F
PER-C30F Quick Installation Guide 9
1.3 Mechanical Drawing and Connector Locations
CN3
MPCI1
CN2
CN1
For model of PER-C30F
Mini PCI Module PER-C30F
PER-C30F Quick Installation Guide 10
CN3
CN4CN2CN1
0.00
6.00
29.00
35.00
0.00
85.00
33.53
29.46
14.55
11.50
29.50
47.50
3.50
81.50
29.00
6.00
10.60
6.10
16.50 18.00 18.00
For model of PER-T010
