Aaeon IMBA-H110A Manual de usuario

Industrial Motherboard

IMBA-H110A

E13195_IMBA-H110A_Guide.indb 1 2017/9/25 14:05:08

E13521

Revised Edition

September 2017

This document is copyrighted, 2017. All rights are reserved. The original

manufacturer reserves the right to make improvements to the products described

in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated, or transmitted

in any form or by any means without the prior written permission of the original

manufacturer. Information provided in this manual is intended to be accurate and

reliable. However, the original manufacturer assumes no responsibility for its use,

or for any infringements upon the rights of third parties that may result from its use.

The material in this document is for product information only and is subject to

change without notice. While reasonable efforts have been made in the preparation

of this document to assure its accuracy, the original manufacturer assumes no

liabilities resulting from errors or omissions in this document, or from the use of the

information contained herein.

The original manufacturer reserves the right to make changes in the product

design without notice to its users.

Acknowledgments

All other products’ name or trademarks are properties of their respective owners.

• AMI is a trademark of American Megatrends Inc.

• Intel®, Core™ are trademarks of Intel®Corporation.

• Microsoft Windows®is a registered trademark of Microsoft Corp.

• IBM, PC/AT, PS/2, and VGA are trademarks of International Business

Machines Corporation.

The original manufacturer reserves the right to make changes in the product

design without notice to its users.

All other product names or trademarks are properties of their respective owners.

E13195_IMBA-H110A_Guide.indb 2 2017/9/25 14:05:08

iii

Contents

Chapter 1: Product overview

1.1 Package contents......................................................................... 1-1

1.2 Features ........................................................................................ 1-1

1.3 Specications............................................................................... 1-2

Chapter 2: Motherboard information

2.1 Before you proceed ..................................................................... 2-1

2.2 Motherboard layout...................................................................... 2-2

2.3 Screw size..................................................................................... 2-4

2.3.1 Component side.............................................................. 2-4

2.3.2 Solder side ...................................................................... 2-5

2.4 Central Processing Unit (CPU) ................................................... 2-6

2.4.1 Installing the CPU ........................................................... 2-7

2.4.2 CPU heatsink and fan assembly installation................... 2-9

2.5 System memory ......................................................................... 2-10

2.6 Jumpers ...................................................................................... 2-12

2.7 Connectors ................................................................................. 2-15

2.7.1 Rear panel connectors.................................................. 2-15

2.7.2 Internal connectors ....................................................... 2-17

Chapter 3: BIOS setup

3.1 BIOS setup.................................................................................... 3-1

3.2 Main menu .................................................................................... 3-2

3.2.1 System Date [Day MM/DD/YYYY] .................................. 3-2

3.2.2 System Time [HH:MM:SS] .............................................. 3-2

3.3 Advanced menu ........................................................................... 3-2

3.3.1 CPUConguration .......................................................... 3-3

3.3.2 Trusted Computing ......................................................... 3-3

3.3.3 SATAConguration ........................................................ 3-4

3.3.4 PCH-FWConguration ................................................... 3-5

3.3.5 SIOConguration ........................................................... 3-5

3.3.6 NCT6791D HW Monitor .................................................. 3-6

3.3.7 USBConguration .......................................................... 3-9

3.3.8 DigitalIOPortConguration ........................................... 3-9

3.3.9 Power Management........................................................ 3-9

3.4 Chipset menu ............................................................................. 3-10

E13195_IMBA-H110A_Guide.indb 3 2017/9/25 14:05:08

3.4.1 SystemAgent(SA)Conguration ................................. 3-10

3.4.2 PCH-IOConguration ................................................... 3-11

3.5 Security menu ............................................................................ 3-11

3.5.1 Administrator Password ................................................ 3-11

3.5.2 User Password.............................................................. 3-12

3.6 Boot menu .................................................................................. 3-12

3.6.1 BootConguration ........................................................ 3-12

3.6.2 Boot Option Priorities .................................................... 3-13

3.7 Save & Exit menu....................................................................... 3-13

Appendix

Notices.......................................................................................................A-1

E13195_IMBA-H110A_Guide.indb 4 2017/9/25 14:05:08

1-1

Chapter 1: General information

1.1 Package contents

Check your industrial motherboard package for the following items.

1 x Industrial Motherboard

1 x SATA 6.0Gb/s cable

1 x COM cable

1 x I/O Shield

1 x Support CD

If any of the above items is damaged or missing, contact your distributor or

sales representative immediately.

1.2 Features

• Intel®7th/ 6th Generation Core™ i7/ i5/ i3, Pentium®and Celeron®14nm

LGA1151 socket processor

• 2 x DIMMs, max. 32GB, DDR4 2400 / 2133/ 1867 MHz, non-ECC,

un-buffered memory

• 3 x SATA III 6.0 Gb/s, 4x USB 3.0, 6 x USB 2.0

• Realtek®ALC8876-ChannelHighDenitionAudioCODEC

• Multi Display: VGA+HDMI, VGA+DP, HDMI+DP

• Dual Ethernet LAN: 1 x Intel®PHY i219V Giga LAN, 1 x Intel®i211AT Giga

LAN, RJ45 x 2

• 1 x PCIe 3.0/2.0 [x16] slot, 1 x PCIe 2.0 [x4] slot, 4 x PCI slots

• 1 x M.2 M key (22 x 80mm) slot for SATA

Chapter 1

Product overview

E13195_IMBA-H110A_Guide.indb 1 2017/9/25 14:05:08

IMBA-H110A

1-2

1.3 Specications

(continued on the next page)

SYSTEM

CPU Intel®7th/ 6th Generation (Kaby Lake-S/ Skylake-S) Core™ i7/ i5/ i3,

Pentium®and Celeron®14nm LGA1151 socket processor

Chipset Intel®H110 Express Chipset

Memory 2 x DIMMs, max. 32 GB, DDR4 2400*/ 2133/ 1867 MHz, non-ECC,

un-buffered memory

Dual channel memory architecture

*2400 MHz can only be reached when a Kaby Lake processor is used.

I/O Chipset NCT6791D + F81216HD

Ethernet 1 x Intel®PHY i219V Giga LAN

1 x Intel®i211AT Giga LAN, RJ45 x 2

Audio Realtek®ALC8876-ChannelHighDenitionAudioCODEC

(Colay/ALC886)

TPM Nuvoton NPCT650ABBYX TPM2.0 onboard (optional)

Expansion slots 1 x PCIe 3.0/2.0 [x16] slot

1 x PCIe 2.0 [x4] slot (open edge)

4 x PCI slots

1 x M.2 M-key (22 x 80mm) slot for SATA

BIOS 1 x 128Mbit Flash ROM, AMI BIOS

Added Buffer IC

H/W Status Monitor Monitors CPU/chasiss temperature

Monitors Vcore/5V/3.3V/12V/3VSB/VBAT voltages

Monitors CPU/chassis fan speed

Watchdog Timer 1~255 steps by software program

Smart Fan Control CPU Fan / Chassis Fan x 2

Wake On LAN / PXE Yes ( WOL, PXE)

Power States S3, S4, S5

Graphics

Graphics Chipset Intel®HD Graphics

VGA support via RTD2168

Graphics Multi Display VGA+HDMI, VGA+DP, HDMI+DP

Resolution VGA: Up to 1920 x 1200 @60Hz (via RTD2168)

HDMI1.4: Up to 4096 x 2304 @24Hz

DP1.2: Up to 4096 x 2304 @60Hz

Environment, Power, and ME

Battery Lithium battery

Power requirement 1 x 24-pin ATX connector

1 x 8-pin (2x4) ATX 12V power connector

Operating temperature 32oF~140oF (0oC~60oC)

Storage temperature -40oF~185oF (-40oC~85oC)

Operating humidity 0%~90% relative humidity, non-condensing

Certicate CE & FCC class A

Form factor ATX form factor: 12 in. x 9.6 in. (305 mm x 244 mm)

Weight 1.76 lb (0.8 Kg)

E13195_IMBA-H110A_Guide.indb 2 2017/9/25 14:05:08

1-3

Chapter 1: General information

Back I/O

USB 4 x USB 3.0 ports

2 x USB 2.0 ports

Display 1 x HDMI ports

1 x VGA port

1 x Disaplay port

Serial port 1 x RS-232/422/485 COM port (COM1, supports 5V/12V/RI, optional)

PS/2 port 1 x PS/2 stack port (keyboard & mouse)

LAN 2 x LAN (RJ-45) ports

Audio 3 x Audio jacks: Line-in, Mic-in, Line-out

Internal I/O

Storage 3 x SATA III 6.0Gb/s ports

1 x M.2 M-Key slot (22 x 80mm)

USB 2 x USB 2.0 connectors support additional 4 USB ports

Audio 1 x AMP speaker header (Line-out)

Serial port 5 x RS-232 headers

DIO 1 x 8-bit Digital I/O interface (In/Out programmable)

Fan 1 x CPU Fan connector (4-pin)

2 x Chassis Fan connectors (4-pin)

Power 1 x 24-pin EATX Power header

1 x 8-pin EATX 12V Power connector

Others 1 x Chassis Intrusion

1 x AT/ATX mode select jumper

1 x Front panel header

1 x Clear CMOS jumper

Others

OS support Windows®10 64-bit

Windows®8.1 64-bit (not supported when using a Kaby Lake processor)

Windows®7 32-bit / 64-bit (not supported when using a Kaby Lake

processor)

Linux Fedora 64bit

Accessories 1 x SATA 6.0Gb/s cable

1 x COM cable

1 x I/O shield

1 x Support DVD

NOTE: Specicationsaresubjecttochangewithoutnotice.

E13195_IMBA-H110A_Guide.indb 3 2017/9/25 14:05:08

IMBA-H110A

1-4

E13195_IMBA-H110A_Guide.indb 4 2017/9/25 14:05:08

2-1

Chapter 2: Motherboard information

Chapter 2

Motherboard information

2.1 Before you proceed

Take note of the following precautions before you install motherboard components

or change any motherboard settings.

CAUTION!

• Unplugthepowercordfromthewallsocketbeforetouchingany

component.

• Beforehandlingcomponents,useagroundedwriststraportouchasafely

groundedobjectorametalobject,suchasthepowersupplycase,toavoid

damaging them due to static electricity.

• HoldcomponentsbytheedgestoavoidtouchingtheICsonthem.

• Wheneveryouuninstallanycomponent,placeitonagroundedantistatic

pad or in the bag that came with the component.

• Beforeyouinstallorremoveanycomponent,ensurethattheATXpower

supply is switched off or the power cord is detached from the power

supply.Failuretodosomaycauseseveredamagetothemotherboard,

peripherals,orcomponents.

E13195_IMBA-H110A_Guide.indb 1 2017/9/25 14:05:08

IMBA-H110A

2-2

IMBA-H110A

PCIEX16_1

M2_TYPE_M1

2280

PCIEX4

PCI1

PCI2

PCI3

PCI4

F_PANEL1

CLRTC1

AT_ATX

CHASSIS

USB910 USB78

EATX_PWR1

CPU_FAN1

CHA_FAN1

CHA_FAN2

BATTERY1

Super

I/O

Super

I/O

ASM

1085

ALC

887

COM1_V1

COM1

VGA

ASM

1442K

RTD

2168

LGA1151

Intel®

H110

Intel®

PHY i219V

Intel®

i211AT

DDR4 DIMM_A1 (64bit, 288-pin module)

DDR4 DIMM_B1 (64bit, 288-pin module)

SATA6G_2

SPI_1

SATA6G_1

SATA6G_3

BUZZER1

AUDIO1

KBMS

24.4cm(9.6in)

128Mb

BIOS

EATX_PWR2

HDMI

_DP1

USB56

30.5cm(12.0in)

COM3COM4

COM2

COM5COM6

DIO

AMP_CON

LAN2_USB3_34

LAN1_USB3_12

5 42 431 6

12134141617 7

2.2 Motherboard layout

Place this side

towards the rear

of the chassis

NOTE: Place nine screws into the holes indicated by circles to secure the

motherboard to the chassis.

CAUTION!Donotovertightenthescrews!Doingsocandamagethe

motherboard.

E13195_IMBA-H110A_Guide.indb 2 2017/9/25 14:05:08

Tabla de contenidos

Otros manuales de Placa madre de Aaeon

Aaeon

Aaeon Gene-6320 Manual de usuario

Aaeon

Aaeon PCM-6894 Manual de usuario

Aaeon

Aaeon EMB-Q170A Manual de usuario

Aaeon

Aaeon MB-662 Manual de usuario

Aaeon

Aaeon GENE-A55E Manual de usuario

Aaeon

Aaeon All-in-One Super7 Single Board Computer... Manual de usuario

Aaeon

Aaeon PCM-7890 Manual de usuario

Aaeon

Aaeon EPIC-9457 Manual de usuario

Aaeon

Aaeon EMB-945T Manual de usuario

Aaeon

Aaeon EMB-BSW1 Manual de usuario

Aaeon

Aaeon EMB-LN8T Manual de usuario

Aaeon

Aaeon PCM-6894 Manual de usuario

Aaeon

Aaeon SBC-670S Manual de usuario

Aaeon

Aaeon EMB-Q170C Manual de usuario

Aaeon

Aaeon EMB-9459T Manual de usuario

Aaeon

Aaeon EMB-BT1 Manual de usuario

Aaeon

Aaeon PCM-6890B Manual de instrucciones

Aaeon

Aaeon EMB-9658T Mini-ITX Manual de usuario

Aaeon

Aaeon Compact Board PCM-9452 Manual de usuario

Aaeon

Aaeon HSB-910I Manual de usuario

Aaeon

Aaeon EMB-Q77B Manual de usuario

Aaeon

Aaeon MIX-H310D2 Manual de usuario

Aaeon

Aaeon GENE-CV05 Manual de usuario

Aaeon

Aaeon VIA Eden Series Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario
