Aaeon AEC-6637 Manual de usuario

Embedded Controller AEC-6637

AEC-6637

Fanless Embedded Controller

Intel

®Core™ i7/i5 Mobile Processor

2 Gigabit Ethernet

2 USB3.0, 2 USB2.0, 4 COM

1 Mini Card

AEC-6637 Manual 2nd Ed.

July 2013

Embedded Controller AEC-6637

This document is copyrighted, 2013. All rights are reserved. The

original manufacturer reserves the right to make improvements to

the products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated, or

transmitted in any form or by any means without the prior written

permission of the original manufacturer. Information provided in

this manual is intended to be accurate and reliable. However, the

original manufacturer assumes no responsibility for its use, or for

any infringements upon the rights of third parties that may result

from its use.

The material in this document is for product information only and is

subject to change without notice. While reasonable efforts have

been made in the preparation of this document to assure its

accuracy, AAEON assumes no liabilities resulting from errors or

omissions in this document, or from the use of the information

contained herein.

AAEON reserves the right to make changes in the product design

without notice to its users.

Embedded Controller AEC-6637

Acknowledgments

All other products’ name or trademarks are properties of their

respective owners.

AMI is a trademark of American Megatrends Inc.

CFast™is a trademark of the CompactFlash Association.

Microsoft Windows®is a registered trademark of Microsoft

Corp.

Intel®, Core™ are trademarks of Intel Corporation.

PC/AT, PS/2, and VGA are trademarks of International

Business Machines Corporation.

All other product names or trademarks are properties of their

respective owners.

Embedded Controller AEC-6637

iii

Packing List

Before you begin operating the product, please make sure that the

following materials are enclosed:

1 AEC-6637 Embedded Controller

2 Wallmount Brackets

1 Screw Package

4 RAM Thermal Pads (1998F15003 x 1, 1998666630 x

2, 1998666652 x 1)

1 DVD-ROM for manual (in PDF format) and drivers

If any of these items should be missing or damaged, please contact

your distributor or sales representative immediately.

Embedded Controller AEC-6637

Safety & Warranty

1. Read these safety instructions carefully.

2. Keep this user's manual for later reference.

3. Disconnect this equipment from anyAC outlet before cleaning. Do

not use liquid or spray detergents for cleaning. Use a damp cloth.

4. For pluggable equipment, the power outlet must be installed near

the equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a firm surface during installation. Dropping

it or letting it fall could cause damage.

7. The openings on the enclosure are for air convection. Protect the

equipment from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before

connecting the equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not

place anything over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the

power source to avoid damage by transient over-voltage.

12. Never pour any liquid into an opening. This could cause fire or

electrical shock.

13. Never open the equipment. For safety reasons, only qualified

service personnel should open the equipment.

14. If any of the following situations arises, get the equipment

checked by service personnel:

a. The power cord or plug is damaged.

b. Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

Embedded Controller AEC-6637

d. The equipment does not work well, or you cannot get it

to work according to the user’s manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT

WHERE THE STORAGE TEMPERATURE IS BELOW -20°C

(-4°F) OR ABOVE 70°C (158°F). IT MAY DAMAGE THE

EQUIPMENT.

FCC

This device complies with Part 15 FCC Rules.

Operation is subject to the following two

conditions: (1) this device may not cause

harmful interference, and (2) this device must

accept any interference received including

interference that may cause undesired

operation.

Caution:

There is a danger of explosion if the battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the

manufacturer. Dispose of used batteries according to the

manufacturer’s instructions and your local government’s recycling or

disposal directives.

Embedded Controller AEC-6637

Below Table for China RoHS Requirements

产品中有毒有害物质或元素名称及含量

AAEON Boxer/ Industrial System

有毒有害物质或元素

部件名称铅

(Pb)

汞

(Hg)

镉

(Cd)

六价铬

(Cr(VI))

多溴联苯

(PBB)

多溴二苯醚

(PBDE)

印刷电路板

及其电子组件 ×○○○○○

外部信号

连接器及线材 ×○○○○○

外壳 ×○○○○○

中央处理器

与内存 ×○○○○○

硬盘 ×○○○○○

电源 ×○○○○○

O：表示该有毒有害物质在该部件所有均质材料中的含量均在

SJ/T 11363-2006 标准规定的限量要求以下。

X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出

SJ/T 11363-2006 标准规定的限量要求。

备注：

一、此产品所标示之环保使用期限，系指在一般正常使用状况下。

二、上述部件物质中央处理器、内存、硬盘、电源为选购品。

Embedded Controller AEC-6637

vii

Contents

Chapter 1 General Information

1.1 Introduction................................................................1-2

1.2 Features....................................................................1-3

1.3 Specifications............................................................1-4

Chapter 2 Hardware Installation

2.1 Dimension & Connectors of AEC-6637.....................2-2

2.2 Connectors and Jumpers of the Main Board ............2-6

2.3 List of Jumpers..........................................................2-8

2.4 List of Connectors .....................................................2-9

2.5 Setting Jumpers ........................................................2-11

2.6 LVDS Port 1 Backlight Inverter VCC Selection (JP3)2-12

2.7 LVDS Port 1 Operating VDD Selection (JP5)...........2-12

2.8 LVDS Port 1 Backlight Lightness Control Mode Selection

(JP6)................................................................................2-12

2.9 COM2 Pin8 Function Selection (JP8) .......................2-13

2.10 Front Panel Connector (JP9) ..................................2-13

2.11 Touch Screen 4/5/8-Wire Selection (JP10).............2-14

2.12 Clear CMOS (JP11) ................................................2-14

2.13 AT/ATX Power Supply Mode Selection (JP12).......2-14

2.14 LVDS Port 1 Inverter/ Backlight Connector (CN1)..2-15

2.15 External +12V Input (CN2)......................................2-15

2.16 USB2.0 Port 7 and Port 8 (CN3).............................2-16

2.17 USB2.0 Port 5 and Port 6 (CN4).............................2-16

Embedded Controller AEC-6637

viii

2.18 USB2.0 Port 3 and Port 4 (CN5).............................2-17

2.19 External +5VSB Input (CN6)...................................2-18

2.20 Audio I/O Port Connector (CN8) .............................2-18

2.21 LVDS Port 1 Connector (CN9)................................2-19

2.22 COM Port 2 Connector (CN11)...............................2-20

2.23 LPT/ Digital I/O Port Connector (CN12)..................2-22

2.24 COM Port 3 Connector (CN13)...............................2-26

2.25 LPC Port Connector (CN14) ...................................2-26

2.26 COM Port 4 Connector (CN15)...............................2-27

2.27 UIM Card Module (CN16) .......................................2-28

2.28 PS/2 Keyboard/Mouse Combo Port Connector (CN17)

.........................................................................................2-28

2.29 +5VSB Output w/SMBus (CN18) ............................2-29

2.30 Touch Screen Connector (CN19)............................2-30

2.31 CPU FAN Connector (CN20)..................................2-32

2.32 +5V Output for SATA HDD (CN22).........................2-32

2.33 Realtek LAN (RJ-45) Port (CN23)...........................2-33

2.34 Intel LAN (RJ-45) Port (CN24)................................2-33

2.35 USB Port 1 and Port 2 (CN25)................................2-34

2.36 VGA Port (CN26).....................................................2-35

2.37 COM Port 1 (D-SUB 9) (CN27)...............................2-36

2.38 CFast Slot (CN28)...................................................2-37

2.39 DDR3 SODIMM Slot (CN29)...................................2-38

2.40 Mini Card Slot (CN30).............................................2-38

2.41 SATA Port 1 (SATA1)..............................................2-40

Embedded Controller AEC-6637

2.42 SATA Port 2 (SATA2)..............................................2-41

2.43 CFast™ Card Installation........................................2-42

2.44 Hard Disk Drive (HDD) Installation..........................2-45

2.45 Memory Card Installation........................................2-48

2.46 Wallmount Kit Installation........................................2-51

Chapter 3 AMI BIOS Setup

3.1 System Test and Initialization. ..................................3-2

3.2 AMI BIOS Setup........................................................3-3

Chapter 4 Driver Installation

4.1 Installation.................................................................4-3

Appendix A Programming The Watchdog Timer

A.1 Programming ........................................................A-2

A.2 ITE8728F Watchdog Timer Initial Program...........A-6

Appendix B I/O Information

B.1 I/O Address Map....................................................B-2

B.2 Memory Address Map............................................B-4

B.3 IRQ Mapping Chart................................................B-5

B.4 DMA Channel Assignments...................................B-5

Appendix C RAID & AHCI Settings

C.1 Setting RAID......................................................... C-2

C.2 Setting AHCI......................................................... C-9
